Kenwood NXR-800 Service Manual Supplement

NXR-800
26
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
RX UNIT (X55-3100-XX)
R53,54 RK73GB2A000J CHIP R 0.0 J 1/10W
R55 RK73FB2B271J CHIP R 270 J 1/8W
R56 RK73GB2A100J CHIP R 10 J 1/10W
R57 RK73GB2A470J CHIP R 47 J 1/10W K2
R60 RK73GB2A100J CHIP R 10 J 1/10W
R61 RK73GB2A470J CHIP R 47 J 1/10W
R62,63 RK73GB2A102J CHIP R 1.0K J 1/10W
R64 RK73GB2A000J CHIP R 0.0 J 1/10W
R65 RK73GB2A103J CHIP R 10K J 1/10W K2
R65 RK73GB2A822J CHIP R 8.2K J 1/10W K
R66,67 RK73FB2B331J CHIP R 330 J 1/8W
R68 RK73GB2A392J CHIP R 3.9K J 1/10W
R69-71 RK73GB2A102J CHIP R 1.0K J 1/10W
R72 RK73GB2A2R2J CHIP R 2.2 J 1/10W
R73 RK73GB2A104J CHIP R 100K J 1/10W
R75,76 RK73GB2A103J CHIP R 10K J 1/10W
R77,78 RK73FB2B151J CHIP R 150 J 1/8W K2
R77,78 RK73FB2B470J CHIP R 47 J 1/8W K
R79 RK73GB2A100J CHIP R 10 J 1/10W
R80 RK73GB2A271J CHIP R 270 J 1/10W
R81 RK73FB2B000J CHIP R 0.0 J 1/8W
R82 RK73GB2A102J CHIP R 1.0K J 1/10W
R83,84 RK73GB2A472J CHIP R 4.7K J 1/10W
R85 RK73GB2A333J CHIP R 33K J 1/10W
R86 RK73GB2A104J CHIP R 100K J 1/10W
R88 RK73GB2A103J CHIP R 10K J 1/10W
R89 RK73GB2A100J CHIP R 10 J 1/10W
R90 RK73GB2A330J CHIP R 33 J 1/10W
R91 RK73GB2A331J CHIP R 330 J 1/10W
R92 RK73GB2A104J CHIP R 100K J 1/10W
R93 RK73GB2A105J CHIP R 1.0M J 1/10W
R94 RK73GB2A332J CHIP R 3.3K J 1/10W
R95 RK73GB2A102J CHIP R 1.0K J 1/10W
R96 RK73GB2A100J CHIP R 10 J 1/10W
R97 RK73GB2A101J CHIP R 100 J 1/10W
R98,99 RK73GB2A331J CHIP R 330 J 1/10W
R100 RK73GB2A000J CHIP R 0.0 J 1/10W
R101 RK73FB2B100J CHIP R 10 J 1/8W
R102 RK73GB2A101J CHIP R 100 J 1/10W
R103 RK73GB2A472J CHIP R 4.7K J 1/10W
R104,105 RK73GB2A123J CHIP R 12K J 1/10W
R106 RK73GB2A105J CHIP R 1.0M J 1/10W
R107,108 RK73GB2A103J CHIP R 10K J 1/10W
R110 RK73GB2A222J CHIP R 2.2K J 1/10W
R112 RK73GB2A102J CHIP R 1.0K J 1/10W
R114 RK73GB2A102J CHIP R 1.0K J 1/10W
R115 RK73FB2B220J CHIP R 22 J 1/8W
R116 RK73GB2A101J CHIP R 100 J 1/10W
R117,118 RK73FB2B220J CHIP R 22 J 1/8W
R119,120 RK73GB2A103J CHIP R 10K J 1/10W
R122 RK73GB2A101J CHIP R 100 J 1/10W
R123 RK73GB2A153J CHIP R 15K J 1/10W
R124 RK73GB2A392J CHIP R 3.9K J 1/10W
R125 RK73GB2A102J CHIP R 1.0K J 1/10W
R128 RK73GB2A101J CHIP R 100 J 1/10W
R129 RK73GB2A102J CHIP R 1.0K J 1/10W
R130,131 RK73FB2B100J CHIP R 10 J 1/8W
R132 RK73GB2A102J CHIP R 1.0K J 1/10W
R133 RK73GB2A123J CHIP R 12K J 1/10W
