Kenwood NXR-800 Service Manual Supplement

NXR-800
14
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
CONTROL UNIT (X53-4130-11)
L15 L33-1476-05 SMALL FIXED INDUCTOR
L16 L33-1475-05 SMALL FIXED INDUCTOR
L17,18 L92-0447-05 BEADS CORE
L19 L33-1475-05 SMALL FIXED INDUCTOR
L20-22 L92-0447-05 BEADS CORE
L32-40 L92-0447-05 BEADS CORE
L43 L92-0447-05 BEADS CORE
L44-49 L92-0467-05 CHIP FERRITE
X1 L77-1984-05 CRYSTAL RESONATOR (14.7456MHZ)
X2 L77-1987-05
CRYSTAL RESONATOR (16.515072MHZ)
CP8 RK75GB1JR00 CHIP-COM 0.00 1/16W
CP10 RK75GB1JR00 CHIP-COM 0.00 1/16W
CP13 RK75GB1JR00 CHIP-COM 0.00 1/16W
CP19 RK75GB1JR00 CHIP-COM 0.00 1/16W
CP24-26 RK75GB1JR00 CHIP-COM 0.00 1/16W
R1,2 RK73GB2A000J CHIP R 0.0 J 1/10W
R4 RK73GB2A000J CHIP R 0.0 J 1/10W
R6 RK73GB2A101J CHIP R 100 J 1/10W
R7-17 RK73GB2A000J CHIP R 0.0 J 1/10W
R18,19 RK73GB2A101J CHIP R 100 J 1/10W
R21-45 RK73GB2A000J CHIP R 0.0 J 1/10W
R47-49 RK73GB2A000J CHIP R 0.0 J 1/10W
R51-61 RK73GB2A000J CHIP R 0.0 J 1/10W
R62 RK73GB2A101J CHIP R 100 J 1/10W
R63,64 RK73GB2A332J CHIP R 3.3K J 1/10W
R65 RK73GB2A183J CHIP R 18K J 1/10W
R66 RK73GB2A823J CHIP R 82K J 1/10W
R67 RK73GH2A822D CHIP R 8.2K D 1/10W
R68 RK73GH2A332D CHIP R 3.3K D 1/10W
R69,70 RK73GB2A000J CHIP R 0.0 J 1/10W
R71 RK73GH2A473D CHIP R 47K D 1/10W
R72-76 RK73GB2A000J CHIP R 0.0 J 1/10W
R77 RK73GH2A104D CHIP R 100K D 1/10W
R78 RK73GB2A104J CHIP R 100K J 1/10W
R79 RK73GH2A332D CHIP R 3.3K D 1/10W
R80 RK73GB2A123J CHIP R 12K J 1/10W
R81,82 RK73GB2A563J CHIP R 56K J 1/10W
R83 RK73GB2A124J CHIP R 120K J 1/10W
R84 RK73GB2A473J CHIP R 47K J 1/10W
R85 RK73GB2A000J CHIP R 0.0 J 1/10W
R86 RK73GB2A473J CHIP R 47K J 1/10W
R87 RK73GB2A223J CHIP R 22K J 1/10W
R88 RK73GB2A000J CHIP R 0.0 J 1/10W
R89 RK73GB2A103J CHIP R 10K J 1/10W
R90 RK73GB2A153J CHIP R 15K J 1/10W
R91 RK73GB2A472J CHIP R 4.7K J 1/10W
R92 RK73GB2A562J CHIP R 5.6K J 1/10W
R93,94 RK73GB2A000J CHIP R 0.0 J 1/10W
R95 RK73GB2A470J CHIP R 47 J 1/10W
R96 RK73GB2A223J CHIP R 22K J 1/10W
R98 RK73GB2A103J CHIP R 10K J 1/10W
R100 RK73GB2A473J CHIP R 47K J 1/10W
R101 RK73GB2A000J CHIP R 0.0 J 1/10W
R102 RK73GB2A123J CHIP R 12K J 1/10W
R103-105 RK73GB2A473J CHIP R 47K J 1/10W
R106-108 RK73GB2A000J CHIP R 0.0 J 1/10W
R109 RK73GB2A153J CHIP R 15K J 1/10W
R111 RK73GB2A823J CHIP R 82K J 1/10W
R112 RK73GB2A123J CHIP R 12K J 1/10W
