If the saved settings need to be adjusted the led has to be moved from ON to SET position in
order to select parameters. Press the SAVE button. It is also possible to save the currently used
parameters by pressing SET when the memory function is in OFF state (no lights on). Channel
is cleared if MEMORY and CH buttons are pressed simultaneously in SET mode.
3.2.4 Adopting the saved settings
1. Select MEMORY by pressing the button.
2. Select memory channel by pressing the CH button.
3. Start welding.
3.2.5 Remote control memory channels
Memory channels are selected by pressing simultaneously both REMOTE and CH button. With
the remote control you can retrieve saved settings on memory channels.
3.2.6 SETUP functions
A so called SETUP state is included for modifying panel functions. You can enter the SETUP
state by pressing the REMOTE (SETUP) button longer than normally. Exit is performed in the
same way. You can select the function (see list below) by pressing the arrow buttons and then
change the setting by turning the potentiometer.
Display Function Factory setting
A1
Upslope with constant time setting /
gradient (steepness) setting
0 constant time
A2
Downslope with constant time setting /
gradient (steepness) setting
0 constant time
A3
TIG antifreeze o / on 1 o
A4
MMA antifreeze o / on 1 on
A5
MMA hot start pulse non adaptive / adaptive 0 non adaptive
A6
Downslope cut o on / o 0 on
A7
MMA open circuit voltage 80V / 40V 0 80 V
A8
2T downslope normal / cuts o by short switch action 0 normal
A9
Tacking automatics o / on 0 o
A10
Current at arc start steep / slightly sloped 0 steep.
A11
Downslope linear / non-linear 0 linear
A12
MMA/TIG method selection with remote control o /on 0 o
A13
Search arc o / on 1 on
A14
Possibility to current freezing during downslope o / on 0 o
A15
Control of channels with torch up-down switch o / on 0 o
A16
Control of current with torch up-down switch always active /
active only when selected with REMOTE button
0 always active
A17
Guard functions of cooling unit not activated / activated 1 activated
A18
Downslope for Minilog and 4T in MTM and MTL panels performed
during long switch action / after switch operation (normal)
0 normal
A19
Cooling unit operates on forced control / automatic on/o control 0 automatic
17
Master, MasterTig, MasterCool 10 / © Kemppi Oy / 1112
