NXR-800

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

PARTS LIST

Ref. No.

Ad dress

Parts No. Description

Desti-

nation

New

parts

CONTROL UNIT (X53-4130-11)

C65 CK73FB0J106K CHIP C 10UF K

C66 CK73GB1H102K CHIP C 1000PF K

C67 CK73FB0J106K CHIP C 10UF K

C68 CK73GB1H102K CHIP C 1000PF K

C69 CK73GB1H104K CHIP C 0.10UF K

C70 CK73GB1H102K CHIP C 1000PF K

C71 CK73FB0J106K CHIP C 10UF K

C72 CK73GB1E105K CHIP C 1.0UF K

C73 CC73GCH1H101J CHIP C 100PF J

C74 CK73GB1H104K CHIP C 0.10UF K

C75 CC73GCH1H101J CHIP C 100PF J

C76 CK73GB1H102K CHIP C 1000PF K

C77 C93-0912-05 CHIP C 100UF M

C78 CK73FB0J106K CHIP C 10UF K

C79-82 CK73GB1H104K CHIP C 0.10UF K

C83-86 CK73FB0J106K CHIP C 10UF K

C87 C93-0912-05 CHIP C 100UF M

C88 CK73GB1H103K CHIP C 0.010UF K

C89,90 CC73GCH1H221J CHIP C 220PF J

C92 CC73GCH1H100D CHIP C 10PF D

C95 C93-0912-05 CHIP C 100UF M

C96 CC73GCH1H101J CHIP C 100PF J

C97 CK73GB1H104K CHIP C 0.10UF K

C98 CK73FB0J106K CHIP C 10UF K

C99 CK73GB1H102K CHIP C 1000PF K

C102 CC73GCH1H150J CHIP C 15PF J

C103 CC73GCH1H101J CHIP C 100PF J

C104-106 CD04BD1H221M ELECTRO 220UF 50WV

C107 CK73GB1H102K CHIP C 1000PF K

C108 CK73GB1H104K CHIP C 0.10UF K

C109 CK73GB1H102K CHIP C 1000PF K

C110 C93-0912-05 CHIP C 100UF M

C111 CK73GB1H104K CHIP C 0.10UF K

C119 CC73GCH1H181J CHIP C 180PF J

C120 CK73GB1H102K CHIP C 1000PF K

C121 CK73FB0J106K CHIP C 10UF K

C122 CC73GCH1H101J CHIP C 100PF J

C123 CK73GB1H472K CHIP C 4700PF K

C125 CK73GB1H472K CHIP C 4700PF K

C127 CK73GB1H182K CHIP C 1800PF K

C128 CC73GCH1H101J CHIP C 100PF J

C130 CD04BD1H221M ELECTRO 220UF 50WV

C131 CE32AU1C330M CHIP EL 33UF 16WV

C133 CD04BD1H221M ELECTRO 220UF 50WV

C134 CK73GB1H104K CHIP C 0.10UF K

C137,138 CK73GB1H102K CHIP C 1000PF K

C139,140 CE32AU1C330M CHIP EL 33UF 16WV

C141 CK73GB1H102K CHIP C 1000PF K

C144 CE32AU1C330M CHIP EL 33UF 16WV

C145 CK73GB1H182K CHIP C 1800PF K

C146 CK73GB1H104K CHIP C 0.10UF K

C152 CK73GB1H102K CHIP C 1000PF K

C155 CC73GCH1H181J CHIP C 180PF J

C157 CE32AU1C330M CHIP EL 33UF 16WV

C159 CK73GB1H102K CHIP C 1000PF K

C161 CK73GB1H102K CHIP C 1000PF K

C162 CE32AU1C330M CHIP EL 33UF 16WV

C165 CK73GB1H102K CHIP C 1000PF K

C166 CE32AU1C330M CHIP EL 33UF 16WV

C169 CK73FB0J106K CHIP C 10UF K

C170 CK73GB1H102K CHIP C 1000PF K

C172 CK73FB0J106K CHIP C 10UF K

C173 CC73GCH1H101J CHIP C 100PF J

C174 CK73GB1H102K CHIP C 1000PF K

C175 CC73GCH1H391J CHIP C 390PF J

C177 CC73GCH1H101J CHIP C 100PF J

C178 CK73FB0J106K CHIP C 10UF K

C188,189 CK73GB1H104K CHIP C 0.10UF K

C190 CK73GB1E105K CHIP C 1.0UF K

C192,193 CK73GB1E105K CHIP C 1.0UF K

C194 CC73GCH1H560J CHIP C 56PF J

C195 CC73GCH1H181J CHIP C 180PF J

C196 CC73GCH1H101J CHIP C 100PF J

C197 CC73GCH1H330J CHIP C 33PF J

C199 C93-0912-05 CHIP C 100UF M

C200 CK73FB0J106K CHIP C 10UF K

C202 CK73GB1E105K CHIP C 1.0UF K

C203 CC73GCH1H101J CHIP C 100PF J

C204 CC73GCH1H121J CHIP C 120PF J

C205 CK73GB1H182K CHIP C 1800PF K

C206 C93-0912-05 CHIP C 100UF M

C207 CK73GB1H102K CHIP C 1000PF K

C208 CK73FB0J106K CHIP C 10UF K

C209 CK73GB1H103K CHIP C 0.010UF K

C212 CC73GCH1H120J CHIP C 12PF J

C213 CK73GB1H103K CHIP C 0.010UF K

C215 CK73GB1H104K CHIP C 0.10UF K

C216 CC73GCH1H100D CHIP C 10PF D

C219 CC73GCH1H100D CHIP C 10PF D

C222 CC73GCH1H150J CHIP C 15PF J

C223 CK73GB1H103K CHIP C 0.010UF K

C224 CK73GB1E105K CHIP C 1.0UF K

C225 CK73GB1H104K CHIP C 0.10UF K

C226 CK73FB0J106K CHIP C 10UF K

C227 CK73GB1H102K CHIP C 1000PF K

C229 CC73GCH1H101J CHIP C 100PF J

C230 CK73GB1E105K CHIP C 1.0UF K

C234,235 CK73GB1H104K CHIP C 0.10UF K

C236 C90-4120-05 ELECTRO 470UF 35WV

C237 CK73GB1H104K CHIP C 0.10UF K

C239 C92-0777-05 ELECTRO 1000UF 25WV

C244 CK73GB1H104K CHIP C 0.10UF K

C245 CK73FB0J106K CHIP C 10UF K

C246,247 CK73GB1H102K CHIP C 1000PF K

C248,249 CK73GB1H104K CHIP C 0.10UF K

C250 CK73FB0J106K CHIP C 10UF K

C251 CK73GB1H102K CHIP C 1000PF K

C252 CK73FB0J106K CHIP C 10UF K

C253-255 CK73GB1H103K CHIP C 0.010UF K

C256 CK73GB1H104K CHIP C 0.10UF K

C257 CK73FB0J106K CHIP C 10UF K

C258 CK73GB1H103K CHIP C 0.010UF K

C262 CK73FB0J106K CHIP C 10UF K

C263 CK73GB1H102K CHIP C 1000PF K

C265 CK73GB1H104K CHIP C 0.10UF K

C266-270 CK73GB1H103K CHIP C 0.010UF K

C271 CK73FB0J106K CHIP C 10UF K

C272,273 CK73GB1H103K CHIP C 0.010UF K

C274 CK73GB1H472K CHIP C 4700PF K

C275 CC73GCH1H120J CHIP C 12PF J
