ADJUSTMENT
MODEL NAME SETTING VOLTAGE
ADJUSTMENT
VOLTAGE
ADJUSTMENT
RANGE
SHUNT
REGISTER
CH1 3.000 A 0.300 V
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
± 0.1 mV
PW18-3ADP
CH2 3.000 A 0.300 V
CH1 1.000 A 1.000 V
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
CH2 2.000 A 2.000 V
PW18-2ATP
CH3 2.000 A 2.000 V
CH1 3.000 A 0.300 V
PW16-5ADP
CH2 5.000 A 0.500 V
CH1 3.000 A 0.300 V
CH2 3.000 A 0.300 V
PW8-3ATP
CH3 1.500 A 1.500 V
CH1 1.000 A 1.000 V
CH2 1.000 A 1.000 VPW26-1AT
CH3 5.000 A 0.500 V
CH1 1.500 A -0.300 V
PW36-1.5ADP
CH2 1.500 A 1.500 V
CH1 1.300 A 1.300 V
CH2 -1.300 A -1.300 VPW18-1.3ATS
CH3 5.000 A 0.500 V
CH1 1.000 A -1.300 V
CH2 1.000 A 0.500 V
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
PW26-1ATS
CH3 5.000 A 0.300 V
100 m Ω
100 m Ω
100 m Ω
100 m Ω
100 m Ω
100 m Ω
100 m Ω
100 m Ω
100 m Ω
3-5. Current rating 10 % adjustment
1. Set up a current display in DIGIT key and a rotary encoder. (refer to the following list)
2. Turn on MAIN OUTPUT.
3. Adjust in DIGIT key and a rotary encoder so that it becomes within the limits of the following list of the value of
DMM.
4. Press the MEMORY key.
MODEL NAME SETTING VOLTAGE
ADJUSTMENT
VOLTAGE
ADJUSTMENT
RANGE
SHUNT
REGISTER
CH1 0.180 A 0.180 V
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
± 1 mV
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
1 Ω
CH2 -0.180 A -0.180 V
CH3 0.200 A 0.200 V
PW18-1.8AQ
CH4 0.100 A 0.100 V
CH1 0.130 A 0.130 V
CH2 -0.130 A -0.130 VPW18-1.3AT
CH3 0.500 A 0.500 V
CH1 0.300 A 0.300 V
PW18-3AD
CH2 -0.300 A -0.300 V
CH1 0.150 A 0.150 V
PW36-1.5AD
CH2 -0.150 A -0.150 V
