Kenwood NXR-800 Service Manual Supplement

NXR-800
22
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
RX UNIT (X55-3100-XX)
C147
✽
CS77CC1C330M CHIP TNTL 33UF 16WV
C149,150 CC73GCH1H180J CHIP C 18PF J
C151 CC73GCH1H070D CHIP C 7.0PF D
C154,155 CK73GB1H104K CHIP C 0.10UF K
C156 CC73GCH1H100C CHIP C 10PF C
C157,158 CC73GCH1H471J CHIP C 470PF J
C159,160 CK73GB1H104K CHIP C 0.10UF K
C161 CC73GCH1H030C CHIP C 3.0PF C
C162 CC73GCH1H060D CHIP C 6.0PF D
C163 CC73GCH1H020B CHIP C 2.0PF B
C164 CK73GB1H104K CHIP C 0.10UF K
C165 CS77CB21C100M CHIP TNTL 10UF 16WV
C166,167 CC73GCH1H180J CHIP C 18PF J
C168 CC73GCH1H471J CHIP C 470PF J
C169 CC73GCH1H150J CHIP C 15PF J
C170,171 CK73GB1H104K CHIP C 0.10UF K
C172 CK73GB1H473K CHIP C 0.047UF K
C173,174 CK73GB1H103K CHIP C 0.010UF K
C175 CC73GCH1H101J CHIP C 100PF J
C176 CK73GB1H104K CHIP C 0.10UF K
C177-179 CC73GCH1H471J CHIP C 470PF J
C180 CK73GB1H104K CHIP C 0.10UF K
C183 CE32AU1E100M CHIP EL 10UF 25WV
C185,186 CC73GCH1H471J CHIP C 470PF J
C187 CC73GCH1H220J CHIP C 22PF J
C188 CK73GB1H103K CHIP C 0.010UF K
C192 CC73GCH1H471J CHIP C 470PF J
C193 CK73GB1H104K CHIP C 0.10UF K
C194 CC73GCH1H080D CHIP C 8.0PF D
C195 CC73GCH1H471J CHIP C 470PF J
C196,197 CK73GB1H103K CHIP C 0.010UF K
C198 CC73GCH1H471J CHIP C 470PF J
C199 CK73GB1H103K CHIP C 0.010UF K
C203 CC73GCH1H471J CHIP C 470PF J K2
C203-205 CC73GCH1H471J CHIP C 470PF J K
C206 CC73GCH1H100C CHIP C 10PF C
C211,212 CK73GB1H103K CHIP C 0.010UF K
C213 CK73GB1H473K CHIP C 0.047UF K
C214 CC73GCH1H040C CHIP C 4.0PF C
C215 CK73GB1H103K CHIP C 0.010UF K
C216 CK73GB1H473K CHIP C 0.047UF K
C217 CK73GB1H104K CHIP C 0.10UF K
C218 CK73GB1H473K CHIP C 0.047UF K
C220 CC73GCH1H040C CHIP C 4.0PF C
C221,222 CK73GB1H104K CHIP C 0.10UF K
C223 CK73GB1H103K CHIP C 0.010UF K
C224 CK73GB1H104K CHIP C 0.10UF K
C225 CK73GB1H473K CHIP C 0.047UF K
C227 CC73GCH1H471J CHIP C 470PF J
C228,229 CK73FB1E474K CHIP C 0.47UF K
C230 CC73GCH1H820J CHIP C 82PF J
C231 CK73GB1H473K CHIP C 0.047UF K
C232 CC73GCH1H470J CHIP C 47PF J
C233 CK73GB1H473K CHIP C 0.047UF K
C234,235 CC73GCH1H270J CHIP C 27PF J
C236 CK73GB1H104K CHIP C 0.10UF K
C237 CK73GB1H102K CHIP C 1000PF K
C238 CC73GCH1H090D CHIP C 9.0PF D
