Kemppi Minarc 150 User Manual

EN
Welding range
MMA 10 A/20,5 V - 140 A/25,6 V 10 A/20,5 V - 140 A/25,6 V
TIG 5 A/10 V - 150 A/16 V 5 A/10 V - 150 A/16 V
Welding current control stepless stepless
Open-circuit voltage 85 V, (VRD 30 V) 85 V
Idle power <10 W <10 W
Power factor 0,60 0,60
Eciency 80 % 80 %
Electrode sizes to be welded, diameter Ø 1,5-3,25 mm Ø 1,5-3,25 mm
External dimensions
length 320 mm 320 mm
width 123 mm 123 mm
height with handle 265 mm 265 mm
Weight without connection cable 4,0 kg 4,4 kg
Weight with connection cable 4,6 kg 5,2 kg
Temperature class B (130 °C) B (130 °C)
Operating temperature range -20...+40°C -20...+40°C
Storage temperature range -40...+60°C -40...+60°C
Degree of protection IP23S IP23S
EMC class A A
Norms EN/IEC 60974-1 EN/IEC 60974-1
EN/IEC 60974-10 EN/IEC 60974-10
The products meet conformity requirements for CE marking.
Minarc 120AU Minarc 150AU
Mains voltage 1 ~ phase 50/60 Hz 240 V + 10 % ... - 20 % 240 V + 10 % ... - 20 %
Rated power
ED MMA 50 % 110 A/5,5 kVA 35 % 140 A/7,5 kVA
ED MMA 100 % 80 A/3,9 kVA 100 % 100 A/5,1 kVA
ED TIG 50 % 120 A/3,5 kVA 35 % 150 A/5,0 kVA
ED TIG 100 % 80 A/2,2 kVA 100 % 110 A/3,3 kVA
Primary current
35 % ED I
1max
24 A 30
100 % ED I
1e
17 22
Connection cable H07RN-F, 3G1,5 (1,5 mm, 3 m) H07RN-F, 3G6 (2,5 mm, 2 m
Recommended fuse, slow 10 A 15 A
16
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

Kemppi Minarc 150 Specifications

General

Input Voltage	230 V
Protection Class	IP23S
Input Current	16 A
Welding Current Range	10 - 150 A
Weight	4.0 kg
Output Current	150 A
Electrode Size	1.5 - 3.25 mm
Power Supply	Single-phase
Welding Processes	MMA
