Kenwood NXR-800 Service Manual Supplement

NXR-800
33
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
TX UNIT (X56-3120-XX)
CP973,974 RK74GB1J681J CHIP-COM 680 J 1/16W
R101 RK73GB2A000J CHIP R 0.0 J 1/10W
R118 RK73GB2A000J CHIP R 0.0 J 1/10W
R119 RK73GB2A101J CHIP R 100 J 1/10W K2
R119 RK73GB2A820J CHIP R 82 J 1/10W K
R120 RK73GB2A151J CHIP R 150 J 1/10W
R123 RK73GB2A000J CHIP R 0.0 J 1/10W
R124,125 RK73GB2A105J CHIP R 1.0M J 1/10W
R129 RK73GB2A101J CHIP R 100 J 1/10W
R131 RK73GB2A101J CHIP R 100 J 1/10W
R132 RK73GB2A181J CHIP R 180 J 1/10W K
R132 RK73GB2A221J CHIP R 220 J 1/10W K2
R133 RK73GB2A470J CHIP R 47 J 1/10W
R134 RK73GB2A220J CHIP R 22 J 1/10W
R135 RK73GB2A272J CHIP R 2.7K J 1/10W
R137 RK73GB2A102J CHIP R 1.0K J 1/10W
R138 RK73GB2A103J CHIP R 10K J 1/10W
R139 RK73GB2A102J CHIP R 1.0K J 1/10W
R141 RK73GB2A101J CHIP R 100 J 1/10W
R142 RK73GB2A221J CHIP R 220 J 1/10W
R144,145 RK73GB2A000J CHIP R 0.0 J 1/10W
R146 RK73GB2A271J CHIP R 270 J 1/10W
R147 RK73GB2A180J CHIP R 18 J 1/10W
R148 RK73GB2A271J CHIP R 270 J 1/10W
R149 RK73GB2A221J CHIP R 220 J 1/10W
R150 RK73GB2A820J CHIP R 82 J 1/10W
R151 RK73GB2A101J CHIP R 100 J 1/10W
R152 RK73GB2A000J CHIP R 0.0 J 1/10W
R153 RK73GB2A271J CHIP R 270 J 1/10W
R154 RK73GB2A180J CHIP R 18 J 1/10W
R155 RK73GB2A682J CHIP R 6.8K J 1/10W
R156 RK73GB2A182J CHIP R 1.8K J 1/10W
R157 RK73GB2A271J CHIP R 270 J 1/10W
R158 RK73GB2A103J CHIP R 10K J 1/10W
R159-161 RK73GB2A104J CHIP R 100K J 1/10W
R164 RK73GB2A104J CHIP R 100K J 1/10W
R165-168 RK73GB2A102J CHIP R 1.0K J 1/10W
R170 RK73GB2A000J CHIP R 0.0 J 1/10W
R171,172 RK73GB2A470J CHIP R 47 J 1/10W
R173,174 RK73GB2A102J CHIP R 1.0K J 1/10W
R176 RK73GB2A000J CHIP R 0.0 J 1/10W
R178 RK73GB2A000J CHIP R 0.0 J 1/10W
R179 RK73GB2A224J CHIP R 220K J 1/10W K
R179 RK73GB2A334J CHIP R 330K J 1/10W K2
R180 RK73GB2A101J CHIP R 100 J 1/10W
R181 RK73GB2A184J CHIP R 180K J 1/10W
R182 RK73GB2A101J CHIP R 100 J 1/10W
R183 RK73GB2A181J CHIP R 180 J 1/10W K
R183 RK73GB2A221J CHIP R 220 J 1/10W K2
R184 RK73GB2A470J CHIP R 47 J 1/10W
R185,186 RK73GB2A103J CHIP R 10K J 1/10W
R187,188 RK73GB2A000J CHIP R 0.0 J 1/10W
R189-191 RK73GB2A103J CHIP R 10K J 1/10W
R201 RK73GB2A121J CHIP R 120 J 1/10W
R202 RK73GB2A470J CHIP R 47 J 1/10W
R203 RK73GB2A121J CHIP R 120 J 1/10W
R204 RK73GB2A103J CHIP R 10K J 1/10W
R205 RK73GB2A272J CHIP R 2.7K J 1/10W
