✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
A N Dest A N Dest
Ref.No. d e Parts No. Description inati Ref.No. d e Parts No. Description inati
dw on dw on
D81 MA3047-M ZENER DIODE M1 Q36 DTA124EK DIGITAL TRANSISTOR
D82 DAN202K DIODE Q36 KRA103S TRANSISTOR
D82 MA152WK DIODE Q36 UN2112 DIGITAL TRANSISTOR
IC1 UPD784217GC103 MI-COM IC KK1M2 Q37 2SC2412K TRANSISTOR
IC1
✽
UPD784218GC105 MI-COM IC M1 Q37 2SD601A TRANSISTOR
IC2 TDA7400 ANALOGUE IC Q38 2SB1443 TRANSISTOR
IC3 M5237ML IC(VOLTAGE REGULATOR) Q39 DTA123JK DIGITAL TRANSISTOR
IC4 TDA7386 ANALOGUE IC Q40 DTC124EUA DIGITAL TRANSISTOR
IC5 TDA7401 ANALOGUE IC KM1 Q40 UN5212 DIGITAL TRANSISTOR
IC6 ICL7660SIBA ANALOGUE IC K Q41 DTC114YUA DIGITAL TRANSISTOR
IC6 TC7662BEOA ANALOGUE IC M1 Q41 UN5214 DIGITAL TRANSISTOR
IC7 -9 NJM4565M-TE2 ANALOGUE IC M1 Q42 2SB1443 TRANSISTOR
IC7 ,8 NJM4565M-TE2 ANALOGUE IC K Q43 DTC114YK DIGITAL TRANSISTOR
IC10 TC74HC02AF IC Q43 KRC107S TRANSISTOR
IC11 TDA7479D ANALOGUE IC KM1 Q43 UN2214 DIGITAL TRANSISTOR
IC12 NJM4565M-TE2 ANALOGUE IC M1 Q44 DTA124EUA DIGITAL TRANSISTOR
IC13 BA6238A ANALOGUE IC Q44 UN5112 DIGITAL TRANSISTOR
IC14 BR24C01AF MEMORY IC Q45 2SA1037K TRANSISTOR
IC14 M24C01-WMN6T MEMORY IC Q51 DTC114YK DIGITAL TRANSISTOR
IC15 S-80830ANNP MOS-IC Q51 KRC107S TRANSISTOR
Q1 -4 2SC2412K TRANSISTOR KK1M2 Q51 UN2214 DIGITAL TRANSISTOR
Q1 -4 2SD601A TRANSISTOR KK1M2 Q55 2SC2412K TRANSISTOR KM1
Q1 -6 2SC2412K TRANSISTOR M1 Q55 2SD601A TRANSISTOR KM1
Q1 -6 2SD601A TRANSISTOR M1 Q56 2SB1443 TRANSISTOR KM1
Q18 DTC144EK DIGITAL TRANSISTOR Q57 2SC2412K TRANSISTOR KM1
Q18 KRC104S TRANSISTOR Q57 2SD601A TRANSISTOR KM1
Q18 UN2213 DIGITAL TRANSISTOR Q58 ,59 2SA1037K TRANSISTOR KM1
Q19 DTA124EK DIGITAL TRANSISTOR Q60 ,61 2SC2412K TRANSISTOR KM1
Q19 KRA103S TRANSISTOR Q60 ,61 2SD601A TRANSISTOR KM1
Q19 UN2112 DIGITAL TRANSISTOR Q62 2SA1037K TRANSISTOR KM1
Q20 2SB1565F(E,F) TRANSISTOR Q71 DTA124EK DIGITAL TRANSISTOR
Q21 2SC2412K TRANSISTOR Q71 KRA103S TRANSISTOR
Q21 2SD601A TRANSISTOR Q71 UN2112 DIGITAL TRANSISTOR
Q22 2SB1565F(E,F) TRANSISTOR Q72 DTC124EK DIGITAL TRANSISTOR
Q23 2SA1037K TRANSISTOR Q72 KRC103S TRANSISTOR
Q24 ,25 2SC2412K TRANSISTOR Q72 UN2212 DIGITAL TRANSISTOR
Q24 ,25 2SD601A TRANSISTOR Q82 DTC124EK DIGITAL TRANSISTOR M1
Q26 2SB1277(Q,R) TRANSISTOR KK1M2 Q82 KRC103S TRANSISTOR M1
Q27 DTC114YK DIGITAL TRANSISTOR KK1M2 Q82 UN2212 DIGITAL TRANSISTOR M1
Q27 KRC107S TRANSISTOR KK1M2 Q86 ,87 DTC124EK DIGITAL TRANSISTOR
Q27 UN2214 DIGITAL TRANSISTOR KK1M2 Q86 ,87 KRC103S TRANSISTOR
Q28 2SB1277(Q,R) TRANSISTOR Q86 ,87 UN2212 DIGITAL TRANSISTOR
Q29 2SA1037K TRANSISTOR Q88 ,89 2SB1188(Q,R) TRANSISTOR
Q30 DTA124EK DIGITAL TRANSISTOR Q91 2SC4081 TRANSISTOR M1
Q30 KRA103S TRANSISTOR Q91 2SD1819A TRANSISTOR M1
Q30 UN2112 DIGITAL TRANSISTOR Q92 DTA124EUA DIGITAL TRANSISTOR M1
Q31 DTC114EK DIGITAL TRANSISTOR Q92 UN5112 DIGITAL TRANSISTOR M1
Q31 UN2211 DIGITAL TRANSISTOR Q93 DTC114TK DIGITAL TRANSISTOR M1
Q32 DTC144EK DIGITAL TRANSISTOR Q93 UN2215 DIGITAL TRANSISTOR M1
Q32 KRC104S TRANSISTOR TH1 PTH9C42BD471Q POSITIVE RESISTOR
Q32 UN2213 DIGITAL TRANSISTOR A1 X86-3100-10 TUNER UNIT KK1M2
Q33 2SD1760 TRANSISTOR A1 X86-3222-70 TUNER UNIT M1
Q35 DTC144EK DIGITAL TRANSISTOR
Q35 KRC104S TRANSISTOR
Q35 UN2213 DIGITAL TRANSISTOR C1 -4 CK73FB1H471K CHIP C 470PF K
E: Europe K: North America M: Other Areas
indicates safety critical components.
DOLBY NOISE REDUCTION UNIT (X87-301X-XX)
K : KRC-X858
K1 : KRC-708
M1 : KRC-PS988R
M2 : KRC-888
(X14-6180-XX)
