NXR-800

PARTS LIST

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

CONTROL UNIT (X53-4140-11)

C449,450 CK73HB1A104K CHIP C 0.10UF K

C453 CK73GB1H103K CHIP C 0.010UF K

C461 CK73GB1H103K CHIP C 0.010UF K

C462 CK73HB1E103K CHIP C 0.010UF K

C463 CC73HCH1H100D CHIP C 10PF D

C465 CK73GB1H103K CHIP C 0.010UF K

C466 CK73GB1H104K CHIP C 0.10UF K

C467 CK73GB1H103K CHIP C 0.010UF K

C468 CK73GB1H104K CHIP C 0.10UF K

C469 CC73GCH1H121J CHIP C 120PF J

C471 CK73HB1H102K CHIP C 1000PF K

C474 CK73HB1H392K CHIP C 3900PF K

C475 CK73FB0J106K CHIP C 10UF K

C476 CK73HB1A104K CHIP C 0.10UF K

C477 CC73GCH1H121J CHIP C 120PF J

C478 CK73HB1H102K CHIP C 1000PF K

C479 CC73GCH1H121J CHIP C 120PF J

C480 CK73FB0J106K CHIP C 10UF K

C482 CK73HB1A104K CHIP C 0.10UF K

C484 CS77BA1C010M CHIP TNTL 1.0UF 16WV

C485 CK73GB1H103K CHIP C 0.010UF K

C486 CC73GCH1H121J CHIP C 120PF J

C487 CK73HB1H102K CHIP C 1000PF K

C491 CK73FB0J106K CHIP C 10UF K

C493,494 CK73HB1A104K CHIP C 0.10UF K

C495 CK73GB1E105K CHIP C 1.0UF K

C496 CK73HB1C822K CHIP C 8200PF K

C501 CK73HB1A104K CHIP C 0.10UF K

C504 CK73HB1A104K CHIP C 0.10UF K

C506 CK73HB1H472K CHIP C 4700PF K

C507 CK73HB1E103K CHIP C 0.010UF K

C508 CK73HB1A104K CHIP C 0.10UF K

C509 CK73GB1E105K CHIP C 1.0UF K

C515 CK73GB1E105K CHIP C 1.0UF K

C516 CK73HB1H102K CHIP C 1000PF K

C517 CK73HB1A104K CHIP C 0.10UF K

C519 CK73HB1C473K CHIP C 0.047UF K

C520 CK73GB1E105K CHIP C 1.0UF K

C521 CK73HB1E103K CHIP C 0.010UF K

C522-525 CK73HB1A104K CHIP C 0.10UF K

C526-529 CK73FB0J106K CHIP C 10UF K

C531 CK73HB1H102K CHIP C 1000PF K

C532 CK73HB1A104K CHIP C 0.10UF K

C533-536 CK73HB1H102K CHIP C 1000PF K

C537 CK73FB0J106K CHIP C 10UF K

C538,539 CK73HB1H102K CHIP C 1000PF K

C543 CK73FB0J106K CHIP C 10UF K

C544-546 CK73HB1H102K CHIP C 1000PF K

C547 CK73FB0J106K CHIP C 10UF K

C548 CK73HB1E103K CHIP C 0.010UF K

C549 CC73HCH1H120G CHIP C 12PF G

C550,551 CC73HCH1H100D CHIP C 10PF D

C552 CC73HCH1H150J CHIP C 15PF J

C553 CK73HB1E103K CHIP C 0.010UF K

C557 CK73HB1H102K CHIP C 1000PF K

C565 CK73FB0J106K CHIP C 10UF K

C566 CK73HB1H102K CHIP C 1000PF K

C567 CK73HB1E103K CHIP C 0.010UF K

C569 CE32AU1C330M CHIP EL 33UF 16WV

C570,571 CK73HB1H102K CHIP C 1000PF K

C572 CE32BM1E470M CHIP EL 47UF 25WV

C574 CK73HB1H102K CHIP C 1000PF K

C575-588 CK73HB1E103K CHIP C 0.010UF K

C590-601 CK73HB1E103K CHIP C 0.010UF K

C700 CK73HB1E103K CHIP C 0.010UF K

C701 CK73HB1A104K CHIP C 0.10UF K

C702 CK73HB1H102K CHIP C 1000PF K

C703 CC73HCH1H150J CHIP C 15PF J

C704,705 CK73FB0J106K CHIP C 10UF K

C706 CK73HB1H102K CHIP C 1000PF K

C707 CC73HCH1H070D CHIP C 7.0PF D

C708 CK73HB1A104K CHIP C 0.10UF K

C709 CK73FB0J106K CHIP C 10UF K

C710 CK73HB1E103K CHIP C 0.010UF K

C711 CK73FB0J106K CHIP C 10UF K

C712 CK73HB1H102K CHIP C 1000PF K

C713 CK73HB1A104K CHIP C 0.10UF K

C714 CK73FB0J106K CHIP C 10UF K

C715 CK73HB1A104K CHIP C 0.10UF K

C716 CK73HB1H102K CHIP C 1000PF K

C717 CK73HB1A104K CHIP C 0.10UF K

C718 CC73HCH1H070D CHIP C 7.0PF D

C719 CK73FB0J106K CHIP C 10UF K

C720 CK73HB1A104K CHIP C 0.10UF K

C721 CC73HCH1H100D CHIP C 10PF D

C722,723 CK73HB1H102K CHIP C 1000PF K

C724 CK73HB1A104K CHIP C 0.10UF K

C725 CK73HB1H102K CHIP C 1000PF K

C726 CK73FB0J106K CHIP C 10UF K

C727 CC73HCH1H020B CHIP C 2.0PF B

C728 CK73HB1E103K CHIP C 0.010UF K

C729 CC73HCH1H020B CHIP C 2.0PF B

C730 CK73HB1A104K CHIP C 0.10UF K

C732 CK73HB1H102K CHIP C 1000PF K

C733-741 CK73HB1A104K CHIP C 0.10UF K

C742 CK73FB0J106K CHIP C 10UF K

C743,744 CK73HB1A104K CHIP C 0.10UF K

C746-750 CK73GB1E105K CHIP C 1.0UF K

C751 CK73HB1E103K CHIP C 0.010UF K

C754-758 CK73HB1A104K CHIP C 0.10UF K

C767,768 CK73HB1H102K CHIP C 1000PF K

C769 CK73FB0J106K CHIP C 10UF K

C770-773 CK73HB1A104K CHIP C 0.10UF K

C775 CK73HB1H102K CHIP C 1000PF K

C776-780 CK73HB1E103K CHIP C 0.010UF K

C781 CK73HB1A104K CHIP C 0.10UF K

C782 CC73HCH1H120G CHIP C 12PF G

C783 CC73HCH1H100D CHIP C 10PF D

C784,785 CK73HB1A104K CHIP C 0.10UF K

C786 CC73HCH1H150J CHIP C 15PF J

C787 CC73HCH1H100D CHIP C 10PF D

C788 CK73FB0J106K CHIP C 10UF K

C789-793 CK73HB1A104K CHIP C 0.10UF K

C794 CK73FB0J106K CHIP C 10UF K

C795 CK73HB1A104K CHIP C 0.10UF K

C796,797 CK73HB1E103K CHIP C 0.010UF K

C798 CK73HB1A104K CHIP C 0.10UF K

C799,800 CK73HB1E103K CHIP C 0.010UF K

C801 CK73HB1H102K CHIP C 1000PF K

C802,803 CK73HB1A104K CHIP C 0.10UF K
