Kenwood NXR-800 Service Manual Supplement

NXR-800
20
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4140-11)
R778 RK73HB1J000J CHIP R 0.0 J 1/16W
R779 RK73HB1J104J CHIP R 100K J 1/16W
R780 RK73HB1J000J CHIP R 0.0 J 1/16W
R781-784 RK73HB1J104J CHIP R 100K J 1/16W
R785 RK73HB1J272J CHIP R 2.7K J 1/16W
R786-788 RK73HB1J104J CHIP R 100K J 1/16W
R794 RK73HB1J104J CHIP R 100K J 1/16W
R796 RK73HB1J104J CHIP R 100K J 1/16W
R799-803 RK73HB1J104J CHIP R 100K J 1/16W
R805-808 RK73HB1J103J CHIP R 10K J 1/16W
R816 RK73HB1J105J CHIP R 1.0M J 1/16W
R817 RK73HB1J821J CHIP R 820 J 1/16W
R818 RK73HB1J104J CHIP R 100K J 1/16W
R819 RK73GB2A000J CHIP R 0.0 J 1/10W
R820 RK73HB1J103J CHIP R 10K J 1/16W
R821 RK73HB1J000J CHIP R 0.0 J 1/16W
R822 RK73HB1J103J CHIP R 10K J 1/16W
R824 RK73HB1J103J CHIP R 10K J 1/16W
R826 RK73HB1J103J CHIP R 10K J 1/16W
R827 RK73GB2A000J CHIP R 0.0 J 1/10W
R828 RK73HB1J104J CHIP R 100K J 1/16W
R829 RK73HH1J113D CHIP R 11K D 1/16W
R830 RK73HB1J104J CHIP R 100K J 1/16W
R832 RK73HB1J104J CHIP R 100K J 1/16W
R833 RK73HB1J000J CHIP R 0.0 J 1/16W
R834 RK73HB1J104J CHIP R 100K J 1/16W
R835 RK73HB1J000J CHIP R 0.0 J 1/16W
R837 RK73GH2A49R9D CHIP R 49.9 D 1/10W
R839 RK73GB2A000J CHIP R 0.0 J 1/10W
R840 RK73GH2A49R9D CHIP R 49.9 D 1/10W
R842-845 RK73HB1J104J CHIP R 100K J 1/16W
R867,868 RK73GH2A24R9D CHIP R 24.9 D 1/10W
R869 RK73HB1J331J CHIP R 330 J 1/16W
R870 RK73HB1J000J CHIP R 0.0 J 1/16W
R871-873 RK73HB1J103J CHIP R 10K J 1/16W
R874 RK73HB1J000J CHIP R 0.0 J 1/16W
R875,876 RK73GH2A24R9D CHIP R 24.9 D 1/10W
R877,878 RK73HB1J103J CHIP R 10K J 1/16W
R879 RK73GB2A000J CHIP R 0.0 J 1/10W
R880,881 RK73HB1J104J CHIP R 100K J 1/16W
R883-885 RK73HB1J000J CHIP R 0.0 J 1/16W
R886 RK73HB1J221J CHIP R 220 J 1/16W
R887 RK73HB1J000J CHIP R 0.0 J 1/16W
R888 RK73HB1J221J CHIP R 220 J 1/16W
R889 RK73HB1J103J CHIP R 10K J 1/16W
R890 RK73HB1J000J CHIP R 0.0 J 1/16W
R891 RK73HB1J104J CHIP R 100K J 1/16W
R892,893 RK73HB1J000J CHIP R 0.0 J 1/16W
R894 RK73HB1J103J CHIP R 10K J 1/16W
R895 RK73HB1J151J CHIP R 150 J 1/16W
R896 RK73HB1J101J CHIP R 100 J 1/16W
R897 RK73HB1J104J CHIP R 100K J 1/16W
