Kenwood NXR-800 Service Manual Supplement

NXR-800
11
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
FINAL UNIT (X45-3820-XX)
CONTROL UNIT (X53-4130-11)
R34 RK73FB2B8R2J CHIP R 8.2 J 1/8W
R35,36 RK73GB2A823J CHIP R 82K J 1/10W
R37 RK73GB2A104J CHIP R 100K J 1/10W
R38 RK73FB2B151J CHIP R 150 J 1/8W
R39,40 RK73GB2A334J CHIP R 330K J 1/10W
R41 RK73GB2A000J CHIP R 0.0 J 1/10W
R42 RK73FB2B8R2J CHIP R 8.2 J 1/8W
R44 RK73FB2B8R2J CHIP R 8.2 J 1/8W
R45,46 RK73GB2A000J CHIP R 0.0 J 1/10W
R47 RK73FB2B151J CHIP R 150 J 1/8W
R49 RK73GB2A000J CHIP R 0.0 J 1/10W
R50,51 RK73GB2A104J CHIP R 100K J 1/10W
R52 RK73FB2B8R2J CHIP R 8.2 J 1/8W
R53-58 RK73GB2A104J CHIP R 100K J 1/10W K2
R53,54 RK73GB2A154J CHIP R 150K J 1/10W K
R55-58 RK73GB2A104J CHIP R 100K J 1/10W K
R59,60 RK73GB2A103J CHIP R 10K J 1/10W
R61 RK73EB2E101J CHIP R 100 J 1/4W
R62 RK73GH2A563D CHIP R 56K D 1/10W
R63 RK73GH2A333D CHIP R 33K D 1/10W
R64 RK73GB2A474J CHIP R 470K J 1/10W
R65 RK73GB2A473J CHIP R 47K J 1/10W
R66 RK73GB2A100J CHIP R 10 J 1/10W
R67 RS14DB3A121J
FL-PROOF RS 120 J 1W
R68 RK73GB2A104J CHIP R 100K J 1/10W
R69 RK73GB2A103J CHIP R 10K J 1/10W
R70-72 RK73GB2A000J CHIP R 0.0 J 1/10W
R75,76 RK73GB2A472J CHIP R 4.7K J 1/10W
R78 RK73GB2A104J CHIP R 100K J 1/10W
R89 RK73GB2A000J CHIP R 0.0 J 1/10W
R92 RK73GB2A104J CHIP R 100K J 1/10W
R98 RK73FB2B000J CHIP R 0.0 J 1/8W K
R102 RK73GH2A471D CHIP R 470 D 1/10W
R104 RK73GB2A393J CHIP R 39K J 1/10W
R105 RK73GB2A000J CHIP R 0.0 J 1/10W
R106 RK73GB2A474J CHIP R 470K J 1/10W
R107 RK73GB2A000J CHIP R 0.0 J 1/10W
R110 RK73GB2A394J CHIP R 390K J 1/10W
R121 RK73GH2A103D CHIP R 10K D 1/10W
R123 RK73GB2A103J CHIP R 10K J 1/10W
R124 RK73FB2B220J CHIP R 22 J 1/8W K
R124 RK73FB2B8R2J CHIP R 8.2 J 1/8W K2
R125 R92-1061-05 JUMPER REST 0 OHM
R133 RK73GB2A102J CHIP R 1.0K J 1/10W
R136 RK73GB2A394J CHIP R 390K J 1/10W
R137-140 RK73GB2A104J CHIP R 100K J 1/10W
R142 RK73GB2A000J CHIP R 0.0 J 1/10W
R144 RK73GB2A000J CHIP R 0.0 J 1/10W K
R145 RK73GB2A000J CHIP R 0.0 J 1/10W K2
R900 RK73GB2A000J CHIP R 0.0 J 1/10W
R901 RK73GB2A182J CHIP R 1.8K J 1/10W
R902 RK73GB2A000J CHIP R 0.0 J 1/10W
