✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
A N Dest A N Dest
Ref.No. d e Parts No. Description inati Ref.No. d e Parts No. Description inati
dw on dw on
C5 CE04NW1A330M ELECTRO 33UF 10WV 12 2B D13-1497-08 GEAR(P)
C6 CE04NW1A470M ELECTRO 47UF 10WV 15 2B J21-9458-08
MOUNTING HARDWARE(HEAD P-AS)
C7 ,8 CK73FB1H103K CHIP C 0.010UF K 17 2B G02-1332-08 FLAT SPRING(HEAD SP-P)
C11 -14 CK73FB1C104K CHIP C 0.10UF K 20 2A D13-1498-08 RACK GEAR(OP PLATE A)
C15 ,16 CE04NW1A330M ELECTRO 33UF 10WV 21 1A D10-4377-08 LEVER(EJ-LEV-A)
C17 CK73EB1C474K CHIP C 0.47UF K 22 3B D10-4378-08 LEVER(SB.PL-AS)
C20 CK73GB1H562K CHIP C 5600PF K 23 2A D10-4379-08 LEVER(OP-PL-HO)
C21 ,22 CK73FB1E683K CHIP C 0.068UF K M1 24 1A D10-4380-08 LEVER(EJE-LEV-A)
C23 CK73FB1C224K CHIP C 0.22UF K 25 1A G01-2960-08 TENSION COIL SPRING(E LEV-SP
C24 CK73GB1C393K CHIP C 0.039UF K KK1M2 26 3A D13-1499-08 GEAR(FR)
C24 CK73GB1C473K CHIP C 0.047UF K M1 27 3A D10-4381-08 ARM(FR-PLATE)
C25 ,26 CC73GCH1H560J CHIP C 56PF J M1 30 2B D10-4382-08 ARM ASSY(PINCH ROLLER F)
31 2B D10-4383-08 ARM ASSY(PINCH ROLLER R)
CN1 E40-9702-05 FLAT CABLE CONNECTOR 33 1B G01-2961-08 TORSION SPRING(SA)
CN2 E40-9218-05 PIN ASSY 34 2B D10-4384-08 ARM(SW)
CN3 E40-9701-05 FLAT CABLE CONNECTOR
CN4 E40-9703-05 SOCKET FOR PIN ASSY 44 1A E39-0305-08
WIRE HARNESS(M CONNECTOR ASSY)
W1 -9 E31-0001-00 JUMPER WIRE 45 2A J11-0632-08 CLAMPER
48 3B D01-0613-08 FLYWHEEL ASSY
R1 -4 RK73FB2A243J CHIP R 24K J 1/10W 49 3B D16-0616-08 BELT
R5 ,6 RK73FB2A181J CHIP R 180 J 1/10W 52 1B D10-4385-08 ARM(CASSETTE LIFTER B)
R7 RK73GB1J203J CHIP R 20K J 1/16W
R8 RK73GB1J564J CHIP R 560K J 1/16W KK1M2 53 1B J19-4953-08 CASSETTE HOLDER
R8 RK73GB1J684J CHIP R 680K J 1/16W M1 54 1A G11-1861-08 CUSHION
56 1B D10-4386-08 ARM ASSY
R9 RK73GB1J302J CHIP R 3.0K J 1/16W M1 57 1B G01-2962-08 TENSION COIL SPRING
R9 RK73GB1J362J CHIP R 3.6K J 1/16W KK1M2 58 1B D10-4387-08 SLIDER
R10 RK73GB1J303J CHIP R 30K J 1/16W M1
R10 RK73GB1J333J CHIP R 33K J 1/16W KK1M2 65 2A B09-0522-08 REEL CAP
R11 ,12 RK73FB2A102J CHIP R 1.0K J 1/10W KK1M2 66 2A G01-2963-08 COMPRESSION SPRING
67 2A D03-0314-08 REEL GEAR ASSY
R11 ,12 RK73FB2A242J CHIP R 2.4K J 1/10W M1 75 3A J69-0510-08 ADHESIVE TAPE(FFC)
R13 RK73EB2B4R7J CHIP R 4.7 J 1/8W 90 3A J26-4036-08 PC BORD ASSY
R18 RK73EB2B121J CHIP R 120 J 1/8W
VR1 ,2 R12-3100-05 TRIMMING POT.(10K) 92 3A E39-0306-08 FLAT CABLE(FFCM4)
W11 ,12 R92-2052-05 CHIP R 0 J 1/10W 94 3A T95-0245-08 PHOTO COUPLER
A 3A N09-4324-08 SCREW(2X2.5)
W14 R92-2052-05 CHIP R 0 J 1/10W B 2A N19-2136-08 FLAT WASHER(1.55X35)
C 2A N09-4325-08 SCREW(2X13ADS)
S1 S40-1140-05 PUSH SWITCH
CM1 1A T42-1002-08 MOTOR ASSY(MAIN)
IC1 CXA2560Q ANALOGUE IC KK1M2 CM2 1A T42-1001-08 MOTOR ASSY(SUB A)
IC1 CXA2561Q ANALOGUE IC M1 D 2A N09-4326-08 SCREW(2X3)
Q1 DTC124EK DIGITAL TRANSISTOR E 2A N09-4058-08 SEMS(2X3AMS)
Q1 KRC103S TRANSISTOR F 2B N19-2038-08 FLAT WASHER(0.85X2.8)
Q1 UN2212 DIGITAL TRANSISTOR
G 2B N19-2136-08 FLAT WASHER(1.55X3)
H 2B N19-2137-08 FLAT WASHER(2.1X3.5)
ME1 3C
✽
D40-1138-15 CASSETTE MECHANISM ASSY HD1 2B T31-0226-08 PLAYBACK HEAD
J 3B N19-2138-08 FLAT WASHER(2.1X3.5)
V3C
✽
N09-4368-05 MACHINE SCREW K 3B N09-4327-08 SCREW
W3D
✽
N09-4377-05 TAPTITE SCREW (2X5)
N 1B N19-2139-08 FLAT WASHER(2.1X4.0)
1 2B A10-4630-08 CHASSIS ASSY
4 3B D10-4375-08 SLIDER(MAIN PLATE)
5 3A D13-1494-08 GEAR(B)
6 3A D13-1495-08 GEAR(C)
7 3A D13-1496-08 GEAR(D)
9 2B D10-4376-08 ARM(P-G PLATE)
10 2B J90-0948-08 GUID
11 2B D15-0919-08 PULLEY(MID)
E: Europe K: North America M: Other Areas
indicates safety critical components.
MECHANISM ASSY (X92-3790-XX)
CASSETTE MECHANISM ASSY (D40-1138-15)
K : KRC-X858
K1 : KRC-708
M1 : KRC-PS988R
M2 : KRC-888
To Next Page
