3.2.2.1. Indicator lights
1. Power On
2. Thermal overload of power source
3. Wrong mains voltage, over or under-voltage
3.2.2.2. MMA welding panel MEL
1. Remote/local control switch
2. Welding current potentiometer
3. Contact TIG welding
4. MMA welding
5. Arc force
6. Hot start
7. Digital display and amperage/voltage switch
8. Welding current table
