Kenwood NXR-800 Service Manual Supplement

NXR-800
24
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
RX UNIT (X55-3100-XX)
C507 CK73GB1H104K CHIP C 0.10UF K
C508 CK73FB0J106K CHIP C 10UF K
C509 CC73GCH1H101J CHIP C 100PF J
C510 CK73GB1H104K CHIP C 0.10UF K
C516 CK73GB1H473K CHIP C 0.047UF K
C517 CK73FB0J106K CHIP C 10UF K
C518 CK73GB1H104K CHIP C 0.10UF K
C519 CC73GCH1H471J CHIP C 470PF J
C520 CK73GB1H103K CHIP C 0.010UF K
C521 CK73GB1H104K CHIP C 0.10UF K
C522 CK73GB1H103K CHIP C 0.010UF K
C523 CK73GB1H104K CHIP C 0.10UF K
C524 CK73FB1H333K CHIP C 0.033UF K
C527 CK73GB1H104K CHIP C 0.10UF K
C532 CK73GB1H104K CHIP C 0.10UF K
C533-536 CE32CL1V100M CHIP EL 10UF 35WV
C537-540 CC73GCH1H471J CHIP C 470PF J
C541,542 CK73GB1H104K CHIP C 0.10UF K
C543 CK73GB1H473K CHIP C 0.047UF K
C544 CC73GCH1H470J CHIP C 47PF J
C545-548 CC73GCH1H471J CHIP C 470PF J
C549 CC73GCH1H470J CHIP C 47PF J
C550-553 CK73GB1H103K CHIP C 0.010UF K
C554 CK73GB1H473K CHIP C 0.047UF K
C555 CE32BM1V220M CHIP EL 22UF 35WV
C556 CC73GCH1H471J CHIP C 470PF J
C557 CK73GB1H473K CHIP C 0.047UF K
C558 CC73GCH1H471J CHIP C 470PF J
C559 CK73GB1H104K CHIP C 0.10UF K
C560,561 CC73GCH1H471J CHIP C 470PF J
C562 CK73GB1H473K CHIP C 0.047UF K
C563 CC73GCH1H471J CHIP C 470PF J
C564 CK73GB1H103K CHIP C 0.010UF K
C565 CC73GCH1H471J CHIP C 470PF J
C566 CK73GB1H473K CHIP C 0.047UF K
C567 CE32CL1V100M CHIP EL 10UF 35WV
C568 CC73GCH1H470J CHIP C 47PF J
C569 CC73GCH1H471J CHIP C 470PF J
C570 CC73GCH1H470J CHIP C 47PF J
C571 C92-0904-05 OS-CON 22UF 35WV
C572,573 CK73GB1H103K CHIP C 0.010UF K
C574-576 CK73GB1H104K CHIP C 0.10UF K
C577 CK73GB1H103K CHIP C 0.010UF K
C578 CC73GCH1H151J CHIP C 150PF J
C579 CC73GCH1H560J CHIP C 56PF J
C580-582 CK73GB1H103K CHIP C 0.010UF K
C583 CK73GB1H102K CHIP C 1000PF K
C584 CK73GB1H103K CHIP C 0.010UF K
C585 CC73GCH1H470J CHIP C 47PF J
C586 CC73GCH1H471J CHIP C 470PF J
C587-590 CK73FB1E474K CHIP C 0.47UF K
C591 CK73GB1H102K CHIP C 1000PF K
C618 CC73GCH1H101J CHIP C 100PF J
C619 CK73GB1H104K CHIP C 0.10UF K
C620 CK73GB1H102K CHIP C 1000PF K
C621,622 CK73GB1H104K CHIP C 0.10UF K
C624 CC73GCH1H101J CHIP C 100PF J
C625 CE32BM1E470M CHIP EL 47UF 25WV
C626 CS77BA1E010M CHIP TNTL 1.0UF 25WV
C628 CK73GB1H104K CHIP C 0.10UF K
C629 CC73GCH1H471J CHIP C 470PF J K2
C630 CK73GB1H104K CHIP C 0.10UF K
C652 CK73GB1H104K CHIP C 0.10UF K
C655 CK73FB0J106K CHIP C 10UF K
C657 CC73GCH1H270J CHIP C 27PF J
C658 CK73FB1E474K CHIP C 0.47UF K
C659 CC73GCH1H101J CHIP C 100PF J
C660 CC73GCH1H050C CHIP C 5.0PF C
C661 CK73GB1H104K CHIP C 0.10UF K
C671 CK73GB1H104K CHIP C 0.10UF K
C673-675 CE32AU1C330M CHIP EL 33UF 16WV K2
C677 CK73GB1H104K CHIP C 0.10UF K
CN1-4 E23-1280-05 TERMINAL
CN5 E04-0460-05 RF COAXIAL RECEPTACLE (SMB)
CN6 E41-2735-05 PIN ASSY
CN8-35 E23-1280-05 TERMINAL
CN36 E41-2735-05 PIN ASSY
CN38,39 E23-1280-05 TERMINAL
CN41 E04-0154-05 PIN SOCKET
CN42 E40-6656-05 PIN ASSY
CN43 E04-0193-05 PIN SOCKET
CN44 E41-2672-05 PIN ASSY
CN45 E04-0193-05 PIN SOCKET
CN46,47 E41-2735-05 PIN ASSY
CN61,62 E23-1280-05 TERMINAL
E1 F10-2379-04 SHIELDING CASE
E2 F10-2409-04 SHIELDING CASE
E3 F10-3080-04 SHIELDING CASE
CF1 L72-1019-05 CERAMIC FILTER
CF2
✽
L72-1028-05 CERAMIC FILTER
CF3,4
✽
L72-1027-05 CERAMIC FILTER
CF5,6
✽
L72-1028-05 CERAMIC FILTER
CF7
✽
L72-1027-05 CERAMIC FILTER
L2 L34-4616-05 AIR-CORE COIL
L5 L34-4604-05 AIR-CORE COIL
L8,9 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH)
L10 L41-6885-33 SMALL FIXED INDUCTOR (0.68UH)
L11 L41-1295-33 SMALL FIXED INDUCTOR (1.2UH)
L12 L34-4605-05 AIR-CORE COIL
L13 L41-1295-33 SMALL FIXED INDUCTOR (1.2UH)
L14 L41-1805-33 SMALL FIXED INDUCTOR (18UH)
L16 L41-2705-33 SMALL FIXED INDUCTOR (27UH)
L17,18 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH) K
L17,18 L41-1098-40 SMALL FIXED INDUCTOR (1000NH) K2
L20 L41-1295-33 SMALL FIXED INDUCTOR (1.2UH)
L21,22 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH) K
L21,22 L41-1098-40 SMALL FIXED INDUCTOR (1000NH) K2
L23 L41-1295-33 SMALL FIXED INDUCTOR (1.2UH)
L26 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L27 L41-1098-40 SMALL FIXED INDUCTOR (1000NH)
L28 L34-4524-05 AIR-CORE COIL
L29 L41-1098-40 SMALL FIXED INDUCTOR (1000NH)
L30 L34-4524-05 AIR-CORE COIL
L31 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH)
L32 L41-8275-33 SMALL FIXED INDUCTOR (0.082UH)
L33 L41-2785-33 SMALL FIXED INDUCTOR (0.27UH)
L34 L41-1205-33 SMALL FIXED INDUCTOR (12UH)
L35 L41-3395-33 SMALL FIXED INDUCTOR (3.3UH)
