Kenwood NXR-800 Service Manual Supplement

NXR-800
✽
New Parts.
indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L : Scandinavia K : USA P : Canada
Y : PX (Far East, Hawaii) T : England E : Eu rope
Y : AAFES (Europe) X : Australia M : Oth er Areas
9
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
1 3A A62-1142-02 MAIN PANEL
3 1E B10-2781-04 FRONT GLASS ACCESSORY
4 3A B11-1841-04 FILTER (PF)
5 3A B11-1842-04 FILTER (17SEG)
6 3A B11-1843-04 FILTER (LED)
7 3A B11-1844-04 FILTER (STATUS)
8 3A B42-7296-04 STICKER (NEXEDGE)
9 3A B43-1188-04 BADGE
10 1F
✽
B62-1994-10 INSTRUCTION MANUAL
12 2B E04-0463-05 RF COAXIAL RECEPTACLE (BNC)
13 1F E30-3344-25 DC CORD ACCESSORY
14 1B E30-7581-05 DC CORD
15 2C E30-7582-05 TRUNK CABLE
16 1B,2C E30-7583-05 TRUNK CABLE
17 1B,1C E37-1295-05 FLAT CABLE (36P)
18 1B E37-1299-05
LEAD WIRE WITH TERMINAL (FUSE-DC +)
19 1B E37-1300-05 LEAD WIRE WITH TERMINAL (FUSE-DC-)
20 1B E37-1301-05 LEAD WIRE WITH TERMINAL (DC-PA +)
21 1B E37-1302-05 LEAD WIRE WITH TERMINAL (DC-PA-)
22 2C E37-1303-05
LEAD WIRE WITH CONNECTOR (BNC-RX)
23 2D E37-1304-05 LEAD WIRE WITH CONNECTOR (BNC-TX)
24 1B E37-1305-05 LEAD WIRE WITH CONNECTOR (DC-TX)
25 1C E37-1306-05 LEAD WIRE WITH CONNECTOR (DC-CONT)
26 2C E37-1307-05 LEAD WIRE WITH CONNECTOR (DC-RX)
27 2D E37-1308-05 LEAD WIRE WITH CONNECTOR (RX-DCDC)
28 1D E37-1310-05 LEAD WIRE WITH CONNECTOR (DSUB-25P)
29 3B E37-1311-05 LEAD WIRE WITH CONNECTOR (DSUB-9P)
30 2D E37-1313-05 LEAD WIRE WITH CONNECTOR (ACC15P)
31 3B E37-1314-05 LEAD WIRE WITH CONNECTOR (DISP-MIC)
32 3B E37-1315-05 LEAD WIRE WITH CONNECTOR (DISP-17SEG)
33 2B E37-1316-05 LEAD WIRE WITH CONNECTOR (SP)
34 1E E37-1381-05 15P PLUG ACCESSORY
36 1D,1E F05-7521-05 BLADE FUSE (7.5A/32V) ACCESSORY
37 2A F07-1930-05 COVER (FAN)
38 1D F09-0445-05 CAP (25P)
39 3B F09-0484-05 CAP (9P)
40 2A F09-0488-05 FANMOTOR
42 3A G10-1343-04 FIBROUS SHEET (FRONT PANEL)
43 2B G11-4408-04 RUBBER SHEET (CONT-TR)
44 3A G13-2163-04 CUSHION (PF)
46 3B J19-5496-02 HOLDER (DISP)
47 1C J19-5497-05 HOLDER (COMPACT FLASH)
48 1E J29-0725-04 BRACKET (SIDE)
49 3A J39-0655-03 SPACER (SP)
50 2D J61-0307-05 BAND (DC)
52 1E K01-0421-05 HANDLE ACCESSORY
53 3A K29-4539-04 KNOB (VOLUME)
55 1F L79-1419-05 LINE FILTER (DC)
A 1E N08-0563-04 DRESSED SCREW (FRONT GLASS)
B 3B,1D N09-2292-05 HEXAGON HEAD SCREW (DSUB)
C 1C N30-2008-43 PAN HEAD MACHINE SCREW (CF)
D 2C,1D N30-2606-48 PAN HEAD MACHINE SCREW (BNC)
E 2A N30-3016-43 PAN HEAD MACHINE SCREW (FAN)
F 2D,3D N32-3006-43
FLAT HEAD MACHINE SCREW (TOP,REAR)
G 3A,1E N32-4008-43 FLAT HEAD MACHINE SCREW (PANEL)
H 1B,1C N67-3008-48 PAN HEAD SEMS SCREW (AVR)
J 3B N80-2006-43 PAN HEAD TAPTITE SCREW (DISP)
K 1D N80-2608-43 PAN HEAD TAPTITE SCREW (FUSE)
L 1B,2C N87-2608-48 BRAZIER HEAD TAPTITE SCREW (PCB)
57 3A T07-0347-15 SPEAKER
C1,2 CD04BD1H101M ELECTRO 100UF 50WV
C7,8 CE32BM1V220M CHIP EL 22UF 35WV
C10,11 CK73GB1H471K CHIP C 470PF K
C15-17 CK73GB1H103K CHIP C 0.010UF K
C21 CK73GB1H471K CHIP C 470PF K
C25,26 CK73GB1H103K CHIP C 0.010UF K
C29,30 CK73GB1H471K CHIP C 470PF K
C32 CE32BM1V220M CHIP EL 22UF 35WV
C33 CE32AU1E100M CHIP EL 10UF 25WV
C36 CK73GB1H471K CHIP C 470PF K
C37 CK73GB1H103K CHIP C 0.010UF K
C38 CE32AU1E100M CHIP EL 10UF 25WV
C39 CK73GB1H471K CHIP C 470PF K
C40 CK73GB1H103K CHIP C 0.010UF K
C41,42 CK73GB1H471K CHIP C 470PF K
C44 CE32CL1V100M CHIP EL 10UF 35WV
C45,46 CK73GB1H471K CHIP C 470PF K
C47 CK73GB1H103K CHIP C 0.010UF K
C49 CK73GB1H104K CHIP C 0.10UF K
C50-52 CK73GB1H471K CHIP C 470PF K
C53 CK73GB1H103K CHIP C 0.010UF K
C54 CK73GB1H471K CHIP C 470PF K
C58 CK73GB1H471K CHIP C 470PF K
C59 CK73GB1H103K CHIP C 0.010UF K
C60 C93-0572-05 CHIP C 100PF J K
C60 C93-0599-05 CHIP C 470PF K K2
C61 CK73GB1H471K CHIP C 470PF K
C62 CK73GB1H103K CHIP C 0.010UF K
C63-65 CK73GB1H471K CHIP C 470PF K
C67 CK73GB1H471K CHIP C 470PF K
C68 CE32CL1V100M CHIP EL 10UF 35WV
C70 CK73GB1H103K CHIP C 0.010UF K
C71-75 CK73GB1H471K CHIP C 470PF K
C77,78 CK73GB1H471K CHIP C 470PF K
C80 CK73GB1H103K CHIP C 0.010UF K
C82 CK73GB1H104K CHIP C 0.10UF K
C83 CK73GB1H471K CHIP C 470PF K
C85 CC73GCH1H080D CHIP C 8.0PF D
C86 CK73GB1H103K CHIP C 0.010UF K
NXR-800
FINAL UNIT (X45-3820-XX) -10 : K -11 : K2
NXR-800 (Y54-3250-XX)
FINAL UNIT (X45-3820-XX)