R206 RK73GB2A181J CHIP R 180 J 1/10W
R207 RK73GB2A121J CHIP R 120 J 1/10W
R208 RK73GB2A101J CHIP R 100 J 1/10W
R210 RK73GB2A000J CHIP R 0.0 J 1/10W
R212 RK73GB2A562J CHIP R 5.6K J 1/10W
R213 RK73GB2A152J CHIP R 1.5K J 1/10W
R215 RK73GB2A000J CHIP R 0.0 J 1/10W
R216 RK73GB2A470J CHIP R 47 J 1/10W
R218 RK73GB2A000J CHIP R 0.0 J 1/10W
R220 RK73GB2A392J CHIP R 3.9K J 1/10W
R221 RK73GB2A103J CHIP R 10K J 1/10W
R222 RK73GB2A000J CHIP R 0.0 J 1/10W
R223 RK73GB2A123J CHIP R 12K J 1/10W
R224 RK73GB2A221J CHIP R 220 J 1/10W
R225 RK73GB2A474J CHIP R 470K J 1/10W
R226 RK73GB2A220J CHIP R 22 J 1/10W
R227 RK73GB2A000J CHIP R 0.0 J 1/10W
R229 RK73GB2A563J CHIP R 56K J 1/10W
R230 RK73FB2B4R7J CHIP R 4.7 J 1/8W
R231,232 RK73GB2A000J CHIP R 0.0 J 1/10W
R233 RK73GB2A104J CHIP R 100K J 1/10W
R234,235 RK73GB2A474J CHIP R 470K J 1/10W
R236 RK73GB2A821J CHIP R 820 J 1/10W
R241 RK73GB2A000J CHIP R 0.0 J 1/10W
R242 RK73GB2A474J CHIP R 470K J 1/10W
R243 RK73GB2A392J CHIP R 3.9K J 1/10W
R244-246 RK73GB2A102J CHIP R 1.0K J 1/10W
R247-249 RK73GB2A104J CHIP R 100K J 1/10W
R250 RK73GB2A474J CHIP R 470K J 1/10W
R251 RK73GB2A100J CHIP R 10 J 1/10W
R252 RK73GB2A104J CHIP R 100K J 1/10W
R253 RK73GB2A331J CHIP R 330 J 1/10W
R254 RK73GB2A100J CHIP R 10 J 1/10W
R255 RK73GB2A274J CHIP R 270K J 1/10W
R256 RK73GB2A102J CHIP R 1.0K J 1/10W
R257,258 RK73GB2A000J CHIP R 0.0 J 1/10W
R259 RK73GB2A562J CHIP R 5.6K J 1/10W
R260 RK73GB2A331J CHIP R 330 J 1/10W
R261 RK73GB2A562J CHIP R 5.6K J 1/10W
R262 RK73GB2A102J CHIP R 1.0K J 1/10W
R263 RK73GB2A563J CHIP R 56K J 1/10W
R264 RK73GB2A100J CHIP R 10 J 1/10W
R265 RK73GB2A471J CHIP R 470 J 1/10W
R266 RK73GB2A000J CHIP R 0.0 J 1/10W
R267 RK73GB2A271J CHIP R 270 J 1/10W
R268 RK73GB2A180J CHIP R 18 J 1/10W
R269 RK73GB2A271J CHIP R 270 J 1/10W
R270,271 RK73GB2A472J CHIP R 4.7K J 1/10W
R272 RK73GB2A100J CHIP R 10 J 1/10W
R274 RK73GB2A221J CHIP R 220 J 1/10W
R276 RK73GB2A000J CHIP R 0.0 J 1/10W
R301,302 RK73GB2A473J CHIP R 47K J 1/10W
R303 RK73GB2A000J CHIP R 0.0 J 1/10W
R304 RK73GB2A471J CHIP R 470 J 1/10W
R305 RK73GB2A104J CHIP R 100K J 1/10W
R306-309 RK73GB2A102J CHIP R 1.0K J 1/10W
R310,311 RK73GB2A104J CHIP R 100K J 1/10W
R312 RK73GB2A154J CHIP R 150K J 1/10W
R313 RK73GB2A2R2J CHIP R 2.2 J 1/10W
R314 RK73GB2A000J CHIP R 0.0 J 1/10W
R316 RK73GB2A273J CHIP R 27K J 1/10W K
R316 RK73GB2A393J CHIP R 39K J 1/10W K2
