©2009 4Front Engineered Solutions, Inc.
January 2009 6004754F — HK and HK-S Hydraulic Dock Leveler, 3 Button — SafeTFrame
™
31
138-837 (x2)
6001044 (x2)
6004009
(STANDARD)
6004010
(WITH ARTD)
OPERATIONS
WARNING AND OPERATION PLACARD
(MOUNTED ON WALL NEAR LEVELER)
DO NOT LIFT
THIS SIDE
700-136
156-241 (x2)
(HK-S Model Only)
921-070
921-074
PREVENTIVE MAINTENANCE
Fig. 34
Every 90 days (quarterly) inspect all safety labels and tags
to ensure they are on the dock leveler and are easily legible.
If any are missing or require replacement, please call your
local Kelley distributor.
