Interactive SourceMeter® Instrument User's Manual Section 10:
2450-900-01 Rev. C / December 2013 10-5
What are the Quick Setup options?
The QUICKSET key opens a screen that provides predefined function, performance, and quick
setups.
The Function button allows you to select the source and measurement functions. These same options
are available through the FUNCTION key
The Performance slider allows you to adjust speed and resolution. As you increase speed, you lower
the amount of resolution. As you increase resolution, you decrease the reading speed. These settings
take effect the next time the output is turned on and measurements are made.
The Quick Setups allow you to set the instrument to operate as a Voltmeter, Ammeter, Ohmmeter, or
Power Supply.
When you select a Quick Setup, the instrument turns the output on. Carefully consider and configure
the appropriate output-off state, source, and limits before connecting the Model 2450 to a device that
can deliver energy, such as other voltage sources, batteries, capacitors, or solar cells. Configure the
settings that are recommended for the instrument before making connections to the device. Failure
to consider the output-off state, source, and limits may result in damage to the instrument or to the
device under test (DUT).
