Keithley 3720 User Manual

In this section:
Rear panel summary ....................................................................................... 3-1
Rear panel connections ................................................................................... 3-2
Switching module installation and connections ................................................. 3-6
Module installation .......................................................................................... 3-6
Bus operation .................................................................................................. 3-10
Power-up ........................................................................................................ 3-11
Rear panel summary
Figure 3-1: Rear panel features
Item
Description
1
Analog backplane fuse (see "Analog backplane AMPS fuse" on page 3-2)
2
Slots (6 places)
(see "Slots" on page 3-2)
3
TSP-link® connectors (2 places) (see "TSP-Link connector" on page 3-2)
4
Instrument fuse
(on page 3-2)
5
Power connector
(on page 3-2)
6
Digital I/O port
(on page 3-3)
7
GPIB connector
(on page 3-4)
8
Ethernet connector (see "Ethernet connector (RJ-45)" on page 3-4)
9
USB connector
(see "USB connectors" on page 3-4)
10
Analog backplane connector (on page 3-5)
