5-10 Sweep Operation Series 2600 System SourceMeters Reference Manual
2600S-901-01 Rev. A / May 2006 Return to Section 5 topics
Pulse sweep functions
Functions for pulse sweeps are listed in Table 5-3.
Table 5-3
Pulse sweep functions
Function Description
PulseIMeasureV(smu, bias, level, ton, toff, points)
smu
bias
level
ton
toff
points
Define fixed source current pulse sweep:
Smu: smua for channel A or smub for channel B.
DC bias current level in amps.
On source value of the pulse in amps.
Pulse on time in seconds.
Pulse off time in seconds.
Number of pulse-measure cycles.
PulseVMeasureI(smu, bias, level, ton, toff, points)
channel
bias
level
ton
toff
points
Define fixed source voltage pulse sweep:
Smu: smua for channel A or smub for channel B.
DC bias voltage level in volts.
On source value of the pulse in volts.
Pulse on time in seconds.
Pulse off time in seconds.
Number of pulse-measure cycles.
Custom sweep functions
Functions for list (custom) sweeps are listed in Table 5-4.
Table 5-4
Custom sweep functions
Command Description
SweepIListMeasureV(smu, ilist, stime, points)
smu
ilist
stime
points
Define current list sweep:
Smu: smua for channel A or smub for channel B.
List of current values in amps.
Settling time (source-measure delay in seconds).
Number of points (≥2).
SweepVListMeasureI(smu, vlist, stime, points)
smu
vlist
stime
points
Define voltage list sweep:
Smu: smua for channel A or smub for channel B.
List of voltage values in volts.
Settling time (source-measure delay in seconds).
Number of points (≥2).
