Kemppi MasterTig 2200 Service Manual

Mastertig 1500 and 2200
1 Main switch S001, dynamics adjustment and welding
current connections
2 Current adjustment potentiometer
3 Overheat protection signal lamp
4 Local / remote control selection
5 Remote controller connector
1
2
345
Pregas time
Pause current Postgas time
2T/4T-selection
Ignition method and process selection
Downslope timePulse frequencyContinous / pulse
welding selection,
pulse ratio
adjustment
Pulse panel
7

Kemppi MasterTig 2200 Specifications

General

Brand	Kemppi
Model	MasterTig 2200
Category	Welding System
Language	English
