Kenwood PW-A series User Manual

PW-A
39
PARTS LIST
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
1
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
Ref. No
Name & Description
-00
-01
Parts No.
-02
0.5 0.5 0.5 J73-0749-03 PCB(UNMOUNTED)
C1 1 1 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
C2 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C3 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C4 1 1 1 CK73GF1E104Z CAP. CERAMIC 0.1µ -20/80% 25V
C5 1 1 1 CK73GB1H103K CAP. CERAMIC 0.01µ 10% 50V
CN2 1 1 1 E40-5314-05 PIN CONNECTOR 25P
D1 1 1 1 B30-3058-05 LED; RED
D2 1 1 1 B30-3058-05 LED; RED
D3 1 1 1 B30-3058-05 LED; RED
D4 1 1 1 B30-3058-05 LED; RED
D5 1 1 1 B30-3058-05 LED; RED
D6 1 1 1 B30-3058-05 LED; RED
D7 1 1 1 B30-3058-05 LED; RED
D8 1 1 1 B30-3058-05 LED; RED
D9 1 1 1 B30-3058-05 LED; RED
D10 1 1 1 B30-3058-05 LED; RED
D11 1 1 1 B30-3058-05 LED; RED
ED1 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED2 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED3 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED4 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED5 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED6 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED7 1 1 1 B30-3045-05 LED; 7-SEGMENT
ED8 1 1 1 B30-3045-05 LED; 7-SEGMENT
IC1 1 1 1 TB62709F IC
IC2 1 1 1 TB62709F IC
IC3 1 1 1 TB62709F IC
R1 1 1 1 RK73FB2A472J RES.CHIP (2✽1.25) 4.7k 5% 1/10W
R2 1 1 1 RK73FB2A472J RES.CHIP (2✽1.25) 4.7k 5% 1/10W
R3 1 1 1 RK73FB2A102J RES.CHIP (2✽1.25) 1k 5% 1/10W
R4 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R5 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R6 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R7 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R8 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R9 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R10 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R11 1 1 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R12 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R13 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
R14 1 RK73FB2A101J RES.CHIP (2✽1.25) 100 5% 1/10W
S1 1 1 1 S70-0644-05 TACT SWITCH
S2 1 1 1 S70-0644-05 TACT SWITCH
S3 1 1 1 S70-0644-05 TACT SWITCH
S4 1 1 1 S70-0644-05 TACT SWITCH
S5 1 1 1 S70-0644-05 TACT SWITCH
S6 1 1 1 S70-0644-05 TACT SWITCH
S7 1 1 1 S70-0644-05 TACT SWITCH
S8 1 1 1 S70-0644-05 TACT SWITCH
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
2
L : Scandinavia K : USA P : Canada R : Mexico
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany
Y : AAFES(Europe) X : Australia M : Other Areas indicates safety critical components .
Ref. No
Name & Description
-00
-01
Parts No.
-02
S9 1 1 1 S70-0645-05 TACT SWITCH
S10 1 1 1 S70-0645-05 TACT SWITCH
S11 1 1 S70-0645-05 TACT SWITCH
S12 1 S70-0645-05 TACT SWITCH
S13 1 1 1 S70-0646-05 TACT SWITCH
S14 1 1 1 S70-0646-05 TACT SWITCH
S15 1 1 1 S70-0645-05 TACT SWITCH
S16 1 1 1 S70-0645-05 TACT SWITCH
S17 1 1 S70-0645-05 TACT SWITCH
S18 1 S70-0645-05 TACT SWITCH
S19 1 1 1 S70-0646-05 TACT SWITCH
S20 1 1 1 S70-0646-05 TACT SWITCH
S21 1 1 1 S70-0644-05 TACT SWITCH
S22 1 1 1 S70-0644-05 TACT SWITCH
S23 1 1 1 S70-0646-05 TACT SWITCH
S24 1 1 1 S70-0644-05 TACT SWITCH
S25 1 1 1 W02-4039-05 ROTARY ENCODER
PANEL UNIT (X66-1820-XX)
