Common Specifications of PW-A Series
ITEMS Rating
Set delay time 0.0 to 10.0 seconds
Functions Described in panels and functions and operation procedures.
Grounding Positive, COM or negative grounding is possible.
Protection MAIN OUTPUT key is turned off if exhaust air temperature
becomes too high.
Heat radiation Forced air cooling. Fan revolution is in proportion to exhaust air
temperature.
Input voltage 100, 115, 200 and 230 VAC, 50/60 Hz selectable.
Voltage fluctuation : ±10%
Operating temperature
range
0 to 40°C
Operating humidity range 30 to 85% RH (No dew condensation)
Storage temperature
range
-20 to +60°C
Storage humidity range 20 to 85% RH (No dew condensation)
Primary - casing : 1500 VAC for 1 minute Dielectric strength voltage
Primary - secondary : 1500 VAC for 1 minute
Primary - casing & primary - secondary : 10 MΩ or more at 500
VDC
Insulation resistance
Secondary
-
casing : 5 MΩ or more at 250 VDC
To-earth voltage ±250 VDC
Freme dimentions [mm] 138 (W) x 124 (H) x 380 (D)
Max. dimentions [mm] 140 (W) x 147.9 (H) x 402.9 (D)
Weight Approx. 9.1 kg
Accessories AC power cable : 1, instruction manual : 1
Lead wires with connectors for external contact control : 1
Lead wires with sensing terminals
(PW18-1.3ATS, PW26-1ATS
only) : 2
Specifications of YB option
The YB option is a vailable. This factory o ption lo wers th e out put voltage qu ickly when output is
turned off with no load or light load.
"YB" is added to the product code of a model with this option. (Example: PW18-1.8AQYB)
ITEMS Specifications
Output voltage fall time
(90% of rated
voltage→10%)
Output lower than 10 V : 50 ms or less
10 V or higher output : 100 ms or less
Residual voltage
20 mV or less
Specifications of remote sensing terminal
ITEMS Rating
Compensation voltage
range
1 V (per wire)
* The performances and voltage display specifications of the PW18-1.3ATS and PW26-1ATS are
the values at the sensing end.
Their transient responses are the values when the sensing function is not used.
