Kemppi Minarc 150 User Manual

EN
Welding range
MMA 10 A/20,5 V - 110 A/24,4 V 10 A/20,5 V - 140 A/25,6 V
TIG 5 A/10 V - 120 A/15 V 5 A/10 V - 150 A/16 V
Welding current control stepless stepless
Open-circuit voltage 30 V 30 V
Idle power <30 W <30 W
Power factor 0,60 0,60
Eciency 80 % 80 %
Electrode sizes to be welded, diameter Ø 1,5-2,5 mm Ø 1,5-3,25 mm
External dimensions length 320 mm 320 mm
width 123 mm 123 mm
height with handle 265 mm 265 mm
Weight without connection cable 4,0 kg 4,0 kg
Weight with connection cable 4,6 kg 4,6 kg
Temperature class B (130 °C) B (130 °C)
Operating temperature range -20...+40°C -20...+40°C
Storage temperature range -40...+60°C -40...+60°C
Degree of protection IP23S IP23S
EMC class A A
Norms
AS 1674.2 AS 1674.2
AS/NZS 3652 AS/NZS 3652
WTIA Tech note 22 WTIA Tech note 22
EN/IEC 60974-1 EN/IEC 60974-1
EN/IEC 60974-10 EN/IEC 60974-10
The products meet conformity requirements for CE marking.
17
Minarc 150, 151, 150 VRD, 120/150 AU / © Kemppi Oy / 0901

Kemppi Minarc 150 Specifications

General

Input Voltage	230 V
Protection Class	IP23S
Input Current	16 A
Welding Current Range	10 - 150 A
Weight	4.0 kg
Output Current	150 A
Electrode Size	1.5 - 3.25 mm
Power Supply	Single-phase
Welding Processes	MMA
