Keithley 2001 Quick Reference Guide

60
:CALCulate3
:LIMit[1]
:CLEAR
[:IMMediate]
:AUTO <b>
:AUTO?
:LIMit2
:UPPer
[:DATA] <n>
[:DATA]?
:SOURce <NRf>
:SOURce?
:LOWer
[:DATA] <n>
[:DATA]?
:SOURce <NRf>
:SOURce?
:STATe <b>
:STATe?
:FAIL?
:CLEAR
[:IMMediate]
:AUTO <b>
:AUTO?
:PASS
:SOURce <NRf>
:CLIMits
:FAIL?
:BSTRobe
:STATe <b>
:STATe?
:IMMediate
Clear failed test indication.
Enable (1 or ON) or disable (0
or OFF) auto clear.
Query auto clear.
Path to control LIMIT 2 test:
Path to configure upper limit:
Specify upper limit
(-9.999999e35
to +9.999999e35).
Query upper limit.
Specify digital output (0 to 15).
Query source (digital output
value).
Path to configure lower limit:
Specify lower limit
(-9.999999e35
to +9.999999e35).
Query lower limit.
Specify digital output (0 to 15).
Query source (digital output
value).
Enable (1 or ON) or disable (0
or OFF) limit test.
Query state of limit test.
Query test result (1 = pass,
0 = fail).
Path to clear failed test:
Clear failed test indication.
Enable (1 or ON) or disable
(0 or OFF) auto clear.
Query auto clear.
Path to define “pass” digital output
pattern.
Specify digital output (0 to 15).
Command path for composite lim-
its:
Query composite result of LIMIT
1 and LIMIT 2 tests (1 = pass, 0
= fail).
Path to control limit binning strobe:
Enable (1 or ON) or disable (0 or
OFF) strobe.
Query state of binning strobe.
Re-perform limit tests.
Table 23. Calculate command summary (cont.)
Command Description

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
