NXR-800
16
Ref. No.
Ad dress
Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No.
Ad dress
Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4130-11)
CONTROL UNIT (X53-4140-11)
IC18 XC6201P182MR MOS-IC
IC19 NJM2732V BI-POLAR IC
IC20,21
✽
NJM2734V BI-POLAR IC
IC22 BU4094BCFV MOS-IC
IC23 TC7SH00FU-F MOS-IC
IC25 TC7S66FUF MOS-IC
IC27 TC7SET126FU-F MOS-IC
IC28 TC7SH126FU-F MOS-IC
IC29 2C LA4425A MOS-IC
IC30 TC7SH00FU-F MOS-IC
IC31 TC7MH4040FK-F MOS-IC
IC32,33 TC7SH126FU-F MOS-IC
IC34 3625MGP396GP MICRO CONTOROL UNIT
IC35 S24CS02AFJTBG ROM IC
IC36 TC7MET541AFK MOS-IC
IC37 320VC5402PGE MICRO CONTOROL UNIT
IC38 TC7SET08FU-F MOS-IC
IC39 TC7SH125FU-F MOS-IC
IC40 TC7SH126FU-F MOS-IC
IC41 TC7SH08FU-F MOS-IC
IC50 TC7SH08FU-F MOS-IC
Q1 DTC114EUA DIGITAL TRANSISTOR
Q2,3 2SJ506-E(S) FET
Q4,5
✽
2SC4738F TRANSISTOR
Q6 DTC363EU DIGITAL TRANSISTOR
Q7,8 DTC114EUA DIGITAL TRANSISTOR
Q9 2SJ506-E(S) FET
Q10
✽
2SC4738F TRANSISTOR
Q11 2SD2114K(W) TRANSISTOR
Q12
✽
2SC4738F TRANSISTOR
Q13 2SD2114K(W) TRANSISTOR
Q14 2SC4116(Y)F TRANSISTOR
Q15 2SA1586(Y)F TRANSISTOR
Q16 2SC4116(Y)F TRANSISTOR
Q17 2SA1586(Y)F TRANSISTOR
Q18 2SK1830F FET
Q19 HN1L02FU(F) FET
Q20 2SA1955A-F TRANSISTOR
Q21 DTC144EUA DIGITAL TRANSISTOR
Q22 2SA1955A-F TRANSISTOR
Q23 DTC144EUA DIGITAL TRANSISTOR
Q25,26 DTC144EUA DIGITAL TRANSISTOR
Q27-29 2SD2114K(W) TRANSISTOR
C302 CC73HCH1H101J CHIP C 100PF J
C303 CK73HB1H102K CHIP C 1000PF K
C305 CK73HB1A104K CHIP C 0.10UF K
C306 CK73HB1H102K CHIP C 1000PF K
C308,309 CK73HB1H102K CHIP C 1000PF K
C311 CK73HB1A104K CHIP C 0.10UF K
C312-317 CK73HB1H102K CHIP C 1000PF K
C320 CC73HCH1H101J CHIP C 100PF J
C322,323 CK73HB1H102K CHIP C 1000PF K
C324 CC73HCH1H101J CHIP C 100PF J
C326-329 CK73HB1H102K CHIP C 1000PF K
C331 CK73HB1H102K CHIP C 1000PF K
C333-335 CK73HB1H102K CHIP C 1000PF K
C337 CK73HB1H102K CHIP C 1000PF K
C339 CC73HCH1H101J CHIP C 100PF J
C341,342 CK73HB1H102K CHIP C 1000PF K
C343 CC73HCH1H101J CHIP C 100PF J
C344 CK73HB1H102K CHIP C 1000PF K
C345 CC73HCH1H101J CHIP C 100PF J
C346-348 CK73HB1H102K CHIP C 1000PF K
C349 CC73HCH1H101J CHIP C 100PF J
C350 CK73HB1H102K CHIP C 1000PF K
C352 CK73HB1H102K CHIP C 1000PF K
C353 CC73HCH1H101J CHIP C 100PF J
C354 CK73HB1H102K CHIP C 1000PF K
C355 CK73HB1E103K CHIP C 0.010UF K
C356 CC73HCH1H101J CHIP C 100PF J
C357,358 CK73HB1H102K CHIP C 1000PF K
C359,360 CK73HB1A104K CHIP C 0.10UF K
C361 CK73HB1H102K CHIP C 1000PF K
C362 CK73HB1E103K CHIP C 0.010UF K
C364-366 CK73HB1H102K CHIP C 1000PF K
C369,370 CK73HB1H102K CHIP C 1000PF K
C371 CK73HB1A104K CHIP C 0.10UF K
C373,374 CK73HB1H102K CHIP C 1000PF K
C376-378 CK73HB1H102K CHIP C 1000PF K
C379 CK73HB1A104K CHIP C 0.10UF K
C380,381 CK73HB1H102K CHIP C 1000PF K
C383-386 CK73HB1H102K CHIP C 1000PF K
C387 CK73GB1H103K CHIP C 0.010UF K
C388-390 CK73HB1H102K CHIP C 1000PF K
C391 CK73GB1E105K CHIP C 1.0UF K
C393-395 CK73HB1H102K CHIP C 1000PF K
C396 CK73GB1H103K CHIP C 0.010UF K
C397,398 CK73HB1H102K CHIP C 1000PF K
C399 CK73GB1H104K CHIP C 0.10UF K
C401 CC73HCH1H101J CHIP C 100PF J
C402 CK73HB1H102K CHIP C 1000PF K
C403 CC73HCH1H101J CHIP C 100PF J
C405,406 CK73HB1H102K CHIP C 1000PF K
C409 CK73HB1H102K CHIP C 1000PF K
C410 CC73HCH1H101J CHIP C 100PF J
C412-415 CK73HB1H102K CHIP C 1000PF K
C416 CC73HCH1H101J CHIP C 100PF J
C417,418 CE32AU1C330M CHIP EL 33UF 16WV
C419 CC73HCH1H101J CHIP C 100PF J
C420 CK73HB1A104K CHIP C 0.10UF K
C421 CK73HB1H102K CHIP C 1000PF K
C422 CE32AU1C330M CHIP EL 33UF 16WV
C423 CC73HCH1H101J CHIP C 100PF J
C424 CK73HB1H102K CHIP C 1000PF K
C426-430 CK73HB1H102K CHIP C 1000PF K
C432 CC73HCH1H101J CHIP C 100PF J
C433 CK73HB1H102K CHIP C 1000PF K
C435-437 CK73HB1H102K CHIP C 1000PF K
C438 CK73GB1H103K CHIP C 0.010UF K
C439 CE32AU1C330M CHIP EL 33UF 16WV
C440-442 CK73HB1H102K CHIP C 1000PF K
C443,444 CE32AU1C330M CHIP EL 33UF 16WV
C445 CK73HB1A104K CHIP C 0.10UF K
C446 CK73FB1H102K CHIP C 1000PF K
C447 CK73HB1A104K CHIP C 0.10UF K
C448 CE32AU1C330M CHIP EL 33UF 16WV
CONTROL UNIT (X53-4140-11 for service)
To Next Page
