Series 2600 System SourceMeters User’s Manual Front Panel Operation 1-13
Return to In this section: 2600S-900-01 Rev. A / May 2006
Figure 1-4
Interlock circuit
To output stage
10kW
Rear panel
Chassis ground
Coil resistance
145W +/- 10%
-220V supply
+220V supply
INTERLOCK pin
(on DIGITAL I/O connector)
Read by firmware
