2-2. Voltage adjustment channel setup
1. Press the V key.
2. Turn a rotary encoder and set the adjusting channel.
3. Press the MEMORY key.
4. Select the OUTPUT SELECT of the channel to adjust.
2-3. Connection of constant apparatus
Connect the output CH to adjust PWA, and COM terminal to DMM.
2-4. Voltage rating 100% adjustment
1. Set up a voltage display in DIGIT key and a rotary encoder. (refer to the following list)
2. Turn on MAIN OUTPUT
3. Adjust in DIGIT key and a rotary encoder so that it becomes within the limits of the following list of the value of
DMM.
4. Press the MEMORY key.
MODEL NAME SETTING VOLTAGE ADJUSTMENT RANGE
CH1 18.00 V
CH2 -18.00 V
CH3 8.000 V
PW18-1.8AQ
CH4 -6.000 V
CH1 18.00 V
CH2 -18.00 V
PW18-1.3AT
CH3 6.000 V
CH1 18.00 V
PW18-3AD
CH2 -18.00 V
CH1 36.00 V
PW36-1.5AD
CH2 -36.00 V
CH1 18.00 V
PW18-3ADP
CH2 18.00 V
CH1 36.00 V
CH2 18.00 V
PW18-2ATP
CH3 8.000 V
CH1 6.000 V
PW16-5ADP
CH2 16.00 V
CH1 8.000 V
CH2 8.000 VPW8-3ATP
CH3 18.00 V
CH1 26.00 V
CH2 -26.00 VPW26-1AT
CH3 6.00 V
CH1 36.00 V
PW36-1.5ADP
CH2 36.00 V
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
