Kenwood NXR-800 Service Manual Supplement

NXR-800
32
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
New
parts
TX UNIT (X56-3120-XX)
C920-925 CK73GB1H104K CHIP C 0.10UF K
C926 CK73GB1H102K CHIP C 1000PF K
C928,929 CK73GB1H104K CHIP C 0.10UF K
C930,931 CK73GB1E105K CHIP C 1.0UF K
C932 CC73GCH1H470J CHIP C 47PF J
C933,934 CS77CA1A1R5M CHIP TNTL 1.5UF 10WV
C935,936 CK73GB1H104K CHIP C 0.10UF K
C937 CK73GB1H103K CHIP C 0.010UF K
C938 CK73FB0J106K CHIP C 10UF K
C939 CK73GB1H102K CHIP C 1000PF K
C941 CK73GB1H102K CHIP C 1000PF K
C943 CK73GB1H104K CHIP C 0.10UF K
C960-965 CK73GB1H104K CHIP C 0.10UF K
CN102-121 E23-1280-05 TERMINAL
CN130 E23-1330-05 TERMINAL
CN403 E04-0193-05 PIN SOCKET
CN405,406 E04-0193-05 PIN SOCKET
CN407 E04-0154-05 PIN SOCKET
CN408 E04-0193-05 PIN SOCKET
CN801 E41-2672-05 PIN ASSY
CN802 E04-0193-05 PIN SOCKET
CN803 E40-6822-05 FLAT CABLE CONNECTOR
CN804-806 E40-6656-05 PIN ASSY
CN807 E41-2671-05 PIN ASSY
CN920 E41-1493-05 PIN ASSY
CN921 E40-6656-05 PIN ASSY
CN923 E41-1483-05 PIN ASSY
CN960 E41-1493-05 PIN ASSY
E100 F10-3081-04 SHIELDING CASE
CF201 L72-1029-05 CERAMIC FILTER
CF601 L72-1019-05 CERAMIC FILTER
L105,106 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L108 L34-4545-05 AIR-CORE COIL
L109-111 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L112,113 L41-1875-33 SMALL FIXED INDUCTOR (0.018UH)
L116-119 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH) K
L116-120 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH) K2
L120 L41-2275-33 SMALL FIXED INDUCTOR (0.022UH) K
L121-124 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L125,126 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L128 L34-4545-05 AIR-CORE COIL
L129-131 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L201,202 L41-1275-33 SMALL FIXED INDUCTOR (0.012UH) K2
L201,202 L41-1575-33 SMALL FIXED INDUCTOR (0.015UH) K
L203,204 L41-1075-33 SMALL FIXED INDUCTOR (0.01UH) K2
L203,204 L41-1275-33 SMALL FIXED INDUCTOR (0.012UH) K
L205 L34-4603-05 AIR-CORE COIL K2
L205 L34-4604-05 AIR-CORE COIL K
L207 L34-4607-05 AIR-CORE COIL
L208 L34-4606-05 AIR-CORE COIL
L210 L41-1595-33 SMALL FIXED INDUCTOR (1.5UH)
L211 L41-1895-33 SMALL FIXED INDUCTOR (1.8UH)
L212,213 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L214,215 L41-4705-33 SMALL FIXED INDUCTOR (47UH)
L216,217 L41-2295-33 SMALL FIXED INDUCTOR (2.2UH)
L218 L41-6885-33 SMALL FIXED INDUCTOR (0.68UH)
L219 L41-6895-33 SMALL FIXED INDUCTOR (6.8UH)
L301 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L302 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L303 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L304 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L305 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L306 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L307,308 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L309 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L310 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L311 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L312 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L313 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L314 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L401-403 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L404 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L405 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L406 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L407 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L408 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L409,410 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L411 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L412 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L413 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L414,415 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L416,417 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L418 L41-5685-33 SMALL FIXED INDUCTOR (0.56UH)
L419,420 L41-6885-33 SMALL FIXED INDUCTOR (0.68UH)
L421 L41-5685-33 SMALL FIXED INDUCTOR (0.56UH)
L422 L39-1517-05 TOROIDAL COIL
L423 L41-3305-33 SMALL FIXED INDUCTOR (33UH)
L424 L39-1517-05 TOROIDAL COIL
L425 L41-3305-33 SMALL FIXED INDUCTOR (33UH)
L426,427 L39-1517-05 TOROIDAL COIL
L430 L41-5685-33 SMALL FIXED INDUCTOR (0.56UH)
L431 L41-6885-33 SMALL FIXED INDUCTOR (0.68UH)
L433,434 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L435 L41-2205-33 SMALL FIXED INDUCTOR (22UH)
L601,602 L41-3305-33 SMALL FIXED INDUCTOR (33UH)
L603,604 L41-4705-33 SMALL FIXED INDUCTOR (47UH)
L605 L41-2205-33 SMALL FIXED INDUCTOR (22UH)
L606,607 L41-1205-33 SMALL FIXED INDUCTOR (12UH)
L608 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L609 L92-0140-05 CHIP FERRITE
L610 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L611 L92-0140-05 CHIP FERRITE
L612 L41-3385-33 SMALL FIXED INDUCTOR (0.33UH)
L613 L41-3985-33 SMALL FIXED INDUCTOR (0.39UH)
L614 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
L801 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L812 L41-1005-33 SMALL FIXED INDUCTOR (10UH)
X301 L77-1981-05 VCXO (19.2MHZ)
X401 L77-1981-05 VCXO (19.2MHZ)
X601 L77-3034-05 TCXO (19.2MHZ)
CP920 RK74GB1J102J CHIP-COM 1.0K J 1/16W
CP923 RK74GB1J102J CHIP-COM 1.0K J 1/16W
CP924 RK75GB1JR00 CHIP-COM 0.00 1/16W
CP926 RK74GB1J681J CHIP-COM 680 J 1/16W
CP928 RK74GB1J681J CHIP-COM 680 J 1/16W
CP961,962 RK74GB1J681J CHIP-COM 680 J 1/16W
CP965,966 RK74GB1J681J CHIP-COM 680 J 1/16W
CP970,971 RK74GB1J681J CHIP-COM 680 J 1/16W
