NXR-800

PARTS LIST

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

CONTROL UNIT (X53-4130-11)

C276 CC73GCH1H100D CHIP C 10PF D

C277 CK73GB1H103K CHIP C 0.010UF K

C278 CK73FB0J106K CHIP C 10UF K

C279 CK73GB1H103K CHIP C 0.010UF K

C280 CC73GCH1H100D CHIP C 10PF D

C281 CC73GCH1H150J CHIP C 15PF J

C282 CK73GB1H103K CHIP C 0.010UF K

C283 CK73GB1H104K CHIP C 0.10UF K

C284-288 CK73GB1H103K CHIP C 0.010UF K

C289 CK73GB1H102K CHIP C 1000PF K

C290-297 CK73GB1H103K CHIP C 0.010UF K

C299,300 CK73GB1H103K CHIP C 0.010UF K

C302 CK73GB1H103K CHIP C 0.010UF K

C304 CC73GCH1H101J CHIP C 100PF J

C305,306 CK73GB1H102K CHIP C 1000PF K

C307-310 CC73GCH1H101J CHIP C 100PF J

C311,312 CK73GB1H102K CHIP C 1000PF K

C313 CC73GCH1H101J CHIP C 100PF J

C314 CK73GB1H102K CHIP C 1000PF K

C315 CC73GCH1H101J CHIP C 100PF J

C316 CK73GB1H102K CHIP C 1000PF K

C317 CK73GB1H103K CHIP C 0.010UF K

C318 CC73GCH1H101J CHIP C 100PF J

C319 CK73GB1H102K CHIP C 1000PF K

C320 CK73GB1H103K CHIP C 0.010UF K

C321 CC73GCH1H101J CHIP C 100PF J

C322,323 CK73GB1H102K CHIP C 1000PF K

C324 CK73GB1H103K CHIP C 0.010UF K

C325 CC73GCH1H101J CHIP C 100PF J

C326,327 CK73GB1H102K CHIP C 1000PF K

C328 CK73GB1H103K CHIP C 0.010UF K

C329-331 CK73GB1H102K CHIP C 1000PF K

C332 CK73GB1H103K CHIP C 0.010UF K

C333-339 CK73GB1H102K CHIP C 1000PF K

C340 CK73GB1H103K CHIP C 0.010UF K

C342,343 CK73GB1H102K CHIP C 1000PF K

C344 CK73GB1H103K CHIP C 0.010UF K

C345 CK73GB1H104K CHIP C 0.10UF K

C346,347 CK73GB1H102K CHIP C 1000PF K

C348 CK73GB1H103K CHIP C 0.010UF K

C350 CK73GB1H102K CHIP C 1000PF K

C351 CK73GB1H103K CHIP C 0.010UF K

C352,353 CK73GB1H102K CHIP C 1000PF K

C354 CK73GB1H103K CHIP C 0.010UF K

C355 CC73GCH1H101J CHIP C 100PF J

C356 CK73GB1H102K CHIP C 1000PF K

C357 CK73GB1H103K CHIP C 0.010UF K

C358 CK73GB1H102K CHIP C 1000PF K

C359 CC73GCH1H101J CHIP C 100PF J

C360 CK73GB1H102K CHIP C 1000PF K

C361 CK73GB1H103K CHIP C 0.010UF K

C362 CK73GB1H102K CHIP C 1000PF K

C363 CC73GCH1H101J CHIP C 100PF J

C364 CK73GB1H102K CHIP C 1000PF K

C365 CK73GB1H103K CHIP C 0.010UF K

C366-368 CK73GB1H102K CHIP C 1000PF K

C369 CK73GB1H103K CHIP C 0.010UF K

C370-372 CK73GB1H102K CHIP C 1000PF K

C373 CC73GCH1H101J CHIP C 100PF J

C374 CK73GB1H103K CHIP C 0.010UF K

C375,376 CK73GB1H102K CHIP C 1000PF K

C377 CC73GCH1H101J CHIP C 100PF J

C379,380 CK73GB1H102K CHIP C 1000PF K

C381 CC73GCH1H101J CHIP C 100PF J

C382 CK73GB1H103K CHIP C 0.010UF K

C383,384 CK73GB1H102K CHIP C 1000PF K

C385 CC73GCH1H101J CHIP C 100PF J

C386,387 CK73GB1H102K CHIP C 1000PF K

C388 CC73GCH1H101J CHIP C 100PF J

C389,390 CK73GB1H102K CHIP C 1000PF K

C394 C92-0905-05 OS-CON 47UF 35WV

C395 CK73GB1H103K CHIP C 0.010UF K

C396-399 CK73GB1H102K CHIP C 1000PF K

C400,401 CE32AU1C330M CHIP EL 33UF 16WV

C403 CK73GB1E105K CHIP C 1.0UF K

C404 CK73FB0J106K CHIP C 10UF K

C405,406 CC73GCH1H101J CHIP C 100PF J

C407 CK73GB1H102K CHIP C 1000PF K

C408-410 CK73GB1E105K CHIP C 1.0UF K

C413 CK73GB1H104K CHIP C 0.10UF K

C414 CK73GB1H103K CHIP C 0.010UF K

C415 CK73GB1H104K CHIP C 0.10UF K

C416 CK73GB1H103K CHIP C 0.010UF K

C417 CK73GB1E105K CHIP C 1.0UF K

C418-420 CK73GB1H102K CHIP C 1000PF K

C421 CC73GCH1H101J CHIP C 100PF J

C422-424 CK73GB1H102K CHIP C 1000PF K

C425,426 CC73GCH1H101J CHIP C 100PF J

C427-435 CK73GB1H102K CHIP C 1000PF K

C436 CK73GB1E105K CHIP C 1.0UF K

C437,438 CC73GCH1H101J CHIP C 100PF J

C440 CK73GB1H102K CHIP C 1000PF K

C442 CC73GCH1H101J CHIP C 100PF J

C444 CK73GB1H102K CHIP C 1000PF K

C445 CK73GB1H104K CHIP C 0.10UF K

C446 CC73GCH1H391J CHIP C 390PF J

C447 CC73GCH1H101J CHIP C 100PF J

C448,449 CK73GB1H102K CHIP C 1000PF K

C450 CC73GCH1H101J CHIP C 100PF J

C452,453 CK73GB1H102K CHIP C 1000PF K

C456,457 CK73GB1H102K CHIP C 1000PF K

C463 CK73GB1H104K CHIP C 0.10UF K

C467,468 CK73GB1H102K CHIP C 1000PF K

C469,470 CC73GCH1H101J CHIP C 100PF J

C471 CK73GB1H102K CHIP C 1000PF K

C473-475 CK73GB1H102K CHIP C 1000PF K

C477 CK73GB1E105K CHIP C 1.0UF K

C499 C92-0905-05 OS-CON 47UF 35WV

C500 CK73GB1H104K CHIP C 0.10UF K

C510 CK73FB0J106K CHIP C 10UF K

CN1-3 E40-6656-05 PIN ASSY

CN4 E41-2673-05 PIN ASSY

CN56,57 E40-6656-05 PIN ASSY

CN58 E40-5960-05 PIN ASSY

CN59 E40-6102-05 PIN ASSY

CN60 E41-2735-05 PIN ASSY

F1,2 F53-0315-05 FUSE

L3-14 L92-0447-05 BEADS CORE
