Front panel introduction
Typical Series 3700 front panels are shown below.
NOTE Not all models will have a DMM installed. All DMM related documentation is not
applicable to those models.
Figure 2-1: Model 3706 System Switch/Multimeter
Item
Description
1
Special keys and power switch
(on page 2-6)
2
Operation keys
(on page 2-7)
3
Range, multifunction keys, and wheel (on page 2-17)
4
Function keys
(on page 2-17)
5
Display
(on page 2-3)
6
USB connector (see "USB connectors" on page 3-4)
Section 2
Using the Front Panel
