NXR-800
28
Ref. No.
Ad dress
Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No.
Ad dress
Parts No. Description
Desti-
nation
New
parts
R417 RK73GB2A000J CHIP R 0.0 J 1/10W
R430,431 RK73GB2A331J CHIP R 330 J 1/10W
R432 RK73GB2A103J CHIP R 10K J 1/10W
R435 RK73GB2A473J CHIP R 47K J 1/10W
R436 RK73GB2A392J CHIP R 3.9K J 1/10W K
R436 RK73GB2A472J CHIP R 4.7K J 1/10W K2
R437 RK73GB2A183J CHIP R 18K J 1/10W
R438 RK73GB2A273J CHIP R 27K J 1/10W
R450 RK73GB2A000J CHIP R 0.0 J 1/10W K
R451 RK73GB2A000J CHIP R 0.0 J 1/10W K2
R455 RK73GB2A104J CHIP R 100K J 1/10W
R456,457 RK73GB2A470J CHIP R 47 J 1/10W K2
D1,2 HSC119 DIODE
D3-6 1SV283F VARIABLE CAPACITANCE DIODE
D9,10 JDP4P02U DIODE
D11 KV1470-G VARIABLE CAPACITANCE DIODE
D12 1SV283F VARIABLE CAPACITANCE DIODE
D13,14 JDP4P02U DIODE
D15,16 DAN235E DIODE
D17,18 MA3J742 DIODE
D19,20 DAN235E DIODE
IC4 TA75S01F-F MOS-IC
IC5 ADF4111BCP7 MOS-IC
IC6 LMC7101BIM5 MOS-IC
IC7 AD9835BRUZ MOS-IC
IC8
✽
NJU6368PF1 MOS-IC
IC9 UPB1509GV BI-POLAR IC
IC10 TK11230CMCL-G BI-POLAR IC
IC11 ADF4111BCP7 MOS-IC
IC12 TA31137FNG MOS-IC
IC13 AD607Z BI-POLAR IC
IC14 AD8051ART ANALOGUE IC
IC15,16 NJM78L05UA-ZB BI-POLAR IC
IC17-19 NJM78M05DL1AZB ANALOGUE IC
IC20 NJM4558E-ZB ANALOGUE IC
IC22 XC6204B332M MOS-IC
IC23 BH2220FVM ANALOGUE IC
IC24,25 2D NJM7808FA-ZB BI-POLAR IC
IC26,27 NJM2386ADL3-09 ANALOGUE IC
IC28 AD1582 ANALOGUE IC
IC29 NJM2732V BI-POLAR IC
IC30 AD7908BRU MOS-IC
IC31 S24CS02AFJTBG ROM IC
IC32 NJM2732V BI-POLAR IC
IC33 LMC7101BIM5 MOS-IC
IC35 LM50BIM3/NOPB MOS-IC
Q1 2SC5337 TRANSISTOR
Q2 2SC4116(BL)F TRANSISTOR
Q3 2SC4617(R) TRANSISTOR
Q4 2SC4116(BL)F TRANSISTOR
Q5 2SC4617(R) TRANSISTOR
Q6 2SC4116(BL)F TRANSISTOR
Q7,8 2SK508NV(K53) FET
Q9-11 2SC4116(BL)F TRANSISTOR
Q12 2SC4617(R) TRANSISTOR
Q13
✽
2SA1832F TRANSISTOR
Q14,15 SSM3K15TE(F) FET
Q16,17 2SC3356-A(R24) TRANSISTOR
Q18-20 RD01MUS1-T113 FET
Q21 2SC4725 TRANSISTOR
Q22 2SC4617(R) TRANSISTOR
Q23 2SC3356-A(R24) TRANSISTOR
Q24 2SK508NV(K52) FET
Q25 SSM3J01F FET
Q26 SSM3K15TE(F) FET
Q27 2SC4116(BL)F TRANSISTOR
Q28,29 3SK317-E FET
Q30 2SC4617(R) TRANSISTOR
Q31 SSM3K15TE(F) FET
Q32 SSM3J01F FET
Q33 2SC4725 TRANSISTOR
Q34
✽
2SA1832F TRANSISTOR
Q35,36 2SC4725 TRANSISTOR
Q37 SSM3K15TE(F) FET
Q38 2SC4725 TRANSISTOR
Q39 2SC4617(R) TRANSISTOR
Q40 2SC4617(S) TRANSISTOR
Q50,51 SSM3K15TE(F) FET
Q52 2SJ484 FET
Q53 2SC4725 TRANSISTOR
Q56 SSM3K15TE(F) FET
Q57 DTA144EE DIGITAL TRANSISTOR
Q58-61 SSM3K15TE(F) FET
TH2,3
✽
157-103-53007 THERMISTOR K2
A1 W02-1940-05 DBM
- 212-1514-05 INSULATING TUBE
D202 B30-2230-05 LED (YG)
D301 B30-2230-05 LED (YG)
D920-924 B30-2265-05 LED (BR/PG)
D925-932 B30-2171-05 LED (D)
C101 CS77CA1ER47M CHIP TNTL 0.47UF 25WV K
C101 CS77CA1VR33M CHIP TNTL 0.33UF 35WV K2
C102 CK73GB1E105K CHIP C 1.0UF K
C103-105 CC73GCH1H471J CHIP C 470PF J
C106,107 CK73GB1H103K CHIP C 0.010UF K
C108 CC73GCH1H471J CHIP C 470PF J
C109 CK73GB1H104K CHIP C 0.10UF K
C110 CC73GCH1H471J CHIP C 470PF J
C111,112 CK73GB1H104K CHIP C 0.10UF K
C113 CC73GCH1H471J CHIP C 470PF J
C114 CK73GB1H104K CHIP C 0.10UF K
C115-117 CC73GCH1H471J CHIP C 470PF J
C120 CK73GB1H103K CHIP C 0.010UF K
C122 CC73GCH1H471J CHIP C 470PF J
C123 CS77CA1VR22M CHIP TNTL 0.22UF 35WV
C124 CS77CC1C330M CHIP TNTL 33UF 16WV
C126 CC73GCH1H471J CHIP C 470PF J
C132 CC73GCH1H090B CHIP C 9.0PF B
C133 CC73GCH1H070D CHIP C 7.0PF D
C134 CC73GCH1H070B CHIP C 7.0PF B K2
C134 CC73GCH1H090B CHIP C 9.0PF B K
C135 CC73GCH1H471J CHIP C 470PF J
C136 CC73GCH1H060B CHIP C 6.0PF B K2
C136 CC73GCH1H070B CHIP C 7.0PF B K
TX UNIT (X56-3120-XX) -10 : K -11 : K2
If a part reference number is listed in a shaded box, that part does not come with the PCB.
RX UNIT (X55-3100-XX)
TX UNIT (X56-3120-XX)
To Next Page
