Kenwood NXR-710 User Manual

NXR-710
3
SYSTEM SET-UP
REALIGNMENT
1. Modes
User mode
PC mode
Firmware programming mode
PC programming mode
PC test mode
PC tuning mode
Mode Function
User mode Use this mode for normal operation.
PC mode
Use this mode to make various settings by
means of the FPU through the RS-232C
port.
PC programming
mode
Use to read and write frequency data and
other features to and from the repeater.
PC test mode
Use to check the repeater using the PC.
This feature is included in the FPU.
Firmware program-
ming mode
Use when changing the fi rmware program
of the fl ash memory.
2. How to Enter Each Mode
Mode Operation
User mode Power on.
PC mode Received commands from PC.
Firmware programming mode [PF1] + Power on (one second)
3. PC Mode
3-1. Preface
The NXR-710 is programmed by using a personal com-
puter, programming interface (KPG-46/46A) and program-
ming software (KPG-129D).
The programming software can be used with a PC. Fig-
ure 1 shows the setup of a PC for programming.
3-2. Connection Procedure
1. Connect the NXR-710 to the computer using the inter-
face cable and USB adapter (When the interface cable is
KPG-46A, the KCT-53U can be used.).
Note:
• You must install the KCT-53U driver in the computer to
use the USB adapter (KCT-53U).
• When using the USB adapter (KCT-53U) for the first time,
plug the KCT-53U into a USB port on the computer with
the computer power ON.
2. When power is applied, the user mode is entered im-
mediately. When the PC sends a command, the repeater
enters the PC mode and displays “PC” on the 7-seg-
ment LED. When data is being transmitted to the PC
from the repeater, the TX LED fl ashes. The BUSY LED
fl ashes when data from the PC is being received by the
repeater.
Note:
• The data stored in the personal computer must match
the model type, when it is written into the fl ash memory.
• Change the NXR-710 to PC mode, then attach the inter-
face cable.
Merchandise received
Choose the type of transceiver
See page 3.
A personal computer, programming interface (KPG-46/46A), and
programming software (KPG-129D) are required for programming.
DC power supply or
duplexer?
Repeater programming & setup
Installation in the optional space
YES
NO
Delivery
(Option)
Frequency range RF power Type
TX/RX 136~174MHz 50W K
External speaker?
KES-5 installation
YES
NO
(Option)
See page 6.
See page 6.

Kenwood NXR-710 Specifications

General

LED indicators	Yes
Channels quantity	30 channels
Reception range (VHF)	136 - 174 MHz
Number of programmable buttons	6
Display type	LED
Certification	IC, FCC
Operating temperature (T-T)	-30 - 60 °C
Input voltage	10.8 - 15.6 V
Power consumption (max)	50 W

Weight and Dimensions

Depth	340 mm
Width	483 mm
Height	88 mm
Weight	9700 g
