Specifications of PW26-1AT(S)
ATS is with a remote sensing terminal to C channel
ITEMS A Channel B Channel C Channel
Output voltage 0 to +26 V 0 to -26 V 0 to +6 V
Voltage setting resolution 10 mV 1 mV
±( 0.5% SET +20 mV ) ±( 0.5% SET +5
mV )
Voltage setting accuracy
At 23 ±5°C after 30-minute aging
Output current 0 to +1 A 0 to -1 A 0 to +5 A
Current setting resolution 1 mA
±( 1% SET +5 mA ) Current setting accuracy
At 23 ±5°C after 30-m
inute aging
CV characteristics
1 mV Input variation
( For ±10% variation of source voltage)
2 mV Load variation
( For 0 to 100% variation )
0.5 mV Ripple noise
Measured in the RMS method using 5 Hz to 1 MHz signals.
Transient response 50 µs ( typ. )
Temperature coefficient 60 ppm/°C ( at rated output voltage )
CC characteristics
2 mA Input variation
( For ±10% variation of source voltage)
5 mA Load variation
( For 0 to 100% variation )
1.5 mA
Ripple noise
Measured in the RM S method using 5 Hz t o 1 MHz
signals.
Temperature coefficient 150 ppm/°C ( at rated output current )
Voltage & current indication
Voltage indicator 4-digit red LEDs, lowest digit: 10 mV
4- digit red LEDs,
lowest digit: 1 mV
±( 0.5% rdg + 20 mV )/ 10 mV ±( 0.5% rdg + 5
mV )/ 1 mV
Voltage indication
accuracy & resolution
At 23 ±5°C after 30-minute aging
Current indicator 4-digit red LEDs, lowest digit: 1 mA
±( 1% rdg + 5 mA )/ 1 mA Current indication
accuracy & resolution
At 23 ±5°C after 30-m inute aging
Voltage & current
indication range
-2.5% FS to +102.5% FS /0% FS to +102.5% FS
Common Common Independent
Power consumption Approx. 220 W, 285 VA
