Kenwood PW-A series User Manual

PW-A
38
PARTS LIST (ELECTRICAL)
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
A01-4125-01 CASE; TOP
A13-2280-11 FRAME; AC INLET
A29-0526-04 PANEL
A40-0733-01 CASE; BOTTOM
A63-0423-12 FRONT PANEL (PW18-1.8AQ)
A63-0427-12 FRONT PANEL (PW18-3AD)
A63-0428-12 FRONT PANEL (PW36-1.5AD)
A63-0429-12 FRONT PANEL (PW18-2ATP)
A63-0430-12 FRONT PANEL (PW18-3ADP)
A63-0461-02 FRONT PANEL (PW16-5ADP)
A63-0462-02 FRONT PANEL (PW8-3ATP)
A63-0464-02 FRONT PANEL (PW36-1.5ADP)
A83-0231-03 REAR PANEL
B09-0408-03 CAP
B11-0597-23 FILTER (PW18-1.8AQ)
B11-1701-23 FILTER (PW18-3AD)
B11-1702-23 FILTER (PW36-1.5AD)
B11-1703-23 FILTER (PW18-2ATP)
B11-1704-23 FILTER (PW18-3ADP)
B11-1719-03 FILTER (PW16-5ADP)
B11-1720-03 FILTER (PW8-3ATP)
B11-1722-03 FILTER (PW36-1.5ADP)
B41-2083-04 CAUTION LABEL; PL GND
B42-3819-05 SERIAL NO. PLATE
B42-6230-05 MODEL NO. PLATE
B63-0541-10 INSTRUCTION MANUAL; JAPANESE
B63-0542-10 INSTRUCTION MANUAL; ENGLISH
E21-0825-13 TERMINAL
E29-0506-04 SHORTING BAR
E30-1929-05 BS POWER CORD
E30-1952-05 CEE POWER CORD
E30-1967-05 JIS POWER CORD
E70-0653-03 TERMINAL BLOCK (PW18-1.8AQ, PW18-2ATP, PW8-3ATP)
E70-0654-03 TERMINAL BLOCK (PW18-3AD, PW36-1.5AD, PW18-3ADP, PW16-5ADP, PW36-1.5ADP)
F01-2414-01 HEAT SINK
F05-1623-05 FUSE T1.6A/250V (5✽20)
F05-3121-05 FUSE T3.15A/250V (5✽20)
F07-1538-03 COVER; TOP (REAR PANEL)
F09-0535-05 FAN
F10-2596-04 SHIELD PLATE
F20-3080-03 INSULATOR SHEET; TOP
F20-3081-12 INSULATOR SHEET; CPU UNIT
F20-3086-03 INSULATOR SHEET; AMP UNIT
F20-3087-03 INSULATOR SHEET; AMP UNIT
F20-3088-14 INSULATOR SHEET; HEAT SINK
H10-2906-15 FOAMED STYREN PAD; FRONT
H10-2907-15 FOAMED STYREN PAD; REAR
H13-1213-05 CARTON BOARD
H20-1743-04 VINYL COVER
H53-0368-03 CARTON BOX
J02-0363-04 RUBBER FOOT
J21-4843-04 BRACKET; HANDLE
Name & Description
J21-9047-04 BRACKET; FET
J21-9048-02 BRACKET; POWER TRANSFORMER
J59-0403-05 NYLON RIVET
K01-0556-15 HANDLE
K21-0907-14 KNOB; ENCORDER
K29-7245-11 BUTTON; CLEAR (PW18-1.8AQ)
K29-7251-11 BUTTON; CLEAR (PW18-2ATP, PW8-3ATP)
K29-7252-11 BUTTON; CLEAR (PW18-3AD, PW36-1.5AD, PW18-3ADP, PW16-5ADP, PW36-1.5ADP)
K29-7257-02 KNOB; TERMINAL (RED)
K29-7258-02 KNOB; TERMINAL (BLACK)
K29-7259-02 KNOB; TERMINAL (WHITE) (PW18-1.8AQ, PW18-3AD, PW36-1.5AD)
K29-7260-02 KNOB; TERMINAL (BLUE)
L07-1587-05 POWER TRANSFORMER (PW18-1.8AQ)
L07-1589-05 POWER TRANSFORMER (PW18-3AD, PW18-3ADP)
L07-1590-05 POWER TRANSFORMER (PW36-1.5AD, PW36-1.5ADP)
L07-1591-05 POWER TRANSFORMER (PW18-2ATP)
L07-1595-05 POWER TRANSFORMER (PW16-5ADP)
L07-1596-05 POWER TRANSFORMER (PW8-3ATP)
N09-4557-05 SCREW, SEMS PAN HD (M4✽60)
N09-4558-05 SPECIAL SCREW (M3✽6)
N11-0030-41 FRANGE NUT (M3)
N11-0040-41 FRANGE NUT (M4)
N32-3008-41 SCSREW, FLAT HD (M3✽8)
N32-4010-41 SCSREW, FLAT HD (M4✽10)
N33-3006-41 SCREW, OVAL HD (M3✽6)
N66-3008-41 SCREW, SEMS PAN HD (M3✽8)
N66-4008-41 SCREW, SEMS PAN HD (M4✽8)
N66-4010-41 SCREW, SEMS PAN HD (M4✽10)
N66-4035-41 SCREW, SEMS PAN HD (M4✽35)
N67-3010-41 SCREW, SEMS PAN HD (M3✽10)
N67-3016-41 SCREW, SEMS PAN HD (M3✽16)
X66-1820-xx PANEL UNIT
X68-2210-xx POWER SUPPLY UNIT
X68-2300-00 POWER SUPPLY UNIT (PW16-5ADP)
X73-2320-xx AMP UNIT
X77-2380-xx CPU UNIT
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
Name & Description
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
Parts No.
Parts No.
PW-A SERIES
