Kenwood NXR-800 Service Manual Supplement

NXR-800
19
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4140-11)
R464 RK73HB1J472J CHIP R 4.7K J 1/16W
R469 RK73HB1J470J CHIP R 47 J 1/16W
R470 RK73HB1J102J CHIP R 1.0K J 1/16W
R474 RK73HB1J100J CHIP R 10 J 1/16W
R478 RK73HB1J100J CHIP R 10 J 1/16W
R479 RK73HB1J102J CHIP R 1.0K J 1/16W
R480 RK73HB1J100J CHIP R 10 J 1/16W
R481 RK73HB1J473J CHIP R 47K J 1/16W
R483 RK73HB1J104J CHIP R 100K J 1/16W
R484 RK73HB1J000J CHIP R 0.0 J 1/16W
R485 RK73HB1J100J CHIP R 10 J 1/16W
R486-489 RK73HB1J000J CHIP R 0.0 J 1/16W
R491-505 RK73HB1J000J CHIP R 0.0 J 1/16W
R516-518 RK73HB1J473J CHIP R 47K J 1/16W
R521 RK73HB1J000J CHIP R 0.0 J 1/16W
R522 RK73HB1J473J CHIP R 47K J 1/16W
R526 RK73HB1J000J CHIP R 0.0 J 1/16W
R527 RK73HB1J473J CHIP R 47K J 1/16W
R528,529 RK73HB1J000J CHIP R 0.0 J 1/16W
R530 RK73HB1J473J CHIP R 47K J 1/16W
R531,532 RK73HB1J000J CHIP R 0.0 J 1/16W
R533,534 RK73HB1J473J CHIP R 47K J 1/16W
R535-539 RK73HB1J000J CHIP R 0.0 J 1/16W
R540-542 RK73HB1J473J CHIP R 47K J 1/16W
R543 RK73HB1J000J CHIP R 0.0 J 1/16W
R546 RK73HB1J000J CHIP R 0.0 J 1/16W
R547,548 RK73HB1J473J CHIP R 47K J 1/16W
R549 RK73HB1J000J CHIP R 0.0 J 1/16W
R550 RK73HB1J473J CHIP R 47K J 1/16W
R551,552 RK73HB1J000J CHIP R 0.0 J 1/16W
R553-555 RK73HB1J473J CHIP R 47K J 1/16W
R556,557 RK73HB1J000J CHIP R 0.0 J 1/16W
R559 RK73HB1J102J CHIP R 1.0K J 1/16W
R560 RK73HB1J103J CHIP R 10K J 1/16W
R561 RK73HB1J000J CHIP R 0.0 J 1/16W
R562 RK73HB1J103J CHIP R 10K J 1/16W
R564-566 RK73HB1J000J CHIP R 0.0 J 1/16W
R567 RK73HB1J473J CHIP R 47K J 1/16W
R568 RK73HB1J000J CHIP R 0.0 J 1/16W
R569 RK73HB1J224J CHIP R 220K J 1/16W
R570 RK73HB1J000J CHIP R 0.0 J 1/16W
R573-576 RK73HB1J000J CHIP R 0.0 J 1/16W
R577,578 RK73HB1J473J CHIP R 47K J 1/16W
R579 RK73HB1J000J CHIP R 0.0 J 1/16W
R581 RK73HB1J000J CHIP R 0.0 J 1/16W
R582 RK73HB1J473J CHIP R 47K J 1/16W
R583 RK73HB1J000J CHIP R 0.0 J 1/16W
R584 RK73HB1J473J CHIP R 47K J 1/16W
R585,586 RK73HB1J000J CHIP R 0.0 J 1/16W
R587 RK73HB1J473J CHIP R 47K J 1/16W
R588 RK73HB1J000J CHIP R 0.0 J 1/16W
R589 RK73HB1J473J CHIP R 47K J 1/16W
R590 RK73HB1J000J CHIP R 0.0 J 1/16W
R591 RK73HB1J223J CHIP R 22K J 1/16W
R592-600 RK73HB1J000J CHIP R 0.0 J 1/16W
R602 RK73HB1J103J CHIP R 10K J 1/16W
R604 RK73HB1J103J CHIP R 10K J 1/16W
R605-610 RK73HB1J000J CHIP R 0.0 J 1/16W
R612-616 RK73HB1J000J CHIP R 0.0 J 1/16W