R903 RK73GB2A681J CHIP R 680 J 1/10W
R905,906 RK73GB2A000J CHIP R 0.0 J 1/10W
R907 RK73GH2A153D CHIP R 15K D 1/10W
R909 RK73GB2A000J CHIP R 0.0 J 1/10W
R910 RK73GB2A182J CHIP R 1.8K J 1/10W
R911,912 RK73GB2A000J CHIP R 0.0 J 1/10W
R914 RK73GB2A222J CHIP R 2.2K J 1/10W
VR1 R32-0744-05
SEMI FIXED VARIABLE RESISTOR (220)
VR2 R32-0754-05 SEMI FIXED VARIABLE RESISTOR (10K)
VR902
✽
R31-0668-05 VARIABLE RESISTOR (10K)
D4
✽
Z5W27V SURGE ABSORBER
D5 DSM3MA1-RPB DIODE
D6 1SS355 DIODE
D7 02CZ5.6(Y)F ZENER DIODE
D9,10 HSB88WS DIODE
D11 L7091CER DIODE
D14-16 L7091CER DIODE
D19 02CZ4.7(Y)F ZENER DIODE
D902 AVRM16270MABB VARISTOR
IC1 LTC6101BIS5-F ANALOGUE IC
IC2 NJM2904E-ZB ANALOGUE IC
IC3 TA78L05FF MOS-IC
IC4-6 NJM2904E-ZB ANALOGUE IC
IC7 S-8130AC MOS-IC
IC8 NJM2904E-ZB ANALOGUE IC
IC9 S24CS02AFJTBG ROM IC
IC10 1A RA13H4452M101 MOS-IC
IC11 1B NJM7808FA-ZB BI-POLAR IC
IC12 1B NJM7805FA-ZB BI-POLAR IC
IC15 NJM2904E-ZB ANALOGUE IC
IC701 NJM78L05UA-ZB BI-POLAR IC
IC702 LTC1046IS8 MOS-IC
IC703 TK72130CS BI-POLAR IC
Q2 SSM3K15TE(F) FET
Q3 SSM3J01F FET
Q4 2SJ506-E(S) FET
Q5,6 SSM3K15TE(F) FET
Q8 SSM3K15TE(F) FET
Q14 SSM3K15TE(F) FET
C1-5 CK73GB1H102K CHIP C 1000PF K
C6 CC73GCH1H101J CHIP C 100PF J
C7 CK73GB1H102K CHIP C 1000PF K
C8 CC73GCH1H101J CHIP C 100PF J
C9 CK73GB1H102K CHIP C 1000PF K
C10 CC73GCH1H101J CHIP C 100PF J
C12-16 CK73GB1H102K CHIP C 1000PF K
C18-28 CK73GB1H102K CHIP C 1000PF K
C29 CC73GCH1H101J CHIP C 100PF J
C30-33 CK73GB1H102K CHIP C 1000PF K
C34 CC73GCH1H101J CHIP C 100PF J
C35 CK73GB1H102K CHIP C 1000PF K
C36 CC73GCH1H101J CHIP C 100PF J
C37 CK73GB1H104K CHIP C 0.10UF K
C39-47 CK73GB1H102K CHIP C 1000PF K
C49 CC73GCH1H101J CHIP C 100PF J
C50-53 CK73GB1H102K CHIP C 1000PF K
C54 CC73GCH1H101J CHIP C 100PF J
C55 CK73GB1H102K CHIP C 1000PF K
C56 CC73GCH1H101J CHIP C 100PF J
C57 CK73GB1H102K CHIP C 1000PF K
C58 CC73GCH1H101J CHIP C 100PF J
C60-62 CK73GB1H102K CHIP C 1000PF K
C63 CK73GB1H104K CHIP C 0.10UF K
C64 CK73GB1H102K CHIP C 1000PF K
CONTROL UNIT (X53-4130-11 for service)
If a part reference number is listed in a shaded box, that part does not come with the PCB.
