Kenwood NXR-800 Service Manual Supplement

NXR-800
15
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4130-11)
R222 RK73GB2A473J CHIP R 47K J 1/10W
R230,231 RK73GB2A473J CHIP R 47K J 1/10W
R232 RK73GB2A102J CHIP R 1.0K J 1/10W
R233 RK73GB2A000J CHIP R 0.0 J 1/10W
R234,235 RK73GB2A473J CHIP R 47K J 1/10W
R237 RK73GB2A473J CHIP R 47K J 1/10W
R240-243 RK73GB2A473J CHIP R 47K J 1/10W
R245,246 RK73GB2A472J CHIP R 4.7K J 1/10W
R247 RK73GB2A473J CHIP R 47K J 1/10W
R249,250 RK73GB2A000J CHIP R 0.0 J 1/10W
R251 RK73GB2A473J CHIP R 47K J 1/10W
R254 RK73GB2A473J CHIP R 47K J 1/10W
R261,262 RK73GB2A473J CHIP R 47K J 1/10W
R267-271 RK73GB2A473J CHIP R 47K J 1/10W
R273 RK73GB2A473J CHIP R 47K J 1/10W
R275 RK73GB2A473J CHIP R 47K J 1/10W
R277 RK73GB2A473J CHIP R 47K J 1/10W
R279 RK73GB2A103J CHIP R 10K J 1/10W
R281 RK73GB2A103J CHIP R 10K J 1/10W
R283 RK73GB2A000J CHIP R 0.0 J 1/10W
R286-288 RK73GB2A000J CHIP R 0.0 J 1/10W
R289 RK73GB2A473J CHIP R 47K J 1/10W
R290 RK73GB2A000J CHIP R 0.0 J 1/10W
R292-294 RK73GB2A000J CHIP R 0.0 J 1/10W
R296,297 RK73GB2A473J CHIP R 47K J 1/10W
R299,300 RK73GB2A103J CHIP R 10K J 1/10W
R301,302 RK73GB2A104J CHIP R 100K J 1/10W
R303-315 RK73GB2A473J CHIP R 47K J 1/10W
R316-338 RK73GB2A000J CHIP R 0.0 J 1/10W
R340 RK73GB2A102J CHIP R 1.0K J 1/10W
R342-351 RK73GB2A102J CHIP R 1.0K J 1/10W
R352 RK73GB2A471J CHIP R 470 J 1/10W
R353-357 RK73GB2A102J CHIP R 1.0K J 1/10W
R358 RK73GB2A122J CHIP R 1.2K J 1/10W
R359 RK73GB2A000J CHIP R 0.0 J 1/10W
R360 RK73GB2A122J CHIP R 1.2K J 1/10W
R361-377 RK73GB2A000J CHIP R 0.0 J 1/10W
R378,379 RK73GB2A122J CHIP R 1.2K J 1/10W
R380 RK73GB2A000J CHIP R 0.0 J 1/10W
R389-396 RK73GB2A000J CHIP R 0.0 J 1/10W
R398-409 RK73GB2A000J CHIP R 0.0 J 1/10W
R410 RK73GB2A684J CHIP R 680K J 1/10W
R411 RK73GB2A224J CHIP R 220K J 1/10W
R412 RK73GB2A103J CHIP R 10K J 1/10W
R413 RK73GB2A104J CHIP R 100K J 1/10W
R414 RK73GB2A000J CHIP R 0.0 J 1/10W
R415-418 RK73GB2A104J CHIP R 100K J 1/10W
R419,420 RK73GB2A000J CHIP R 0.0 J 1/10W
R426 RS14KB3D220J
FL-PROOF RS 22 J 2W
R428-430 RK73GB2A000J CHIP R 0.0 J 1/10W
R432 RK73GB2A470J CHIP R 47 J 1/10W
R433 RK73GB2A473J CHIP R 47K J 1/10W
