✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
A N Dest A N Dest
Ref.No. d e Parts No. Description inati Ref.No. d e Parts No. Description inati
dw on dw on
E 3C N09-4384-05 BINDING HEAD TAPTITE SCREW S1 -13 S70-0856-05 TACT SWITCH
F 2D N80-2008-45 PAN HEAD TAPTITE SCREW S14 -17 S70-0860-05 TACT SWITCH
G 1C N09-4381-05 MACHINE SCREW (M2X2) S18 -20 S70-0851-05 TACT SWITCH
J 2D N19-2062-04 FLAT WASHER S21 S70-0857-05 TACT SWITCH
K 2D N19-2022-04 FLAT WASHER S22 S68-0822-05 PUSH SWITCH
M 1D N09-4185-05 MACHINE SCREW (M2X2) S23 S70-0864-05 TACT SWITCH
N 2C N80-2004-46 PAN HEAD TAPTITE SCREW
Q 1D N09-4218-05 MACHINE SCREW (M2X3) D1 MA3091-M ZENER DIODE
R 1D N19-2058-04 FLAT WASHER IC1 LC75808W MOS-IC
S 1D N19-2103-04 FLAT WASHER IC2
✽
LC75878W MOS-IC M1
IC3 RS-171 ANALOGUE IC
T 2D N09-4340-05 MACHINE SCREW (M2X2.5) Q1 ,2 DTA114EK DIGITAL TRANSISTOR
X 2D N19-2147-04 FLAT WASHER
Q1 ,2 UN2111 DIGITAL TRANSISTOR
PS1 1D S68-0829-05 PUSH SWITCH Q3 ,4 2SD2114K TRANSISTOR
Q5 DTC114YK DIGITAL TRANSISTOR
PM1 1D T42-0752-34 MOTOR ASSY Q5 KRC107S TRANSISTOR
Q5 UN2214 DIGITAL TRANSISTOR
293 2C B11-0970-04 REFLECTION SHEET Q6 ,7 DTC114YK DIGITAL TRANSISTOR
294 2C
✽
B11-1301-04 OPTICAL DIFFUSER Q6 ,7 KRC107S TRANSISTOR
295 2C
✽
B19-2017-03 LIGHTING BOARD Q6 ,7 UN2214 DIGITAL TRANSISTOR
D2 -4 B30-1571-05 LED(WHITE) Q8 2SC2412K TRANSISTOR
D5 ,6 B30-1562-05 LED Q8 2SD601A TRANSISTOR
ED1 2C B38-1034-05 LIQUID CRYSTAL KK1M2
ED1 2C
✽
B38-1035-05 LIQUID CRYSTAL M1 300 2C
✽
B03-3056-12 DRESSING PLATE K
300 2C B03-3057-02 DRESSING PLATE K1M1M2
C1 CK73FB1H681K CHIP C 680PF K
C2 -6 CK73FB1C104K CHIP C 0.10UF K J1 E58-0895-05 RECTANGULAR RECEPTACLE
C7 CK73EB1C225K CHIP C 2.2UF K
C8 CK73FB1H681K CHIP C 680PF K M1 301 2C
✽
G16-1146-04 SHEET
C9 -12 CK73FB1C104K CHIP C 0.10UF K M1
302 2C
✽
J21-9540-04 MOUNTING HARDWARE ASSY
C13 -16 CK73FB1H103K CHIP C 0.010UF K KK1M2 FPC2 2C J84-0106-02
FLEXIBLE PRINTED WIRING BOARD
C13 -17 CK73FB1H103K CHIP C 0.010UF K M1
C19 CK73EB1C105K CHIP C 1.0UF K U 2C N38-2025-46 PAN HEAD MACHIN SCREW
296 2C E29-1596-04 CONDUCTIVE RUBBER
CN1 E59-0833-05 RECTANGULAR PLUG C1 ,2
✽
C92-0685-05 ELECTROLYTIC CAPACITOR
C3 C92-0092-05 CHIP C 47UF 6.3WV
CP1 R90-1016-05 MULTI-COMP 470 X4 C4 CK73FB1H103K CHIP C 0.010UF K
R1 RK73FB2A433J CHIP R 43KJ 1/10W C5 ,6 C90-2525-05 NP-ELECT 2.2UF 35WV
R2 -5 RK73FB2A222J CHIP R 2.2K J 1/10W C7 -10 CK73EB1C225K CHIP C 2.2UF K KM1
R6 RK73FB2A102J CHIP R 1.0K J 1/10W
R7 ,8 RK73FB2A223J CHIP R 22KJ 1/10W C11 -18 CK73FB1C274K CHIP C 0.27UF K KM1
C19 -22 CK73FB1C104K CHIP C 0.10UF K KM1
R9 RK73FB2A101J CHIP R 100J 1/10W C25 -30 C92-0671-05 ELECTRO 10UF 16WV M1
R10 RK73FB2A222J CHIP R 2.2K J 1/10W C27 -30 C92-0671-05 ELECTRO 10UF 16WV KK1M2
R11 RK73FB2A433J CHIP R 43K J 1/10W M1 C31 -34 C90-5297-05 NP-ELECT 0.22UF 50WV
R12 -15 RK73FB2A222J CHIP R 2.2K J 1/10W M1
R16 RK73EB2B331J CHIP R 330 J 1/8W C43 ,44 C90-2597-05 ELECTRO 10UF 16WV KM1
C47 C90-2597-05 ELECTRO 10UF 16WV KM1
R17 RK73EB2B391J CHIP R 390 J 1/8W C48 C90-2554-05 ELECTRO 10UF 16WV KM1
R18 -22 RK73EB2B331J CHIP R 330 J 1/8W C51 ,52 C90-2597-05 ELECTRO 10UF 16WV M1
R23 ,24 RK73FB2A103J CHIP R 10K J 1/10W C53 -56 CK73FB1H102K CHIP C 1000PF K KK1M2
R25 RK73EB2B331J CHIP R 330 J 1/8W
R26 RK73EB2B122J CHIP R 1.2K J 1/8W C53 -58 CK73FB1H102K CHIP C 1000PF K M1
C59 -61 CK73FB1H103K CHIP C 0.010UF K M1
R27 RK73FB2A751J CHIP R 750 J 1/10W C59 ,60 CK73FB1H103K CHIP C 0.010UF K KK1M2
R28 RK73EB2B122J CHIP R 1.2K J 1/8W C81 C90-2822-05 ELECTRO 3900UF 16WV M1
R29 RK73FB2A102J CHIP R 1.0K J 1/10W C81 C90-5242-05 ELECTRO 3300UF 16WV KK1M2
R30 RK73FB2A222J CHIP R 2.2K J 1/10W M1
R31 RK73FB2A223J CHIP R 22K J 1/10W C82 C90-2926-05 ELECTRO 220UF 16WV
E: Europe K: North America M: Other Areas
indicates safety critical components.
SWITCH UNIT (X13-9720-XX)
SUB-CIRCUIT UNIT (X13-9780-1X)
SYNTHESIZER UNIT (X14-6180-XX)
K : KRC-X858
K1 : KRC-708
M1 : KRC-PS988R
M2 : KRC-888
To Next Page
