Keithley DMM6500 Quick Start Guide

FAQs and next steps
Why can’t the DMM6500 read my USB ash drive?
Verify that the ash drive is formatted with the FAT le
system. The DMM6500 only supports FAT drives.
In Microsoft
®
Windows
®
, you can check the le system by
checking the properties of the USB ash drive.
How do I save the present state of the instrument?
You can save the settings in the instrument as a script using
the front-panel menus or from a remote interface. After they
are saved, you can recall the script or copy it to a USB ash
drive.
From the front panel:
1. Congure the DMM6500 to the settings that you want
to save.
2. Press the MENU key.
3. Under Scripts, select Save Setup.
4. Select Create.
5. Use the keyboard to enter the name of the script.
6. Select the OK button on the displayed keyboard. The
script is added to internal memory.

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
