Kenwood NXR-800 Service Manual Supplement

NXR-800
25
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
RX UNIT (X55-3100-XX)
L36 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L37 L41-1205-33 SMALL FIXED INDUCTOR (12UH)
L38 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L39 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L40,41 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH) K
L40,41 L41-1098-40 SMALL FIXED INDUCTOR (1000NH) K2
L42 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L43,44 L41-3395-33 SMALL FIXED INDUCTOR (3.3UH)
L45 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L46,47 L34-4749-05 COIL
L48 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L49 L41-2705-33 SMALL FIXED INDUCTOR (27UH)
L50 L41-2275-33 SMALL FIXED INDUCTOR (0.022UH)
L51 L92-0140-05 CHIP FERRITE
L52,53 L34-4749-05 COIL
L54 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L55 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L56 L41-8295-33 SMALL FIXED INDUCTOR (8.2UH)
L57 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L58,59 L41-1885-33 SMALL FIXED INDUCTOR (0.18UH)
L60,61 L41-2275-33 SMALL FIXED INDUCTOR (0.022UH)
L62 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L66,67 L41-8275-33 SMALL FIXED INDUCTOR (0.082UH)
L68 L41-8295-33 SMALL FIXED INDUCTOR (8.2UH)
L69 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L70 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L71 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L72 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L73 L41-2285-33 SMALL FIXED INDUCTOR (0.22UH)
L74,75 L34-4748-05 COIL
L76 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L77 L92-0140-05 CHIP FERRITE
L78 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L79 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L80 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L81 L41-8285-33 SMALL FIXED INDUCTOR (0.82UH)
L82 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L83 L41-6895-33 SMALL FIXED INDUCTOR (6.8UH)
L86 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L87 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L88 L41-8295-33 SMALL FIXED INDUCTOR (8.2UH)
L89 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L90,91 L34-4748-05 COIL
L92 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L93 L41-1085-33 SMALL FIXED INDUCTOR (0.1UH)
L94,95 L39-1476-05 TOROIDAL COIL
L96 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L97 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L98,99 L41-1895-33 SMALL FIXED INDUCTOR (1.8UH)
L100 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L101 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L102 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L103 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L106 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L107 L41-6895-33 SMALL FIXED INDUCTOR (6.8UH)
L108,109 L41-4775-33 SMALL FIXED INDUCTOR (0.047UH)
L110 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L111 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH9
L112,113 L39-1476-05 TOROIDAL COIL
L114 L41-6875-33 SMALL FIXED INDUCTOR (0.068UH)
L115 L41-8275-33 SMALL FIXED INDUCTOR (0.082UH)
L116,117 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L118 L41-6875-33 SMALL FIXED INDUCTOR (0.068UH)
L119 L41-2285-33 SMALL FIXED INDUCTOR (0.22UH)
L120 L41-8295-33 SMALL FIXED INDUCTOR (8.2UH)
L121 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L122 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L123 L41-3395-33 SMALL FIXED INDUCTOR (3.3UH)
L124-126 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH)
L127 L41-8295-33 SMALL FIXED INDUCTOR (8.2UH)
L128 L34-4725-05 COIL
L129,130 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L131 L41-1585-33 SMALL FIXED INDUCTOR (0.15UH) K
L131 L41-5685-33 SMALL FIXED INDUCTOR (0.56UH) K2
L132-135 L79-1849-05 HELICAL BLOCK K
L132-135 L79-1852-05 HELICAL BLOCK K2
L136,137 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
XF1 L71-0646-15 MCF (49.95MHZ WIDE)
XF2 L71-0645-15 MCF (49.95MHZ NARROW)
XF3 L71-0648-05 MCF (49.95MHZ WIDE)
XF4 L71-0647-05 MCF (49.95MHZ NARROW)
R1 RK73GB2A332J CHIP R 3.3K J 1/10W
R2 RK73GB2A182J CHIP R 1.8K J 1/10W
R4 RK73FB2B121J CHIP R 120 J 1/8W
R8 RK73GB2A100J CHIP R 10 J 1/10W K
R8 RK73GB2A4R7J CHIP R 4.7 J 1/10W K2
R9 RK73GB2A332J CHIP R 3.3K J 1/10W
R10 RK73GB2A103J CHIP R 10K J 1/10W
R11 RK73GB2A681J CHIP R 680 J 1/10W
R12 RK73GB2A102J CHIP R 1.0K J 1/10W
R13 RK73GB2A682J CHIP R 6.8K J 1/10W
R14 RK73FB2B100J CHIP R 10 J 1/8W
R15,16 RK73GB2A000J CHIP R 0.0 J 1/10W
R17 RK73GB2A181J CHIP R 180 J 1/10W
R19,20 RK73GB2A104J CHIP R 100K J 1/10W
R21 RK73GB2A684J CHIP R 680K J 1/10W
R22 RK73GB2A474J CHIP R 470K J 1/10W
R23 RK73GB2A000J CHIP R 0.0 J 1/10W
R24 RK73GB2A100J CHIP R 10 J 1/10W
R26,27 RK73GB2A000J CHIP R 0.0 J 1/10W
R28 RK73GB2A100J CHIP R 10 J 1/10W
R29 RK73GB2A152J CHIP R 1.5K J 1/10W
R30 RK73GB2A684J CHIP R 680K J 1/10W
R31 RK73GB2A271J CHIP R 270 J 1/10W K
R31 RK73GB2A471J CHIP R 470 J 1/10W K2
R32 RK73GB2A104J CHIP R 100K J 1/10W
R33 RK73GB2A102J CHIP R 1.0K J 1/10W
R34 RK73GB2A471J CHIP R 470 J 1/10W
R36 RK73GB2A103J CHIP R 10K J 1/10W
R37 RK73GB2A123J CHIP R 12K J 1/10W
R38 RK73GB2A101J CHIP R 100 J 1/10W
R39 RK73GB2A000J CHIP R 0.0 J 1/10W
R40 RK73GB2A102J CHIP R 1.0K J 1/10W
R42-44 RK73GB2A000J CHIP R 0.0 J 1/10W
R45 RK73GB2A471J CHIP R 470 J 1/10W
R46 RK73GB2A330J CHIP R 33 J 1/10W
R48 RK73FB2B271J CHIP R 270 J 1/8W
R50 RK73FB2B180J CHIP R 18 J 1/8W
R52 RK73GB2A100J CHIP R 10 J 1/10W
