Kenwood NXR-800 Service Manual Supplement

NXR-800
21
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4140-11)
RX UNIT (X55-3100-XX)
Q300 2SC4738(GR)F TRANSISTOR
Q301 DTC114EUA DIGITAL TRANSISTOR
Q302 2SA1955A-F TRANSISTOR
Q303 DTA144EUA DIGITAL TRANSISTOR
Q304,305 2SC4738(GR)F TRANSISTOR
Q307,308 2SC4738(GR)F TRANSISTOR
Q309 SSM6N16FE-F FET
Q700 2SC4738(GR)F TRANSISTOR
Q702 2SC4738(GR)F TRANSISTOR
Q704,705 2SC4738(GR)F TRANSISTOR
Q706 DTC114EUA DIGITAL TRANSISTOR
Q707 DTC144EUA DIGITAL TRANSISTOR
BA300 W09-1004-05 LITHIUM CELL
D21 B30-2230-05 LED (1608/YG/8)
C7 CC73GCH1H471J CHIP C 470PF J
C10 CC73GCH1H070B CHIP C 7.0PF B K2
C10 CC73GCH1H080B CHIP C 8.0PF B K
C12 CC73GCH1H060B CHIP C 6.0PF B K2
C12 CC73GCH1H100C CHIP C 10PF C K
C14 CC73GCH1H471J CHIP C 470PF J
C15 CK73GB1H104K CHIP C 0.10UF K
C17 CC73GCH1H471J CHIP C 470PF J
C18 CK73GB1H104K CHIP C 0.10UF K
C19 CC73GCH1H471J CHIP C 470PF J
C24 CC73GCH1H471J CHIP C 470PF J
C25 CK73GB1H104K CHIP C 0.10UF K
C26 CC73GCH1H471J CHIP C 470PF J
C27 CK73GB1H102K CHIP C 1000PF K
C32 CC73GCH1H151J CHIP C 150PF J
C33 CC73GCH1H271J CHIP C 270PF J
C34,35 CC73GCH1H471J CHIP C 470PF J
C36 CK73GB1H102K CHIP C 1000PF K
C37 CK73FB1E224K CHIP C 0.22UF K
C38 CS77CA1VR33M CHIP TNTL 0.33UF 35WV
C39 CC73GCH1H271J CHIP C 270PF J
C41,42 CC73GCH1H471J CHIP C 470PF J
C43 CC73GCH1H561J CHIP C 560PF J
C44 CK73GB1H103K CHIP C 0.010UF K
C45 CK73GB1H104K CHIP C 0.10UF K
C46 CC73GCH1H561J CHIP C 560PF J
C47 CC73GCH1H471J CHIP C 470PF J
C48 CK73GB1H104K CHIP C 0.10UF K
C50 CE32BM1E470M CHIP EL 47UF 25WV
C51 CK73GB1H104K CHIP C 0.10UF K
C53 CC73GCH1H271J CHIP C 270PF J
C54 CC73GCH1H101J CHIP C 100PF J
C55 CC73GCH1H080B CHIP C 8.0PF B K2
C55 CC73GCH1H080D CHIP C 8.0PF D K
C56 CC73GCH1H271J CHIP C 270PF J
C58
✽
CS77CB21C220M CHIP TNTL 22UF 16WV
C59 CK73GB1H104K CHIP C 0.10UF K
C60,61 CC73GCH1H471J CHIP C 470PF J
C62-66 CK73GB1H104K CHIP C 0.10UF K
C67
✽
CS77CB21C220M CHIP TNTL 22UF 16WV
C68 CC73GCH1H101J CHIP C 100PF J
C69 CC73GCH1H471J CHIP C 470PF J
C70
✽
CS77CC1C330M CHIP TNTL 33UF 16WV
C71 CC73GCH1H271J CHIP C 270PF J
C74 CC73GCH1H271J CHIP C 270PF J
C75
✽
CS77CC1C330M CHIP TNTL 33UF 16WV
C76 CC73GCH1H561J CHIP C 560PF J
C77 CK73GB1H104K CHIP C 0.10UF K
C79 CS77BA1E010M CHIP TNTL 1.0UF 25WV
C80 CC73GCH1H561J CHIP C 560PF J
C81 CK73GB1H104K CHIP C 0.10UF K
C82 CC73GCH1H271J CHIP C 270PF J
C83-85 CC73GCH1H471J CHIP C 470PF J
C86 CC73GCH1H271J CHIP C 270PF J
C87 CK73GB1H104K CHIP C 0.10UF K
C88 CK73GB1H103K CHIP C 0.010UF K
C89 CC73GCH1H180G CHIP C 18PF G K2
C89 CC73GCH1H220G CHIP C 22PF G K
C90 CK73GB1H103K CHIP C 0.010UF K
C91 CC73GCH1H120G CHIP C 12PF G K2
C91 CC73GCH1H180G CHIP C 18PF G K
C92-95 CC73FCH1H040B CHIP C 4.0PF B K2
C92,93 CC73FCH1H050B CHIP C 5.0PF B K
C94 CC73FCH1H060B CHIP C 6.0PF B K
C95 CC73FCH1H050B CHIP C 5.0PF B K
C96 CE32BM1E470M CHIP EL 47UF 25WV
C97 CK73GB1H104K CHIP C 0.10UF K
C98,99 CC73GCH1H471J CHIP C 470PF J
C100 CK73GB1H103K CHIP C 0.010UF K
C102 CC73GCH1H471J CHIP C 470PF J
C103 CC73GCH1H060D CHIP C 6.0PF D
C104 CC73GCH1H471J CHIP C 470PF J
C105 CC73FCH1H050B CHIP C 5.0PF B K2
C105,106 CC73FCH1H050B CHIP C 5.0PF B K
C106 CC73FCH1H040B CHIP C 4.0PF B K2
C107 CC73GCH1H330J CHIP C 33PF J
C108 CC73GCH1H560J CHIP C 56PF J
C109,110 CK73GB1H103K CHIP C 0.010UF K
C112 CC73GCH1H220J CHIP C 22PF J
C113 CC73FCH1H060B CHIP C 6.0PF B K
C113,114 CC73FCH1H060B CHIP C 6.0PF B K2
C114 CC73FCH1H050B CHIP C 5.0PF B K
C115 CC73GCH1H090D CHIP C 9.0PF D
C116 CC73GCH1H560J CHIP C 56PF J
C117 CC73GCH1H121J CHIP C 120PF J
C118-120 CC73GCH1H471J CHIP C 470PF J
C122 CC73GCH1H090D CHIP C 9.0PF D
C123,124 CC73FCH1H060B CHIP C 6.0PF B
C125 CC73GCH1H070D CHIP C 7.0PF D
C126 CK73GB1H104K CHIP C 0.10UF K
C128 CC73GCH1H560J CHIP C 56PF J
C129,130 CK73GB1H103K CHIP C 0.010UF K
C131
✽
CS77CC1C330M CHIP TNTL 33UF 16WV
C132-134 CC73GCH1H471J CHIP C 470PF J
C137 CC73GCH1H060D CHIP C 6.0PF D
C138 CC73GCH1H150J CHIP C 15PF J
C139 CE32BM1E470M CHIP EL 47UF 25WV
C140,141 CK73GB1H103K CHIP C 0.010UF K
C142,143 CC73FCH1H0R5C CHIP C 0.5PF C
C144-146 CK73GB1H104K CHIP C 0.10UF K
RX UNIT (X55-3100-XX) -10 : K -11 : K2