R113 RK73GB2A823J CHIP R 82K J 1/10W
R114 RK73GB2A223J CHIP R 22K J 1/10W
R115 RK73GB2A154J CHIP R 150K J 1/10W
R116 RK73GB2A223J CHIP R 22K J 1/10W
R127 RK73GB2A473J CHIP R 47K J 1/10W
R128-130 RK73GB2A000J CHIP R 0.0 J 1/10W
R131-133 RK73GB2A473J CHIP R 47K J 1/10W
R135 RK73GB2A000J CHIP R 0.0 J 1/10W
R137 RK73GB2A102J CHIP R 1.0K J 1/10W
R138 RK73GB2A473J CHIP R 47K J 1/10W
R141-144 RK73GB2A000J CHIP R 0.0 J 1/10W
R145 RK73GB2A104J CHIP R 100K J 1/10W
R146-148 RK73GB2A000J CHIP R 0.0 J 1/10W
R149 RK73GB2A333J CHIP R 33K J 1/10W
R150 RK73GB2A563J CHIP R 56K J 1/10W
R151 RK73GB2A124J CHIP R 120K J 1/10W
R152 RK73GB2A104J CHIP R 100K J 1/10W
R153 RK73GB2A000J CHIP R 0.0 J 1/10W
R154,155 RK73GB2A333J CHIP R 33K J 1/10W
R156,157 RK73GH2A104D CHIP R 100K D 1/10W
R158 RK73GB2A333J CHIP R 33K J 1/10W
R159 RK73GB2A000J CHIP R 0.0 J 1/10W
R160,161 RK73GB2A563J CHIP R 56K J 1/10W
R162 RK73GB2A224J CHIP R 220K J 1/10W
R163 RK73GB2A000J CHIP R 0.0 J 1/10W
R165 RK73GB2A104J CHIP R 100K J 1/10W
R166 RK73GB2A333J CHIP R 33K J 1/10W
R167 RK73GB2A473J CHIP R 47K J 1/10W
R168 RK73GB2A563J CHIP R 56K J 1/10W
R169 RK73GB2A333J CHIP R 33K J 1/10W
R171 RK73GB2A183J CHIP R 18K J 1/10W
R172,173 RK73GB2A473J CHIP R 47K J 1/10W
R174 RK73GB2A683J CHIP R 68K J 1/10W
R175 RK73GB2A393J CHIP R 39K J 1/10W
R176 RK73GB2A473J CHIP R 47K J 1/10W
R177,178 RK73GB2A000J CHIP R 0.0 J 1/10W
R179 RK73GB2A473J CHIP R 47K J 1/10W
R181,182 RK73GB2A103J CHIP R 10K J 1/10W
R183 RK73GB2A000J CHIP R 0.0 J 1/10W
R184 RK73GB2A473J CHIP R 47K J 1/10W
R188 RK73GB2A000J CHIP R 0.0 J 1/10W
R191 RK73GB2A000J CHIP R 0.0 J 1/10W
R193 RK73GB2A103J CHIP R 10K J 1/10W
R194 RK73GB2A473J CHIP R 47K J 1/10W
R195,196 RK73GB2A000J CHIP R 0.0 J 1/10W
R197 RK73GB2A103J CHIP R 10K J 1/10W
R198 RK73GB2A473J CHIP R 47K J 1/10W
R199 RK73GB2A103J CHIP R 10K J 1/10W
R200,201 RK73GB2A000J CHIP R 0.0 J 1/10W
R202 RK73GB2A473J CHIP R 47K J 1/10W
R203 RK73GB2A104J CHIP R 100K J 1/10W
R204 RK73GB2A473J CHIP R 47K J 1/10W
R205 RK73GB2A104J CHIP R 100K J 1/10W
R206 RK73GB2A122J CHIP R 1.2K J 1/10W
R207,208 RK73GB2A473J CHIP R 47K J 1/10W
R210 RK73GB2A000J CHIP R 0.0 J 1/10W
R211,212 RK73GB2A473J CHIP R 47K J 1/10W
R215 RK73GB2A473J CHIP R 47K J 1/10W
R216,217 RK73GB2A000J CHIP R 0.0 J 1/10W
R218,219 RK73GB2A473J CHIP R 47K J 1/10W
R220,221 RK73GB2A000J CHIP R 0.0 J 1/10W
