8. TECHNICAL DATA
MinarcTig Evo models
Connection voltage
1 ~ 50/60 Hz 230 V ±15 %
Connection voltage (AU)
1 ~ 50/60 Hz 240 V ±15 %
Rated power at max. current
35% ED TIG 200 A/4.9 kVA
35% ED MMA 170 A/5.7 kVA
Supply current, I1max
TIG 21.1 A
MMA 24.8 A
Supply current, I1eff
TIG 12.7 A
MMA 14.7 A
Connection cable
H07RN-F 3G1.5 (1.5 mm², 3 m)
Fuse
type C 16 A
Output 40 °C
TIG 35 % ED 200 A/18.0 V
100 % ED 140 A/15.6 V
MMA 35 % ED 170 A/26.8 V
100 % ED 110 A/24.4 V
Welding range
TIG 5 A/10.2 V–200 A/18.0 V
MMA 10 A/20.4 V–170 A/26.8 V
Open circuit voltage
average 95 V; VRD 30 V; AU VRD 12 V
Idle power
TIG 10 W
MMA 30 W
Power factor at 100 % ED
TIG 0.99
MMA 0.99
Efficiency at 100 % ED
TIG 77 %
MMA 83 %
Arc striking voltage
6–12 kV
MMA welding electrodes
MMA ø 1.5–4.0 mm
External dimensions (L × W × H)
449 × 210 × 358
Weight
11 kg
Temperature class
F (155 °C)
Degree of protection
IP23S
EMC class
A
Operating temperature range
-20 °C...+40 °C
Storage temperature range
-40 °C...+60 °C
Standards
IEC 60974-1
IEC 60974-3
IEC 60974-10
IEC 61000-3-12
17
© Kemppi Oy / 1201

Kemppi MinarcTig Evo 200 Specifications

General

Input Voltage	230 V
Protection Class	IP23
Power Factor	0.99
Welding Process	TIG, MMA
Duty Cycle TIG	35% at 200 A
Standards	IEC 60974-1, IEC 60974-10
