8. TECHNICAL DATA
MASTER 2200
Mains voltage 3~, 50/60 Hz 380 V -10 % … 415 V +6 %
Rated power 25 % ED 220 A / 8,4 kVA
60 % ED 145 A / 5,5 kVA
100 % ED 110 A / 3,5 kVA
Connection cable/fuses 4 x 1,5S / 10 A delayed
Welding current range MMA 15 A / 20,5 V … 220 A / 28,8 V
Electrode sizes to be welded ø 1,5 … 4,0 (5,0) mm
Welding current control stepless
Open circuit voltage 80 V
Efficiency 82 % (220 A / 28,8 V)
Power factor 0,9 (220 A / 28,8 V)
Open circuit power approx. 10 W
Storage temperature range -40 … +60°C
Operation temperature range -20 … +40°C
Temperature class H (180°C) / B (130°C)
Degree of protection IP 23C
External dimensions: length 472 mm
width 152 mm
height 302 mm
Weight 12,5 kg
Suitable accessories: remote control units C 100C, C 100D
The product meets conformity requirements for CE marking.
10 – MASTER 2200/0530 © KEMPPI OY