R134 RK73GB2A104J CHIP R 100K J 1/10W
R135,136 RK73GB2A332J CHIP R 3.3K J 1/10W
R137 RK73GB2A101J CHIP R 100 J 1/10W
R138,139 RK73GB2A682J CHIP R 6.8K J 1/10W
R140,141 RK73GB2A181J CHIP R 180 J 1/10W
R142 RK73FB2B100J CHIP R 10 J 1/8W
R145 RK73GB2A100J CHIP R 10 J 1/10W
R146 RK73GB2A101J CHIP R 100 J 1/10W
R147 RK73GB2A271J CHIP R 270 J 1/10W
R149 RK73GB2A821J CHIP R 820 J 1/10W
R150 RK73FB2B101J CHIP R 100 J 1/8W
R151 RK73GB2A000J CHIP R 0.0 J 1/10W
R152 RK73GB2A102J CHIP R 1.0K J 1/10W
R153 RK73GB2A101J CHIP R 100 J 1/10W
R154 RK73GB2A000J CHIP R 0.0 J 1/10W
R155 RK73GB2A332J CHIP R 3.3K J 1/10W
R156 RK73GB2A680J CHIP R 68 J 1/10W
R157 RK73GB2A151J CHIP R 150 J 1/10W
R158 RK73GB2A101J CHIP R 100 J 1/10W
R159 RK73GB2A000J CHIP R 0.0 J 1/10W
R160 RK73GB2A3R3J CHIP R 3.3 J 1/10W
R161 RK73GB2A000J CHIP R 0.0 J 1/10W
R164 RK73GB2A104J CHIP R 100K J 1/10W
R165,166 RK73GB2A273J CHIP R 27K J 1/10W
R167 RK73GB2A000J CHIP R 0.0 J 1/10W
R169 RK73GB2A103J CHIP R 10K J 1/10W
R171 RK73GB2A103J CHIP R 10K J 1/10W
R172 RK73GB2A100J CHIP R 10 J 1/10W
R173 RK73GB2A271J CHIP R 270 J 1/10W
R174,175 RK73GB2A153J CHIP R 15K J 1/10W
R176 RK73GB2A100J CHIP R 10 J 1/10W
R177 RK73GB2A470J CHIP R 47 J 1/10W
R178,179 RK73GB2A103J CHIP R 10K J 1/10W
R180 RK73GB2A100J CHIP R 10 J 1/10W
R181 RK73GB2A102J CHIP R 1.0K J 1/10W
R183 RK73GB2A102J CHIP R 1.0K J 1/10W
R184 RK73GB2A000J CHIP R 0.0 J 1/10W
R185 RK73GB2A100J CHIP R 10 J 1/10W
R186,187 RK73GB2A104J CHIP R 100K J 1/10W
R189,190 RK73FB2B101J CHIP R 100 J 1/8W
R191,192 RK73FB2B271J CHIP R 270 J 1/8W
R193 RK73GB2A102J CHIP R 1.0K J 1/10W
R194 RK73GB2A472J CHIP R 4.7K J 1/10W
R195 RK73GB2A181J CHIP R 180 J 1/10W
R196,197 RK73FB2B100J CHIP R 10 J 1/8W
R198,199 RK73GB2A102J CHIP R 1.0K J 1/10W
R200 RK73GB2A682J CHIP R 6.8K J 1/10W
R201 RK73GB2A330J CHIP R 33 J 1/10W
R202 RK73GB2A2R2J CHIP R 2.2 J 1/10W
R203 RK73GB2A104J CHIP R 100K J 1/10W
R204 RK73GB2A332J CHIP R 3.3K J 1/10W
R205 RK73GB2A682J CHIP R 6.8K J 1/10W
R206 RK73GB2A152J CHIP R 1.5K J 1/10W
R207,208 RK73GB2A470J CHIP R 47 J 1/10W
R209 RK73GB2A101J CHIP R 100 J 1/10W
R210 RK73GB2A100J CHIP R 10 J 1/10W
R211 RK73GB2A104J CHIP R 100K J 1/10W
R212 RK73GB2A100J CHIP R 10 J 1/10W
R213,214 RK73GB2A563J CHIP R 56K J 1/10W
R215 RK73GB2A181J CHIP R 180 J 1/10W
R217 RK73GB2A104J CHIP R 100K J 1/10W
