Kenwood NXR-800 Service Manual Supplement

NXR-800
18
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4140-11)
C804 CK73FB0J106K CHIP C 10UF K
C805-807 CK73HB1E103K CHIP C 0.010UF K
C808 CK73HB1H102K CHIP C 1000PF K
C809 CK73HB1A104K CHIP C 0.10UF K
C812 CK73HB1A104K CHIP C 0.10UF K
C813-815 CK73HB1H102K CHIP C 1000PF K
C816-818 CK73HB1A104K CHIP C 0.10UF K
C819 CK73HB1H102K CHIP C 1000PF K
C820,821 CK73HB1A104K CHIP C 0.10UF K
C822 CK73HB1H102K CHIP C 1000PF K
C825 CK73HB1H102K CHIP C 1000PF K
C826,827 CC73HCH1H101J CHIP C 100PF J
C828 CK73HB1H102K CHIP C 1000PF K
C829 CC73HCH1H101J CHIP C 100PF J
C830 CK73HB1H102K CHIP C 1000PF K
C831 CC73HCH1H101J CHIP C 100PF J
C832 CK73HB1H102K CHIP C 1000PF K
C833,834 CK73HB1A104K CHIP C 0.10UF K
C835-837 CK73HB1H102K CHIP C 1000PF K
C838,839 CC73HCH1H101J CHIP C 100PF J
C841-848 CC73GCH1H470J CHIP C 47PF J
C850 CC73GCH1H470J CHIP C 47PF J
C851-869 CC73HCH1H470J CHIP C 47PF J
C870-873 CK73HB1H102K CHIP C 1000PF K
CN300 E04-0193-05 PIN SOCKET
CN302 E04-0193-05 PIN SOCKET
CN400-402 E40-6656-05 PIN ASSY
CN713 E41-2263-05 PIN ASSY
J700 E58-0516-05 MODULAR JACK
J701 E58-0515-05 RECTANGULAR RECEPTACLE
J702,703 E58-0533-05 MODULAR JACK
- J19-5497-05 HOLDER (COMPACT FLASH)
L300-307 L92-0447-05 BEADS CORE
L308,309 L41-8285-33 SMALL FIXED INDUCTOR (0.82UH)
L310 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L311,312 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L313-316 L92-0447-05 BEADS CORE
L317,318 L33-1500-05 CHOKE COIL
L319-325 L92-0447-05 BEADS CORE
L326-329 L92-0467-05 CHIP FERRITE
X300 L77-1988-05 VCXO (12.288MHZ)
X301 L77-1984-05 CRYSTAL RESONATOR (14.7456MHZ)
X700 L77-1985-05 CRYSTAL RESONATOR (25.8048MHZ)
X701 L77-1802-05 CRYSTAL RESONATOR (32768HZ)
X702 L77-1986-05 CRYSTAL RESONATOR (25MHZ)
- N30-2008-43 PAN HEAD MACHINE SCREW
CP716 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP718 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP720 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP737 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP739 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP743 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP747 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP750 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP760 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP762 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP768 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP775-778 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
CP783-798 RK75HA1J390J CHIP-COM 39 J 1/16W
CP807-811 RK75HA1J104J CHIP-COM 100K J 1/16W
CP813 RK75HA1J104J CHIP-COM 100K J 1/16W
CP814,815 RK75HA1JR00J CHIP-COM 0.00 J 1/16W
R300,301 RK73GB2A000J CHIP R 0.0 J 1/10W
R302 RK73HB1J000J CHIP R 0.0 J 1/16W
R303 RK73GB2A000J CHIP R 0.0 J 1/10W
R309 RK73HB1J000J CHIP R 0.0 J 1/16W
R311-317 RK73HB1J000J CHIP R 0.0 J 1/16W
R318,319 RK73HB1J101J CHIP R 100 J 1/16W
R320-337 RK73HB1J000J CHIP R 0.0 J 1/16W
R339 RK73HB1J473J CHIP R 47K J 1/16W
R340-350 RK73HB1J000J CHIP R 0.0 J 1/16W
R352-354 RK73HB1J000J CHIP R 0.0 J 1/16W
R356-360 RK73HB1J000J CHIP R 0.0 J 1/16W
R361 RK73GB2A104J CHIP R 100K J 1/10W
R362 RK73GB2A681J CHIP R 680 J 1/10W
R363-386 RK73HB1J000J CHIP R 0.0 J 1/16W
R387 RK73HB1J104J CHIP R 100K J 1/16W
R388-390 RK73GB2A000J CHIP R 0.0 J 1/10W
R391 RK73GB2A100J CHIP R 10 J 1/10W
R392 RK73HB1J103J CHIP R 10K J 1/16W
R393-397 RK73HB1J000J CHIP R 0.0 J 1/16W
R398 RK73HB1J104J CHIP R 100K J 1/16W
R399 RK73HB1J151J CHIP R 150 J 1/16W
R401 RK73HB1J000J CHIP R 0.0 J 1/16W
R403 RK73GB2A000J CHIP R 0.0 J 1/10W
R404,405 RK73HB1J000J CHIP R 0.0 J 1/16W
R406 RK73GB2A000J CHIP R 0.0 J 1/10W
R408,409 RK73HB1J000J CHIP R 0.0 J 1/16W
R410 RK73GB2A103J CHIP R 10K J 1/10W
R411 RK73GB2A472J CHIP R 4.7K J 1/10W
R413 RK73GB2A103J CHIP R 10K J 1/10W
R414 RK73HB1J000J CHIP R 0.0 J 1/16W
R415 RK73HB1J100J CHIP R 10 J 1/16W
R416 RK73HB1J104J CHIP R 100K J 1/16W
R417 RK73HB1J000J CHIP R 0.0 J 1/16W
R418,419 RK73GB2A104J CHIP R 100K J 1/10W
R420 RK73HB1J000J CHIP R 0.0 J 1/16W
R421 RK73HB1J100J CHIP R 10 J 1/16W
R423 RK73HB1J000J CHIP R 0.0 J 1/16W
R424 RK73GB2A681J CHIP R 680 J 1/10W
R425 RK73HB1J000J CHIP R 0.0 J 1/16W
R428 RK73GB2A100J CHIP R 10 J 1/10W
R429 RK73GB2A471J CHIP R 470 J 1/10W
R431 RK73HB1J000J CHIP R 0.0 J 1/16W
R432 RK73GB2A220J CHIP R 22 J 1/10W
R433 RK73HB1J105J CHIP R 1.0M J 1/16W
R438 RK73GB2A100J CHIP R 10 J 1/10W
R439,440 RK73GB2A220J CHIP R 22 J 1/10W
R441 RK73HB1J823J CHIP R 82K J 1/16W
R442 RK73HB1J683J CHIP R 68K J 1/16W
R445 RK73HB1J393J CHIP R 39K J 1/16W
R446,447 RK73HB1J000J CHIP R 0.0 J 1/16W
R448 RK73GB2A221J CHIP R 220 J 1/10W
R449 RK73HB1J683J CHIP R 68K J 1/16W
R451 RK73HB1J473J CHIP R 47K J 1/16W
R452-454 RK73HB1J100J CHIP R 10 J 1/16W
R457-461 RK73HB1J473J CHIP R 47K J 1/16W