R620-623 RK73HB1J000J CHIP R 0.0 J 1/16W
R624 RK73HB1J473J CHIP R 47K J 1/16W
R626 RK73HB1J473J CHIP R 47K J 1/16W
R627 RK73HB1J000J CHIP R 0.0 J 1/16W
R629-631 RK73HB1J000J CHIP R 0.0 J 1/16W
R632 RK73HB1J101J CHIP R 100 J 1/16W
R634 RK73HB1J473J CHIP R 47K J 1/16W
R635,636 RK73HB1J000J CHIP R 0.0 J 1/16W
R637-640 RK73HB1J473J CHIP R 47K J 1/16W
R641 RK73HB1J000J CHIP R 0.0 J 1/16W
R642 RK73HB1J101J CHIP R 100 J 1/16W
R643 RK73HB1J473J CHIP R 47K J 1/16W
R644 RK73HB1J000J CHIP R 0.0 J 1/16W
R646 RK73HB1J473J CHIP R 47K J 1/16W
R648 RK73HB1J000J CHIP R 0.0 J 1/16W
R649 RK73HB1J101J CHIP R 100 J 1/16W
R650 RK73HB1J473J CHIP R 47K J 1/16W
R651-653 RK73HB1J000J CHIP R 0.0 J 1/16W
R656,657 RK73HB1J000J CHIP R 0.0 J 1/16W
R660-664 RK73HB1J000J CHIP R 0.0 J 1/16W
R667,668 RK73HB1J000J CHIP R 0.0 J 1/16W
R672-674 RK73HB1J473J CHIP R 47K J 1/16W
R678,679 RK73HB1J000J CHIP R 0.0 J 1/16W
R680 RK73HB1J473J CHIP R 47K J 1/16W
R685-687 RK73HB1J000J CHIP R 0.0 J 1/16W
R690 RK73HB1J000J CHIP R 0.0 J 1/16W
R700,701 RK73HB1J103J CHIP R 10K J 1/16W
R702,703 RK73HB1J473J CHIP R 47K J 1/16W
R709,710 RK73HB1J104J CHIP R 100K J 1/16W
R711 RK73GB2A000J CHIP R 0.0 J 1/10W
R712-714 RK73HB1J100J CHIP R 10 J 1/16W
R715 RK73GB2A000J CHIP R 0.0 J 1/10W
R716 RK73HB1J000J CHIP R 0.0 J 1/16W
R718 RK73HB1J104J CHIP R 100K J 1/16W
R719 RK73HB1J472J CHIP R 4.7K J 1/16W
R720 RK73HB1J100J CHIP R 10 J 1/16W
R721 RK73GB2A000J CHIP R 0.0 J 1/10W
R722 RK73HB1J472J CHIP R 4.7K J 1/16W
R725,726 RK73HB1J000J CHIP R 0.0 J 1/16W
R727 RK73HB1J103J CHIP R 10K J 1/16W
R729,730 RK73HB1J000J CHIP R 0.0 J 1/16W
R731 RK73HB1J103J CHIP R 10K J 1/16W
R732 RK73HB1J390J CHIP R 39 J 1/16W
R733 RK73HB1J104J CHIP R 100K J 1/16W
R734 RK73HB1J102J CHIP R 1.0K J 1/16W
R735,736 RK73HB1J000J CHIP R 0.0 J 1/16W
R738 RK73HB1J104J CHIP R 100K J 1/16W
R742 RK73HB1J104J CHIP R 100K J 1/16W
R743,744 RK73HB1J153J CHIP R 15K J 1/16W
R745 RK73HB1J104J CHIP R 100K J 1/16W
R751 RK73HB1J000J CHIP R 0.0 J 1/16W
R754 RK73HB1J103J CHIP R 10K J 1/16W
R756 RK73HB1J000J CHIP R 0.0 J 1/16W
R758 RK73HB1J103J CHIP R 10K J 1/16W
R759 RK73HB1J000J CHIP R 0.0 J 1/16W
R760 RK73HB1J103J CHIP R 10K J 1/16W
R761-765 RK73GB2A000J CHIP R 0.0 J 1/10W
R766 RK73HB1J000J CHIP R 0.0 J 1/16W
R767 RK73HB1J102J CHIP R 1.0K J 1/16W
R768-770 RK73HB1J000J CHIP R 0.0 J 1/16W
R772-777 RK73HB1J104J CHIP R 100K J 1/16W
