Mastertig MLs™ 2300 aDCD / 0743 – 19© keMppi oy
SETUP-function Display
*C = Common: applies to all memory
channels
Factory setting with a grey background
Upslope current
dependency (*C)
A1 ON The upslope time is determined by the current.
OFF The upslope time remains as set.
Downslope current
dependency (*C)
A2 ON The downslope time is determined by the
current (the user may set the slope gradient).
OFF The downslope time remains as set.
TIG Antifreeze (*C)
A3 ON TIG Antifreeze on.
OFF TIG Antifreeze off.
MMA Antifreeze (*C)
A4 ON MMA Antifreeze on.
OFF MMA Antifreeze off.
VRD (*C)
A7 ON VRD mode: idle voltage < 35 V
OFF Normal idle voltage
2T downslope cut off A8 ON In 2T mode, cut off the downslope with a quick
push of the start button.
OFF Quick push has no effect.
Tacking automatics A9 ON If welding has lasted less than 3 seconds, no
downslope when welding is stopped.
OFF Tacking automatics off.
Limitation of rate of current
rise with high currents
A10 ON If the current is over 100 A and UpSlope is 0.0
sec., there is a 0.2-second slope from half the
welding current.
OFF Current rises directly to maximum.
MMA/TIG method selection
with remote control (C*)
A12 ON TIG = the start of remote control scale.
MMA = the end of the scale.
OFF Remote control as a normal current regulator.
SearchArc On/Off A13 ON SearchArc on.
OFF SearchArc off.
Current freeze function A14 ON During the downslope, the current can be
‘frozen’ at a certain level by pushing the start
button.
OFF Freeze function off.
Memory channel selection
with Up/Down buttons (C*)
A15 ON The Plus/Minus buttons on the remote control
can be used to select the memory channel.
OFF The buttons adjust the current.
Activation of the Plus/Minus
buttons (C*)
A16 ON The Plus/Minus remote control is always active.
OFF The Plus/Minus remote control is active only
when selected by pressing the REMOTE button.
Water cooler ow guard (C*) A17 ON Flow guard on.
OFF Flow guard off.
Water cooler automatic
control (C*)
A19 ON Automatic control on.
OFF Water cooler runs constantly.
Water cooler temperature
guard (C*)
A20 ON Water cooler temperature guard selected.
OFF Temperature guard off.
Automatic remote control
device recognition (C*)
A21 ON Automatic recocnition on, control cannot be
selected if it is not connected.
OFF Automatic recocnition On/Off. Controller can be
selected even if it is not connected.
Tail arc A22 ON* Tail arc on. * 4T LOG
OFF** Tail arc off. ** MINILOG
