NXR-800

PARTS LIST

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

RX UNIT (X55-3100-XX)

C326 CC73GCH1H151J CHIP C 150PF J

C327 CK73GB1H102K CHIP C 1000PF K

C329 CK73GB1H103K CHIP C 0.010UF K

C330 CK73GB1H102K CHIP C 1000PF K

C331 CC73GCH1H020B CHIP C 2.0PF B

C332 CK73GB1H104K CHIP C 0.10UF K

C333 CC73GCH1H151J CHIP C 150PF J

C334,335 CK73GB1H103K CHIP C 0.010UF K

C336 CC73GCH1H471J CHIP C 470PF J

C337 CC73GCH1H560J CHIP C 56PF J

C340

✽

CS77CC1C330M CHIP TNTL 33UF 16WV

C341,342 CK73GB1H473K CHIP C 0.047UF K

C343 CC73GCH1H220J CHIP C 22PF J

C347,348 CK73GB1H103K CHIP C 0.010UF K

C349 CC73GCH1H121J CHIP C 120PF J K

C349 CC73GCH1H680J CHIP C 68PF J K2

C350

✽

CS77CC1C330M CHIP TNTL 33UF 16WV

C351 CK73GB1H102K CHIP C 1000PF K

C352 CK73GB1H473K CHIP C 0.047UF K

C353 CK73GB1H102K CHIP C 1000PF K

C355 CK73GB1H103K CHIP C 0.010UF K

C356 CK73GB1H473K CHIP C 0.047UF K

C357 CK73GB1H103K CHIP C 0.010UF K

C358 CK73GB1H473K CHIP C 0.047UF K

C359,360 CC73GCH1H471J CHIP C 470PF J

C361 CK73GB1H102K CHIP C 1000PF K

C362 CC73GCH1H270J CHIP C 27PF J

C363 CK73GB1H473K CHIP C 0.047UF K

C365,366 CK73GB1H104K CHIP C 0.10UF K

C367 CC73GCH1H560J CHIP C 56PF J K

C367,368 CC73GCH1H330J CHIP C 33PF J K2

C368 CC73GCH1H330J CHIP C 33PF J K

C369,370 CK73FB1E474K CHIP C 0.47UF K

C371 CK73GB1H102K CHIP C 1000PF K

C372 CK73GB1H473K CHIP C 0.047UF K

C373 CK73GB1H103K CHIP C 0.010UF K

C375 CK73GB1H103K CHIP C 0.010UF K

C377 CK73GB1H103K CHIP C 0.010UF K

C379 CC73GCH1H121J CHIP C 120PF J

C380 CC73GCH1H560J CHIP C 56PF J

C381 CE32BM1E470M CHIP EL 47UF 25WV

C382,383 CK73GB1H104K CHIP C 0.10UF K

C385,386 CK73GB1H104K CHIP C 0.10UF K

C387 CC73GCH1H270J CHIP C 27PF J

C388 CC73GCH1H820J CHIP C 82PF J

C389 CK73GB1H473K CHIP C 0.047UF K

C390 CK73GB1H104K CHIP C 0.10UF K

C391,392 CK73GB1H103K CHIP C 0.010UF K

C394,395 CK73GB1H102K CHIP C 1000PF K

C396-398 CK73GB1H104K CHIP C 0.10UF K

C400 CC73GCH1H220J CHIP C 22PF J

C401 CK73GB1H473K CHIP C 0.047UF K

C402 CC73GCH1H560J CHIP C 56PF J

C403 CK73GB1H104K CHIP C 0.10UF K

C405 CK73GB1H102K CHIP C 1000PF K

C406 CK73GB1H103K CHIP C 0.010UF K

C407 CC73GCH1H560J CHIP C 56PF J

C408 CC73GCH1H220J CHIP C 22PF J

C409 CK73GB1H102K CHIP C 1000PF K

C410 CK73GB1H104K CHIP C 0.10UF K

C411 CC73GCH1H121J CHIP C 120PF J

C412 CK73GB1H104K CHIP C 0.10UF K

C413 CK73GB1H103K CHIP C 0.010UF K

C414 CK73GB1H104K CHIP C 0.10UF K

C415,416 CK73GB1H103K CHIP C 0.010UF K

C417 CK73GB1H104K CHIP C 0.10UF K

C418,419 CK73GB1H103K CHIP C 0.010UF K

C420 CK73GB1H102K CHIP C 1000PF K

C421,422 CK73GB1H473K CHIP C 0.047UF K

C423,424 CK73GB1H103K CHIP C 0.010UF K

C425 CK73GB1H104K CHIP C 0.10UF K

C427 CK73FB1E474K CHIP C 0.47UF K

C428,429 CC73GCH1H560J CHIP C 56PF J

C430 CK73GB1H102K CHIP C 1000PF K

C431 CK73GB1H473K CHIP C 0.047UF K

C432 CK73GB1H102K CHIP C 1000PF K

C434,435 CK73GB1H473K CHIP C 0.047UF K

C437 CK73GB1H102K CHIP C 1000PF K

C438 CK73GB1H473K CHIP C 0.047UF K

C439 CK73GB1H104K CHIP C 0.10UF K

C440-442 CK73FB1E474K CHIP C 0.47UF K

C443,444 CK73GB1H473K CHIP C 0.047UF K

C446 CE32AU1E100M CHIP EL 10UF 25WV

C447 CK73FB1E474K CHIP C 0.47UF K

C448 CK73GB1H104K CHIP C 0.10UF K

C449 CK73GB1H473K CHIP C 0.047UF K

C450,451 CK73FB1E474K CHIP C 0.47UF K

C452,453 CK73GB1H104K CHIP C 0.10UF K

C454,455 CK73FB1E474K CHIP C 0.47UF K

C456 CK73GB1H473K CHIP C 0.047UF K

C458 CK73GB1H104K CHIP C 0.10UF K

C459 CC73GCH1H221J CHIP C 220PF J

C460 CK73FB1E474K CHIP C 0.47UF K

C461 CC73GCH1H221J CHIP C 220PF J

C462 CK73GB1H104K CHIP C 0.10UF K

C463-465 CK73FB1E474K CHIP C 0.47UF K

C466 CK73GB1H473K CHIP C 0.047UF K

C467 CK73GB1H102K CHIP C 1000PF K

C468 CK73GB1H104K CHIP C 0.10UF K

C469 CK73GB1H473K CHIP C 0.047UF K

C470 CC73GCH1H471J CHIP C 470PF J

C471,472 CK73GB1H104K CHIP C 0.10UF K

C473 CC73GCH1H270J CHIP C 27PF J

C474 CK73FB1E474K CHIP C 0.47UF K

C476 CE32AU1E100M CHIP EL 10UF 25WV

C477 CK73GB1H104K CHIP C 0.10UF K

C478 CK73FB1E474K CHIP C 0.47UF K

C480-482 CE32CL1V100M CHIP EL 10UF 35WV

C484-488 CC73GCH1H471J CHIP C 470PF J

C489 CK73GB1H102K CHIP C 1000PF K

C491 CK73GB1H104K CHIP C 0.10UF K

C492 C93-0912-05 CHIP C 100UF M

C493 CK73GB1H473K CHIP C 0.047UF K

C494 CK73FB0J106K CHIP C 10UF K

C495 CK73GB1H104K CHIP C 0.10UF K

C498 CC73GCH1H470J CHIP C 47PF J

C499 CK73FB0J106K CHIP C 10UF K

C500-504 CC73GCH1H471J CHIP C 470PF J

C505 CK73FB0J106K CHIP C 10UF K

C506 CK73GB1H102K CHIP C 1000PF K
