1-4 (No.RA094<Rev.002>)
TIA measurement compliant
Specifications are measured according to applicable standards. Specifications shown are typical.
JVCKENWOOD Corporation reserves the right to change specifications without prior notice or obligation.
*1 25 kHz in UHF Band excluding T-Band are not included in the models sold in the USA or US territories.
GENERAL
Frequency Range E 450 ~ 520 MHz
E2 400 ~ 470 MHz
Channel Capacity 32
Channel Spacing Analog 12.5 / 25 *1 kHz
Digital 6.25 / 12.5 kHz
PLL Channel Step 3.125 / 5 / 6.25 kHz
Frequency Stability ± 0.5 ppm
Power Supply 10.8 ~ 15.6 V DC
Current Drain Standby 0.7 A
Transmitting 12.0 A (Max. power), 9.0 A (25 W)
Operating Temperature -22 F to +140 F (-30 C to +60 C)
Antenna Impedance 50
Dimensions (W x H x D) Projections included 8.44 x 1.73 x 9.56 in (214.5 x 44.0 x 242.9 mm)
Projections not included 8.21 x 1.73 x 8.33 in (208.5 x 44.0 x 211.5 mm)
Weight (net) 4.18 lbs (1.9 kg)
RECEIVER
Sensitivity DMR (5 % BER) 0.22 V
DMR (1 % BER) 0.28 V
NXDN (3 % BER) 6.25 / 12.5 kHz 0.20 / 0.25 V
Analog (12 dB SINAD) 0.25 V
Selectivity Analog 12.5 / 25 kHz (TIA603) 74 / 80 dB
Analog 12.5 / 25 kHz (TIA603E) 50 / 80 dB
FM Hum & Noise Analog 12.5 / 25 kHz 50 / 55 dB
Intermodulation 80 dB
Spurious Rejection 90 dB
TRANSMITTER
RF Output Power 40 ~ 1 W (40 W @ 50% Duty, 25 W @ 100 % Duty)
Spurious Emission -80 dB
FM Hum & Noise Analog @ 12.5 / 25 kHz 50 / 55 dB
Audio Distortion 1 %
Emission Designator (TIA) 16K0F3E, 11K0F3E, 7K60FXD, 7K60F7D, 7K60FXE,
7K60F7E, 7K60FXW, 7K60F7W, 8K30F1E, 8K30F1D,
8K30F7W, 4K00F1E, 4K00F1D, 4K00F7W, 4K00F2D
