In this section:
DMM measurement capabilities ....................................................................... 5-1
High-energy circuit safety precautions .............................................................. 5-2
Performance considerations ............................................................................ 5-3
Voltage measurements (DCV and ACV)........................................................... 5-4
Current measurements (DCI and ACI) ............................................................. 5-15
AMPS analog backplane fuse replacement ...................................................... 5-16
Resistance measurements .............................................................................. 5-17
Temperature measurements ............................................................................ 5-35
Frequency and period measurements
.............................................................. 5-48
Continuity testing ............................................................................................ 5-50
DMM measurement capabilities
The DMM of the Series 3700 can make the following measurements:
DCV: DC voltage measurements from -303V to 303V
ACV: AC voltage measurements from 0V to 303V
DCI: DC current measurements from -3.1A to 3.1A
ACI: AC current measurements from 0A to 3.1A
2: 2-wire resistance measurements from 0to 120M
4: 4-wire resistance measurements from 0to 120M.
CS: Common side ohms resistance measurements from 0to 120M.
FREQ: Frequency measurements from 3Hz to 500kHz.
PERIOD: Period measurements from 2s to 333ms.
TEMP: Temperature measurements from -200°C to 1820°C.
CONT: Continuity testing using the 1krange.
CAUTION When using a switching module, do not exceed the maximum signal levels of
the module.
