Kenwood NXR-800 Service Manual Supplement

NXR-800
10
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
FINAL UNIT (X45-3820-XX)
C87 CC73GCH1H080D CHIP C 8.0PF D K2
C87 CC73GCH1H120J CHIP C 12PF J K
C88-90 CK73GB1H471K CHIP C 470PF K
C94,95 CK73GB1H104K CHIP C 0.10UF K
C96-102 CK73GB1H471K CHIP C 470PF K
C104 CK73GB1H471K CHIP C 470PF K
C105 C93-0568-05 CHIP C 47PF J K2
C105 C93-0599-05 CHIP C 470PF K K
C106 CK73GB1H471K CHIP C 470PF K
C108,109 CK73GB1H471K CHIP C 470PF K
C111 C93-0552-05 CHIP C 2.0PF C
C112 CK73GB1H471K CHIP C 470PF K
C113,114 CK73GB1H472K CHIP C 4700PF K
C115 CK73GB1H471K CHIP C 470PF K
C117 CK73GB1H103K CHIP C 0.010UF K
C119 CC73GCH1H040C CHIP C 4.0PF C K
C119 CC73GCH1H050C CHIP C 5.0PF C K2
C122 C93-0562-05 CHIP C 15PF J K2
C122 C93-0572-05 CHIP C 100PF J K
C123 C93-0566-05 CHIP C 33PF J K
C123 C93-0567-05 CHIP C 39PF J K2
C124 CK73GB1H471K CHIP C 470PF K
C126 C93-0554-05 CHIP C 4.0PF C K
C127,128 CK73GB1H471K CHIP C 470PF K
C130 C93-0557-05 CHIP C 7.0PF D K2
C131 C93-0557-05 CHIP C 7.0PF D K
C132 C93-0556-05 CHIP C 6.0PF D K2
C133,134 CK73GB1H471K CHIP C 470PF K
C137 C93-0554-05 CHIP C 4.0PF C K2
C138 CE32CL1V100M CHIP EL 10UF 35WV
C141 C93-0599-05 CHIP C 470PF K
C147 C93-0557-05 CHIP C 7.0PF D K
C148 C93-0553-05 CHIP C 3.0PF C K2
C149 C93-0556-05 CHIP C 6.0PF D K2
C149 C93-0557-05 CHIP C 7.0PF D K
C150 CK73GB1H104K CHIP C 0.10UF K
C158 C93-0552-05 CHIP C 2.0PF C K
C159 C93-0553-05 CHIP C 3.0PF C K
C161 CC73FCH1H102J CHIP C 1000PF J K2
C161 CC73FCH1H220J CHIP C 22PF J K
C162 CK73GB1H104K CHIP C 0.10UF K
C167 CK73GB1H104K CHIP C 0.10UF K
C169,170 CK73GB1H471K CHIP C 470PF K
C187,188 C92-0905-05 OS-CON 47UF 35WV
C189 CK73GB1H103K CHIP C 0.010UF K
C190 CK73GB1H471K CHIP C 470PF K
C191 CK73GB1E105K CHIP C 1.0UF K
C193 CC73FCH1H101J CHIP C 100PF J K2
C701 CK73GB1E105K CHIP C 1.0UF K
C702,703 CK73GB1H471K CHIP C 470PF K
C704 CE32AU1E100M CHIP EL 10UF 25WV
C705 CK73GB1E105K CHIP C 1.0UF K
C706,707 CK73GB1H471K CHIP C 470PF K
C708 CE32CL1V100M CHIP EL 10UF 35WV
C709 CE32AU1C330M CHIP EL 33UF 16WV
C710 CK73GB1H104K CHIP C 0.10UF K
C711 CS77CB21C100M CHIP TNTL 10UF 16WV
C712 CE32AU1C330M CHIP EL 33UF 16WV
C713,714 CK73GB1H104K CHIP C 0.10UF K
C715 CE32AU1C330M CHIP EL 33UF 16WV
C716 CK73GB1H104K CHIP C 0.10UF K
C717,718 CK73GB1H471K CHIP C 470PF K
C900 CK73GB1H104K CHIP C 0.10UF K
C901 CK73GB1H102K CHIP C 1000PF K
C902 CC73GCH1H101J CHIP C 100PF J
C904 CC73GCH1H101J CHIP C 100PF J
C905 CK73FB0J106K CHIP C 10UF K
C906-908 CK73GB1H102K CHIP C 1000PF K
C909,910 CC73GCH1H101J CHIP C 100PF J
C912,913 CC73GCH1H101J CHIP C 100PF J
C914 CK73GB1H104K CHIP C 0.10UF K
C915 CC73GCH1H101J CHIP C 100PF J
C916 CK73GB1H102K CHIP C 1000PF K
CN1 E04-0193-05 PIN SOCKET
CN2 E23-0902-05 TERMINAL
CN8 E41-2671-05 PIN ASSY
CN11 E41-2673-05 PIN ASSY
CN12 E41-2672-05 PIN ASSY
CN15 E41-2672-05 PIN ASSY
CN19 E04-0193-05 PIN SOCKET
CN20 E40-6656-05 PIN ASSY
CN701 E41-2741-05 PIN ASSY
CN905 E41-1483-05 PIN ASSY
J901 E58-0526-05 MODULAR JACK
CN4 J13-0071-05 FUSE HOLDER
L1 L92-0179-05 CHIP FERRITE
L3 L79-0558-05 FILTER
L4 L92-0131-05 CHIP FERRITE
L5 L34-4518-05 AIR-CORE COIL K
L9 L34-4638-05 AIR-CORE COIL
L10 L34-4605-05 AIR-CORE COIL
L12 L34-4518-05 AIR-CORE COIL
L13-15 L34-4517-05 AIR-CORE COIL
L17 L34-4523-05 AIR-CORE COIL
L701,702 L41-4705-33 SMALL FIXED INDUCTOR (47UH)
L703,704 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L900 L92-0447-05 BEADS CORE
CP1 RK75GB1J103J CHIP-COM 10K J 1/16W
R1 RK73FB2B271J CHIP R 270 J 1/8W
R2 RK73FB2B180J CHIP R 18 J 1/8W
R3 RK73FB2B271J CHIP R 270 J 1/8W
R4 R92-3604-05 CHIP R 0.047 D 1.0W
R9 RK73GB2A101J CHIP R 100 J 1/10W
R11 RS14DB3A4R7J
FL-PROOF RS 4.7 J 1W
R12,13 RK73GB2A103J CHIP R 10K J 1/10W
R15 RK73GB2A332J CHIP R 3.3K J 1/10W
R17 RK73GB2A103J CHIP R 10K J 1/10W
R18 RK73GB2A473J CHIP R 47K J 1/10W
R20 RK73GB2A104J CHIP R 100K J 1/10W
R21,22 RK73GB2A184J CHIP R 180K J 1/10W
R23 RK73FB2B000J CHIP R 0.0 J 1/8W
R25 RK73GB2A104J CHIP R 100K J 1/10W
R26 RK73EB2E101J CHIP R 100 J 1/4W
R27 RK73GB2A224J CHIP R 220K J 1/10W
R28 RK73GB2A474J CHIP R 470K J 1/10W
R29,30 RK73GB2A103J CHIP R 10K J 1/10W
R31-33 RK73GB2A104J CHIP R 100K J 1/10W