R902,903 RK73HB1J000J CHIP R 0.0 J 1/16W
R907 RK73HB1J000J CHIP R 0.0 J 1/16W
R909 RK73HB1J000J CHIP R 0.0 J 1/16W
R910 RK73HB1J473J CHIP R 47K J 1/16W
R911 RK73HB1J000J CHIP R 0.0 J 1/16W
R912 RK73HB1J473J CHIP R 47K J 1/16W
R913,914 RK73HB1J000J CHIP R 0.0 J 1/16W
R915 RK73HB1J473J CHIP R 47K J 1/16W
R916-923 RK73HB1J000J CHIP R 0.0 J 1/16W
R924 RK73HB1J104J CHIP R 100K J 1/16W
R926 RK73HB1J473J CHIP R 47K J 1/16W
R927-933 RK73HB1J000J CHIP R 0.0 J 1/16W
R934,935 RK73HB1J474J CHIP R 470K J 1/16W
R936 RK73HB1J104J CHIP R 100K J 1/16W
R942 RK73HB1J104J CHIP R 100K J 1/16W
R943 RK73HB1J000J CHIP R 0.0 J 1/16W
R945-950 RK73HB1J000J CHIP R 0.0 J 1/16W
R951 RK73HB1J104J CHIP R 100K J 1/16W
R952,953 RK73HB1J000J CHIP R 0.0 J 1/16W
R954-957 RK73GB2A000J CHIP R 0.0 J 1/10W
R961 RK73GB2A000J CHIP R 0.0 J 1/10W
S700 S79-0473-05 DIP SWITCHES
D300 1SS388F DIODE
D701 1SS388F DIODE
D702 1SS355 DIODE
IC300,301 TC7SET126FU-F MOS-IC
IC302 SN65HVD485EDR MOS-IC
IC303 BU4829FVE MOS-IC
IC304 TC7SH125FU-F MOS-IC
IC305 XC6209B332PR MOS-IC
IC306 BA15BC0FP MOS-IC
IC307 XC6201P152PR MOS-IC
IC308 XC61CN2702N MOS-IC
IC309 AK4550VTP MOS-IC
IC312 ADCS7476AIMF MOS-IC
IC313 TC7WU04FK-F MOS-IC
IC314
✽
Note 1 (BGA) ROM IC
IC315 ADF4001BRUZ MOS-IC
IC318 TC7SH126FU-F MOS-IC
IC319-321 TC7SET126FU-F MOS-IC
IC323,324 Note 1 (BGA) MICRO CONTOROL UNIT
IC325 3625MGP396GP MICRO CONTOROL UNIT
IC327 TC7SH08FU-F MOS-IC
IC329 1C BA33DD0WT MOS-IC
IC330 TC7SH126FU-F MOS-IC
IC700 62167DV30LL55 SRAM IC
IC701 RV5C386A MOS-IC
IC702
✽
29PL127JKCDB ROM IC
IC703
✽
Note 1 (BGA) MICRO CONTOROL UNIT
IC704 48LC8M16A2P75I DRAM IC
IC705 ADM3202ARUZ MOS-IC
IC707 48LC8M16A2P75I DRAM IC
IC708 BU4829FVE MOS-IC
IC709 TC7SH126FU-F MOS-IC
IC710,711 TC7SH00FU-F MOS-IC
IC712,713 TC7SH32FU-F MOS-IC
IC714-716 TC7MA244FK MOS-IC
IC717,718 TC7MA245FK MOS-IC
IC719 LAN91C111I-NU MOS-IC
IC720 AT93C4610SU1.8 ROM IC
IC721 TC7SH08FU-F MOS-IC
IC722 TC7SH32FU-F MOS-IC
IC723 TC7SH00FU-F MOS-IC
IC724 TC7SH125FU-F MOS-IC
IC725 TC7SH126FU-F MOS-IC
IC726 TC7SH08FU-F MOS-IC
IC727,728 TC7SH126FU-F MOS-IC
Note 1 : This part cannot be replaced. Therefore, this part is not supplied as a service part.