R434 RK73GB2A470J CHIP R 47 J 1/10W
R435 RK73GB2A473J CHIP R 47K J 1/10W
R436-446 RK73GB2A000J CHIP R 0.0 J 1/10W
R448-454 RK73GB2A000J CHIP R 0.0 J 1/10W
R455 RK73GB2A104J CHIP R 100K J 1/10W
R457 RK73GB2A473J CHIP R 47K J 1/10W
R458,459 RK73GB2A104J CHIP R 100K J 1/10W
R460,461 RK73GB2A103J CHIP R 10K J 1/10W
R467,468 RK73GB2A000J CHIP R 0.0 J 1/10W
R469 RK73GB2A103J CHIP R 10K J 1/10W
R470 RK73GB2A000J CHIP R 0.0 J 1/10W
R471-473 RK73GB2A104J CHIP R 100K J 1/10W
R474 RK73GB2A000J CHIP R 0.0 J 1/10W
R475 RK73GB2A104J CHIP R 100K J 1/10W
R477 RK73GB2A104J CHIP R 100K J 1/10W
R478 RK73GB2A103J CHIP R 10K J 1/10W
R479 RK73GB2A000J CHIP R 0.0 J 1/10W
R482 RK73GB2A000J CHIP R 0.0 J 1/10W
R484 RK73GB2A000J CHIP R 0.0 J 1/10W
R491-495 RK73GB2A000J CHIP R 0.0 J 1/10W
R501 RK73GB2A000J CHIP R 0.0 J 1/10W
R502 RK73GB2A183J CHIP R 18K J 1/10W
R507-510 RK73GB2A183J CHIP R 18K J 1/10W
R511-515 RK73GB2A123J CHIP R 12K J 1/10W
R522,523 RK73GB2A000J CHIP R 0.0 J 1/10W
R524,525 RK73GB2A473J CHIP R 47K J 1/10W
R526,527 RK73GB2A121J CHIP R 120 J 1/10W
R528-535 RK73GB2A000J CHIP R 0.0 J 1/10W
R536 RK73GB2A104J CHIP R 100K J 1/10W
R540 RK73GB2A222J CHIP R 2.2K J 1/10W
R541 RK73GB2A123J CHIP R 12K J 1/10W
R551 RK73GB2A000J CHIP R 0.0 J 1/10W
D1,2 CMS05-Q DIODE
D3,4 DA204U DIODE
D5 1SS355 DIODE
D6
✽
02DZ18F-X ZENER DIODE
D7-11 DA204U DIODE
D12 1SS355 DIODE
D13
✽
02DZ18F-X ZENER DIODE
D14-18 DA204U DIODE
D20 DA204U DIODE
D23 DA204U DIODE
D24 SMD185F-2 VARISTOR
D25 MINISMDC020F VARISTOR
D26 1SS388F DIODE
D28 1SS355 DIODE
D29
✽
02DZ18F-X ZENER DIODE
D30 1SS355 DIODE
D31
✽
02DZ18F-X ZENER DIODE
D32 1SS355 DIODE
D33
✽
02DZ18F-X ZENER DIODE
D36,37 DA204U DIODE
D38,39 1SS388F DIODE
IC1 BU4094BCFV MOS-IC
IC2,3 BU4053BCFV MOS-IC
IC4 AK4550VTP MOS-IC
IC5 NJM2732V BI-POLAR IC
IC6 XC6209B332PR MOS-IC
IC7 TA75S01F-F MOS-IC
IC8 M62364FP-F MOS-IC
IC9
✽
NJM2734V BI-POLAR IC
IC10,11 NJM2340RB1 MOS-IC
IC12 NJM2732V BI-POLAR IC
IC14 BU4053BCFV MOS-IC
IC15 BA33BC0FP MOS-IC
IC16 XC6209B502PR MOS-IC
IC17
✽
Note 1 (BGA) ROM IC
Note 1 : This part cannot be replaced. Therefore, this part is not supplied as a service part.