C239 CE32AU1C330M CHIP EL 33UF 16WV
C240 CS77CB21C100M CHIP TNTL 10UF 16WV
C241,242 CC73GCH1H150J CHIP C 15PF J
C243 CC73GCH1H820J CHIP C 82PF J
C244 CC73GCH1H100D CHIP C 10PF D
C245 CK73GB1H102K CHIP C 1000PF K
C248 CC73GCH1H471J CHIP C 470PF J
C249 CC73GCH1H070D CHIP C 7.0PF D
C250,251 CK73GB1H104K CHIP C 0.10UF K
C252 CC73GCH1H151J CHIP C 150PF J
C253 CC73GCH1H010C CHIP C 1.0PF C
C254 CC73GCH1H030C CHIP C 3.0PF C
C255 CK73GB1H104K CHIP C 0.10UF K
C256 CK73GB1H102K CHIP C 1000PF K
C257 CK73GB1H103K CHIP C 0.010UF K
C258 CK73GB1H473K CHIP C 0.047UF K
C260 CC73GCH1H471J CHIP C 470PF J
C261 CK73GB1H103K CHIP C 0.010UF K
C262,263 CK73GB1H102K CHIP C 1000PF K
C264 CS77CA1ER47M CHIP TNTL 0.47UF 25WV
C265 CC73GCH1H470J CHIP C 47PF J
C266,267 CC73GCH1H471J CHIP C 470PF J
C268,269 CK73GB1H473K CHIP C 0.047UF K
C270
✽
CS77CA1DR68M CHIP TNTL 0.68UF 20WV
C271 CC73GCH1H471J CHIP C 470PF J
C272 CK73GB1H104K CHIP C 0.10UF K
C273 CC73GCH1H220J CHIP C 22PF J
C274 CK73GB1H473K CHIP C 0.047UF K
C277 CK73GB1H102K CHIP C 1000PF K
C278 CC73GCH1H151J CHIP C 150PF J
C279 CK73GB1H473K CHIP C 0.047UF K
C280 CC73GCH1H080B CHIP C 8.0PF B
C281 CC73GCH1H030B CHIP C 3.0PF B
C282
✽
CS77CB21C150M CHIP TNTL 15UF 16WV
C284 CK73GB1H473K CHIP C 0.047UF K
C285 CC73GCH1H471J CHIP C 470PF J
C287 CC73GCH1H390J CHIP C 39PF J
C288,289 CC73GCH1H150J CHIP C 15PF J
C290,291 CK73GB1H473K CHIP C 0.047UF K
C292 CE32CL1V100M CHIP EL 10UF 35WV
C293 CC73GCH1H151J CHIP C 150PF J
C295 CK73GB1H102K CHIP C 1000PF K
C296
✽
CS77CA1DR68M CHIP TNTL 0.68UF 20WV
C297 CC73GCH1H151J CHIP C 150PF J
C298 CK73GB1H102K CHIP C 1000PF K
C300 CC73GCH1H220G CHIP C 22PF G
C301 CK73GB1H473K CHIP C 0.047UF K
C302 CC73GCH1H100D CHIP C 10PF D
C303,304 CK73GB1H473K CHIP C 0.047UF K
C305 CC73GCH1H151J CHIP C 150PF J
C306 CK73GB1H102K CHIP C 1000PF K
C307,308 CK73GB1H103K CHIP C 0.010UF K
C309 CC73GCH1H471J CHIP C 470PF J
C310 CK73GB1H102K CHIP C 1000PF K
C314 CK73GB1H104K CHIP C 0.10UF K
C315 CC73GCH1H270G CHIP C 27PF G
C316 CK73GB1H473K CHIP C 0.047UF K
C317 CC73GCH1H151J CHIP C 150PF J
C318,319 CK73GB1H103K CHIP C 0.010UF K
C320 CE32BM1E470M CHIP EL 47UF 25WV
C324 CC73GCH1H471J CHIP C 470PF J
C325 CC73GCH1H270G CHIP C 27PF G
