Kemppi MasterTig 2200 Service Manual

X2 X3
X1
X10X11
R70
X17
X16
X15
X18
R48
R47
R98
R49
X8 X4
R47 Maximum current
R48 MMA ignition current
R49 Minimum current
R70 Inverter frequency
R98 Set value min. (TIG)
Closed
X15 MMA
Open
X15 Scratch-TIG
X16
X17
X18 OCV approx. + 80 V
X18 OCV approx.. + 40 V
Control card A001 layout (Master / Mastertig 1500)
R47 Maximum current
R48 MMA ignition current
R49 Minimum current
R70 Inverter frequency
R98 Set value min. (TIG)
Closed
X15 MMA
Open
X15 Scratch-TIG
X16 Net voltage 3∼ 400 V
X16 Net voltage 3∼ 460 V
X17 Net voltage 3∼ 460 V
X17 Net voltage 3∼ 400 V
X2 X3
X1
X12
X13
X10X11
R70
X17
X16
X15
X18
R48
R47
R98
R49
X8 X4X5
X14
X20
X18 OCV approx. + 80 V
X18 OCV approx. + 40 V
Control card A001 layout (Master / Mastertig 2000/2200)
